PreSonus Studio 1824c - 18x18, 192 kHz, USB-C Audio Interface
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The Studio 1824c USB-C audio interface is ideal for project studios and bands/producers interested in recording full bands including multi-channel drums. It records up to 18 simultaneous inputs at up to 24-bit/192 kHz and offers 8 microphone inputs with XMAX Class A preamps and ADAT and S/PDIF I/O. Its 18 outputs offer flexible routing with zero-latency DSP-based monitor mixing and control-room integration with included Studio One® Artist for macOS® and Windows® and UC Surface for macOS, Windows, iPad®, and Android. In addition to stereo main outputs with a dedicated mute and mono button, you get eight balanced, DC-coupled line outputs; two headphone outputs with independent mix streams; word clock output; and MIDI I/O. PreSonus' Studio Magic Plug-in Suite is included, and USB-C to USB-C and USB-C to USB-A cables are provided for compatibility with most computers.
Features:
- 24-bit/192 kHz, USB-C 18x8 audio interface (8x6 at 192 kHz)
- 2 mic/instrument/line inputs and 2 mic/line inputs all with XMAX Class A mic preamps and +48V phantom power
- 4 back panel 1/4" TRS balanced line inputs
- 8 channels of ADAT Optical input (4 channels at 96 kHz)
- 2 1/4" TRS balanced DC coupled main outputs with level control and dedicated mute button
- 4 1/4" TRS balanced DC coupled line outputs
- 2 headphone outputs with A/B switching on headphone output 1
- LED metering for all analog inputs and main outputs
- S/PDIF and MIDI I/O
- Flexible routing, zero-latency monitor mixing, and control-room integration with included Studio One Artist
- Monitor mix control with free UC Surface for macOS®, Windows®, iPad®, and Android
- USB-C to USB-C and USB-C to USB-A cables included
- Studio Magic Plug-in Suite included
| Performance | |
| Digital Audio Bit Depth | 24 Bit |
| Digital Audio Dynamic Range | 114 dB |
| Electronics | |
| Connectivity | USB-C¨ |
| Headphone Jack | 1/4" TRS Active Stereo |
| Inputs | Eight - Eight Combo Mic/Instrument/Line Inputs (XLR Female Balance, 1/4" TS Female Unbalanced (Inst)) |
| Line Out | Four - 1/4" TRS Balanced, DC Coupled |
| Phantom Power | +48 VDC |
| Voltage Requirements | 100-240 VAC, 50-60 Hz |
| Input | |
| Instrument Inputs Dynamic Range | 112 dB (A-Weighted, Minimum Gain) |
| Instrument Inputs Frequency Response | 20 Hz - 20 kHz (Minimum Gain) |
| Instrument Inputs Gain Range | 80 dB |
| Instrument Inputs Maximum Level | +15 dBu (Unbalanced, Minimum Gain) |
| Line Inputs Dynamic Range | 112 dB (A-Weighted, Minimum Gain) |
| Line Inputs Frequency Response | 20 Hz - 20 kHz (Unity Gain) |
| Line Inputs Gain Range | 40 dB |
| Line Inputs Impedance | 10 k½ |
| Line Inputs Maximum Level | +21 dBu (Balanced, Minimum Gain) |
| Line Inputs Total Harmonic Distortion | 0.005% (1 kHz, +18 dBu, Minimum Gain) |
| Microphone Input Connection Type | XLR Female (Combo), Balanced |
| Microphone Preamp Dynamic Range | 110 dB (A-Weighted, Minimum Gain) |
| Microphone Preamp Equivalent Input Noise | -128 dBu (A-Weighted, 20 kHz BW, Rs=150½, Maximum Gain) |
| Microphone Preamp Frequency Response | 20 Hz - 20 kHz (Unity Gain) |
| Microphone Preamp Gain Control Range | 80 dB |
| Microphone Preamp Input Impedance | 1.4 k½ |
| Microphone Preamp Maximum Input Level | +16 dBu, Minimum Gain |
| Microphone Preamp Total Harmonic Distortion | 0.005% (1 kHz, 0dBu, Unity Gain) |
| Output | |
| Headphone Outputs Dynamic Range | 103 dB (A-weighted, 1 kHz, Unity Gain) |
| Headphone Outputs Frequency Response | 20 Hz - 20 kHz (Unity Gain) |
| Headphone Outputs Impedance Working Range | 32½ to 600½ |
| Headphone Outputs Maximum Output | 150 mW/Channel (60½ Load) |
| Headphone Outputs Total Harmonic Distortion | 0.250% (1 kHz, 150 mW, Unity Gain) |
| Line Outputs Connection Type | 1/4" TRS Female |
| Main And Line Outputs Dynamic Range | 108 dB (A-Weighted, Unity Gain) |
| Main And Line Outputs Frequency Response | 20 Hz - 20 kHz (Unity Gain) |
| Main And Line Outputs Maximum Level | +18 dBu (Balanced) |
| Main And Line Outputs Total Harmonic Distortion | 0.004% (1 kHz, -1 dBFS, Unity Gain) |
| Main Outputs Connection Type | 1/4" TRS Female |
| Measurements | |
| Product Depth | 5.5" (140 mm) |
| Product Height | 1.75" (44.45 mm) |
| Product Width | 19" (483mm) |
| Miscellaneous | |
| Commodity Code | 8517.62.0090 |
| Power Cable | 12 VDC, External Power Supply |
| Supported Sample Rates | 44.1, 48, 88.2, 96, 176.4, 192 kHz (kHz) |
The Studio 1824c USB-C audio interface is ideal for project studios and bands/producers interested in recording full bands including multi-channel drums. It records up to 18 simultaneous inputs at up to 24-bit/192 kHz and offers 8 microphone inputs with XMAX Class A preamps and ADAT and S/PDIF I/O. Its 18 outputs offer flexible routing with zero-latency DSP-based monitor mixing and control-room integration with included Studio One® Artist for macOS® and Windows® and UC Surface for macOS, Windows, iPad®, and Android. In addition to stereo main outputs with a dedicated mute and mono button, you get eight balanced, DC-coupled line outputs; two headphone outputs with independent mix streams; word clock output; and MIDI I/O. PreSonus' Studio Magic Plug-in Suite is included, and USB-C to USB-C and USB-C to USB-A cables are provided for compatibility with most computers.
