AKG DMM8 UL - Eight-Channel Automatic Microphone Mixer with LAN and AMX Control
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
Engineered and made in Germany, the DMM8 U digital automatic microphone mixer is ideal for large meetings and conferences. Its DSP function ensures precise mixing of up to 80 channels by cascading up to 10 DMM8 U mixers. Two additional stereo audio outputs and one stereo USB offer additional routing options. Due to high signal-to-noise ratio, the DMM8 U also keeps noise from multiple open microphones to a minimum. Numerous DSP functions such as filters, compressor/limiter, ducking and routing make the DMM8 U a great fit in a variety of spoken word applications.
The UL version offers a LAN interface via Ethernet to enable the control over large distances using, for instance, an AMX control system.
Features:
- 12 band graphic EQ on outputs for optimized loudspeaker tuning
- 6 programmable presets for easy/fast tailoring to different situations
- Two channel USB streaming In and Out to interface with IT networks
- Up to 10 units cascadable for simultaneous use of up to 80 channels
- Digital signal processing and sophisticated mixing algorithm to feed in e.g. a laptop signal for wireless multimedia presentations
- Audio matrix routing of all inputs to all outputs for creating multiple mixes of multiple output combinations
Applications:
- Large meeting areas
- Conferencing
- Round table discussions in TV shows
| Number of input channels | 6x: Line, Mic, Aux, mono, stereo USB (= 2 channels) All analog inputs phoenix type |
| Number of output channels | 2x analog, 2x USB Out, Rec and USB out. Each 2 channels. |
| DSP functions | Treble, Bass, Low Cut, Limiter, Compressor, Automix, Priority, Pan/Balance, Delay |
| Presets | 6 free programmable presets |
| Phantom power | + 48 V, max. 10 mA per input |
| Type | symmetrical |
| Level | - 60 dBu to 0 dBu |
| FRQ range | +/- 3 dB 20Hz Ð 20 kHz |
| THD / N | < 0.1% |
| Noise level (22 Hz Ð 22 kHz, QPK) | < -120 dBu |
| Dynamics | > 100 dB |
| Distortion headroom | 20 dB |
| S/N (22 Hz - 22 kHz, RMS, A-Filter) | > 90 dB |
| Included Accessories | Power Cable |
Engineered and made in Germany, the DMM8 U digital automatic microphone mixer is ideal for large meetings and conferences. Its DSP function ensures precise mixing of up to 80 channels by cascading up to 10 DMM8 U mixers. Two additional stereo audio outputs and one stereo USB offer additional routing options. Due to high signal-to-noise ratio, the DMM8 U also keeps noise from multiple open microphones to a minimum. Numerous DSP functions such as filters, compressor/limiter, ducking and routing make the DMM8 U a great fit in a variety of spoken word applications.
The UL version offers a LAN interface via Ethernet to enable the control over large distances using, for instance, an AMX control system.
Features:
- 12 band graphic EQ on outputs for optimized loudspeaker tuning
- 6 programmable presets for easy/fast tailoring to different situations
- Two channel USB streaming In and Out to interface with IT networks
- Up to 10 units cascadable for simultaneous use of up to 80 channels
- Digital signal processing and sophisticated mixing algorithm to feed in e.g. a laptop signal for wireless multimedia presentations
- Audio matrix routing of all inputs to all outputs for creating multiple mixes of multiple output combinations
Applications:
- Large meeting areas
- Conferencing
- Round table discussions in TV shows
| Number of input channels | 6x: Line, Mic, Aux, mono, stereo USB (= 2 channels) All analog inputs phoenix type |
| Number of output channels | 2x analog, 2x USB Out, Rec and USB out. Each 2 channels. |
| DSP functions | Treble, Bass, Low Cut, Limiter, Compressor, Automix, Priority, Pan/Balance, Delay |
| Presets | 6 free programmable presets |
| Phantom power | + 48 V, max. 10 mA per input |
| Type | symmetrical |
| Level | - 60 dBu to 0 dBu |
| FRQ range | +/- 3 dB 20Hz Ð 20 kHz |
| THD / N | < 0.1% |
| Noise level (22 Hz Ð 22 kHz, QPK) | < -120 dBu |
| Dynamics | > 100 dB |
| Distortion headroom | 20 dB |
| S/N (22 Hz - 22 kHz, RMS, A-Filter) | > 90 dB |
| Included Accessories | Power Cable |
