Zaxcom ERX3TCD Zaxnet IFB Audio and Timecode Receiver

  • Dale #:

    ZAXC-ERX3TCD
  • Availability:

    Usually ships in 5 - 10 Days
  • This item usually ships within 5-10 days after your order is placed. Your payment will be charged after completing checkout.

Description

The updated ERX3TCD features an OLED display, locking headphone connector a practically unbreakable rubber volume knob. It receives high quality encrypted digital audio and timecode from any ZaxNet source. The OLED display shows timecode, user bits, current Scene and Take metadata in real time wi... Read More

Free Shipping (Continental US)

Have a Question?

Call Toll Free: 888-462-7828 Live Chat Email Us

Description

The updated ERX3TCD features an OLED display, locking headphone connector a practically unbreakable rubber volume knob. It receives high quality encrypted digital audio and timecode from any ZaxNet source. The OLED display shows timecode, user bits, current Scene and Take metadata in real time with a hold button to freeze the display. An adjustable delay can be set to match audio to monitors with various video lag due to video signal processing.

Mounted on a camera or slate the ERX3TCD can provide frame accurate timecode with no drift since it is constantly receiving and updating its timecode from the source. There is also a 1kHz notch filter to eliminate the transmission of tone that is sometimes sent from the mixing console. The notch filter frequency is adjustable and using it won't affect the quality of your IFB audio.

Features:

  • ENCRYPTED AUDIO
    keeps transmitted audio private
  • TIMECODE
    built-in timecode reader and generator
  • ZAXNET
    provides wireless timecode, ZaxNet audio and remote control between Zaxcom products
  • AUDIO
    Monitor high quality audio anywhere on set or mount your ERX on a camera to feed an audio scratch track.
  • TIMECODE
    Mount on a camera or digital slate to jam frame accurate timecode wirelessly. The ERX will constantly re-jam time code from any ZaxNet transmitter so you will never experience any drift.
  • DELAY
    Grumpy director at Video Village? No problem... with an ERX you can delay the audio up to 12 frames to match their picture.

More +

Product Specs

RECEIVER RF Frequency: 2.403 GHz to 2.475 GHz
RF Bandwidth: 1MHz
Frequency Spacing: 2MHz
System channels: 36
TIMECODE Timecode output: SMPTE
Timecode output level: .01VPP to 3VPP
PHYSICAL Display: OLED
Size: 4.1″ x 2.4″ x .6″
Weight: 3oz
Battery: 2 x AA
Battery life: approximately 12 hours
OUTPUT Audio output impedance: 16 ohm
Audio output level max: +10dB
Audio output format: 2 channel mono
Connector: 1/4" (3.5mm) locking

More +