Features:
- 24-bit/192 kHz, USB-C 18x8 audio interface (8x6 at 192 kHz)
- 2 mic/instrument/line inputs and 2 mic/line inputs all with XMAX Class A mic preamps and +48V phantom power
- 4 back panel 1/4" TRS balanced line inputs
- 8 channels of ADAT Optical input (4 channels at 96 kHz)
- 2 1/4" TRS balanced DC coupled main outputs with level control and dedicated mute button
- 4 1/4" TRS balanced DC coupled line outputs
- 2 headphone outputs with A/B switching on headphone output 1
- LED metering for all analog inputs and main outputs
- S/PDIF and MIDI I/O
- Flexible routing, zero-latency monitor mixing, and control-room integration with included Studio One Artist
- Monitor mix control with free UC Surface for macOS®, Windows®, iPad®, and Android
- USB-C to USB-C and USB-C to USB-A cables included
- Studio Magic Plug-in Suite included
| Performance | |
| Digital Audio Bit Depth | 24 Bit |
| Digital Audio Dynamic Range | 114 dB |
| Electronics | |
| Connectivity | USB-C¨ |
| Headphone Jack | 1/4" TRS Active Stereo |
| Inputs | Eight - Eight Combo Mic/Instrument/Line Inputs (XLR Female Balance, 1/4" TS Female Unbalanced (Inst)) |
| Line Out | Four - 1/4" TRS Balanced, DC Coupled |
| Phantom Power | +48 VDC |
| Voltage Requirements | 100-240 VAC, 50-60 Hz |
| Input | |
| Instrument Inputs Dynamic Range | 112 dB (A-Weighted, Minimum Gain) |
| Instrument Inputs Frequency Response | 20 Hz - 20 kHz (Minimum Gain) |
| Instrument Inputs Gain Range | 80 dB |
| Instrument Inputs Maximum Level | +15 dBu (Unbalanced, Minimum Gain) |
| Line Inputs Dynamic Range | 112 dB (A-Weighted, Minimum Gain) |
| Line Inputs Frequency Response | 20 Hz - 20 kHz (Unity Gain) |
| Line Inputs Gain Range | 40 dB |
| Line Inputs Impedance | 10 k½ |
| Line Inputs Maximum Level | +21 dBu (Balanced, Minimum Gain) |
| Line Inputs Total Harmonic Distortion | 0.005% (1 kHz, +18 dBu, Minimum Gain) |
| Microphone Input Connection Type | XLR Female (Combo), Balanced |
| Microphone Preamp Dynamic Range | 110 dB (A-Weighted, Minimum Gain) |
| Microphone Preamp Equivalent Input Noise | -128 dBu (A-Weighted, 20 kHz BW, Rs=150½, Maximum Gain) |
| Microphone Preamp Frequency Response | 20 Hz - 20 kHz (Unity Gain) |
| Microphone Preamp Gain Control Range | 80 dB |
| Microphone Preamp Input Impedance | 1.4 k½ |
| Microphone Preamp Maximum Input Level | +16 dBu, Minimum Gain |
| Microphone Preamp Total Harmonic Distortion | 0.005% (1 kHz, 0dBu, Unity Gain) |
| Output | |
| Headphone Outputs Dynamic Range | 103 dB (A-weighted, 1 kHz, Unity Gain) |
| Headphone Outputs Frequency Response | 20 Hz - 20 kHz (Unity Gain) |
| Headphone Outputs Impedance Working Range | 32½ to 600½ |
| Headphone Outputs Maximum Output | 150 mW/Channel (60½ Load) |
| Headphone Outputs Total Harmonic Distortion | 0.250% (1 kHz, 150 mW, Unity Gain) |
| Line Outputs Connection Type | 1/4" TRS Female |
| Main And Line Outputs Dynamic Range | 108 dB (A-Weighted, Unity Gain) |
| Main And Line Outputs Frequency Response | 20 Hz - 20 kHz (Unity Gain) |
| Main And Line Outputs Maximum Level | +18 dBu (Balanced) |
| Main And Line Outputs Total Harmonic Distortion | 0.004% (1 kHz, -1 dBFS, Unity Gain) |
| Main Outputs Connection Type | 1/4" TRS Female |
| Measurements | |
| Product Depth | 5.5" (140 mm) |
| Product Height | 1.75" (44.45 mm) |
| Product Width | 19" (483mm) |
| Miscellaneous | |
| Commodity Code | 8517.62.0090 |
| Power Cable | 12 VDC, External Power Supply |
| Supported Sample Rates | 44.1, 48, 88.2, 96, 176.4, 192 kHz (kHz) |
