360 Systems TSS-2100 - 2 Channel HD / SD Server 4TB Storage


  • Dale #:

    360S-TSS2100
  • Availability:

    Not in Stock - Reserve Yours
  • This item is not in stock, but we can usually ship it within 10-20 days after your order is placed. Your payment will be charged after completing checkout.

Description

2 Channel SD & HD Compact, up to 8TB of Storage The Reliable, Multi Format Video Server. The TSS - 2100 offers a single bi-directional channel and a single playout channel while the TSS - 2200 allows both channels to be either record or playout.Features 2 Channels, 1 Record/Playout and 1 Play... Read More

Contact us

Shipping Charges Apply

Have a Question?

Call Toll Free: 888-462-7828 Live Chat Email Us

Suggested Accessories

Description

2 Channel SD & HD Compact, up to 8TB of Storage The Reliable, Multi Format Video Server. The TSS - 2100 offers a single bi-directional channel and a single playout channel while the TSS - 2200 allows both channels to be either record or playout.

Features

  • 2 Channels, 1 Record/Playout and 1 Playout - TSS - 2100
  • 1U, Short Chassis Form Factor
  • 16 Channels Embedded Audio
  • H.264 and MPEG2 Encoding / Decoding
  • Automatic Up/Down/Cross Conversion of HD or SD content
  • Remote Control From PC’s via Ethernet
  • Redundant Power / Cooling

360 Systems' constantly strives to produce smaller and more affordable video servers without sacrificing quality or reliability. The new TSS class of server furthers this goal. With a shorter 1U chassis, the TSS fits in more confined spaces and its lower cost makes it the budget conscious model. All of this is accomplished on the same great platform as the larger TSS servers.

- Flexibility, Reliability, Simplicity… at an affordable price.

Video

  • Record and play in 720p, 1080i or SD on any channel
  • Various standard codec and file formats are accepted for playout, such as H.264 or MPEG-2 in .mxf, .mp4, .mpg or .mov containers.
  • Independently configure each output to broadcast in 720p, 1080i or SD
  • Perform jog and shuttle for rapid movement within a clip
  • Smooth slow motion playout
  • 16 channels of embedded audio per video channel
  • Configurable for 29.97/59.94 or 25/50
  • High quality 10 bit video and 24 bit audio support

Reliability

  • Redundant cooling and power
  • Redundant RAID 5 storage
  • Linux based operating system

Connectivity

  • HD-SDI, SD-SDI compatibility
  • Gigabit Ethernet
  • Serial port control for each channel via the VDCP or Odetics protocols for use with automation or remote controls
  • Independent GPI inputs and outputs (12 each) for external triggering or control

Software

  • Automatic conversion plays SD and HD files back-to-back
  • Local software GUI
  • Remote control from a PC
  • Record & playlisting

TSS Applications

  • Budget conscious broadcasters
  • requiring multiple channels
  • Broadcast trucks
  • Backup systems
  • Public broadcasting
  • Government meetings
  • Education
  • Stadiums
  • Record and store
  • Video insertion
  • Production

More +

Product Specs

VIDEO
    Video Input1 Channel (2 Channels with upgrade to 2200)
   Video Outputs2 Channels
   Simultaneous video streams2 (1 record 1 playout, 2 playout or (2 record on TSS – 2200 only)
   HD Input/OutputHD-SDI (SMPTE 292M), SD-SDI (SMPTE 259M)
   Video Format1080i at 29.97 or 25 Hz; 720p at 59.94 or 50 fps; 525/60 NTSC; 625/50 PAL
   Encoding FormatH.264 or MPEG2
   HS/SD ScalingUp, Down, and Cross Conversion of Any File Format to Selected Output
   Jog/ShuttleZero to 128X, forward/reverse
   Slow Motion Play with audioZero to +/- 2X, forward/reverse
   Frame AccuracyFrame accurate play, pause and stop
   Genlock InputBlackburst or tri-level
ANCILLARY DATA
   Ancillary DataHD – 608/708 in VANC; SD – Line 21 VBI
AUDIO INPUTS / OUTPUTS (per video channel)
   SDI Embedded Audio16 channels
STORAGE
   Disk Storage SystemSATA array, four – 1 or 2 Terabyte drives, RAID 5 controller
   Total Capacity8 Terabytes (4 Terabytes standard model)
   Drive ReplacementHot Swappable
CONNECTIVITY
   NetworkingGigabit Ethernet
   Serial ControlVDCP or Odetics protocols, 9-pin on CXP-5 module (optional).
   GPI Control12 Inputs, Outputs, Programmable on CXP-5 module (optional)
MISCELLANEOUS
   Fault Monitoring LEDsFront Panel LEDs, power, system, network
   Fault Monitoring OutputGPI output, open collector
   Software UpdatesUSB
   Power SupplyDual Redundant, 100-250V – 50/60 Hz. 400W, rear panel plug-in
   CoolingRedundant fans
   Chassis1-RU x 19” Rack, Weight: approx 45 lb. (22 kg)
EXPANSION MODULES
   CXP-5Serial and GPI control module. 1 RU (optional)

Specifications and availability are subject to change without notice.
