Lectrosonics SRc - Dual-Channel Slot-Mount Digital Hybrid Wireless Receiver (Block 941 / 941-960 MHz)

The SRc5P and SRc consists of two separate receivers built into a single, ultra compact housing with adapters for video camera receiver slots and for stand-alone use. Digital Hybrid Wireless¨ technology provides superb, compandor-free audio quality and compatibility with other wireless systems. The RF performance is extremely stable over a very wide temperature range, making the receiver perfectly suited to the rough environmental conditions found in field production.

Features:

• Fits camera "slots," Lectrosonics Duopack adapter and Octopack multicoupler, and operates stand-alone with various adapters
• Tunes over a 75 MHz range* (3 blocks)
• Dual receiver design for two channels with phase switched diversity or single channel with ratio diversity operation
• Digital Hybrid Wireless¨ with compatibility modes for use with other transmitters
• Tracking front-end filters for high performance in tough RF environments
• LCD with RF spectrum scanning
• SmartSquelchTM DSP-controlled, noise based filtering and squelch
• DSP-based pilot tone for squelch control
• IR sync port for quick transmitter setup (LMb, LT, HHa, HMa, & SSM)
• SmartTune operation for quick and confident frequency selection

DSP compatibility modes allow the receiver to be used with a variety of Lectrosonics systems, other brands of wireless systems and with Lectrosonics IFB transmitters.

Included Accessories:

• 1 - Adjustment Tool (Part# 35679)
• 2 - Antennas (Part #AMJ-XX)
• 1 - Quickstart Guide

Ikegami
All current Ikegami camcorders with Uni-Slot receiver mounts are dual-channel capable in the slot with a simple switch activation on the UI board, including models:

• HDS-V10
• HDN-X10
• DNS-33W

Panasonic
SR Compatibility with Panasonic Professional Camcorders:

Cameras currently shipping with the two-channel* audio operation within the receiver slot (Unislot) with the SR/SRa Receivers. If you have an older version of these cameras,
you may need a firmware upgrade available from Panasonic.

• AG-HPX300
• AJ-HPX2000
• AJ-HPX2100
• AJ-HPX2700
• AJ-HPX3000
• AJ-HPX3700

*Note: SRc, Src5P, SRb, SRb5p, SR, SRa, SR5P and SRa5P Receivers all operate in diversity mode in either single or dual-channel modes.

Cameras requiring SRa5P Receiver and external audio inputs for two channel operation.

• AG-HPX500
• AG-HDX900
• AJ-SPX900/800
• AJ-SPC700
