DALE SKU # 360S-TSS3100

360 Systems TSS-3100 - 3 Channel HD / SD Server, 4TB Storage

Contact us

  • Availability:

    Special Order Item
  • This item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.


  • LET OUR TEAM OF EXPERTS ASSIST YOU

    Description

    The latest iteration of the 360 Systems flagship video server introduces an even smaller form factor, playout of a recording in progress, network folder sharing and 1080p output. Plus, all of the same features as before with HD and SD compatibility and flexible file format support. All standard.

    Features

    • 3 Channels, 1 Record/Playout and 2 Playout
    • Automatic Up/Down/Cross Conversion of HD or SD content
    • H.264 and MPEG2 Encoding / Decoding
    • Automatic Up/Down/Cross Conversion of HD or SD content
    • Remote Control From PC's via Ethernet
    • Redundant Power / Cooling
    • 1U Form Factor, aprox. 1/3 shorter chassis

    360 Systems' TSS class servers are designed and built with reliability as the primary focus. It is understood that broadcasters rely on their equipment to perform trouble free for years. With this in mind, 360 Systems' servers are built utilizing server grade components to insure quality performance.

    TSS servers offer an intuitive user interface that allows quick access to the most common day to day functions. Those familiar with previous generations of 360 Systems' servers will find the transition to the TSS very simple. Even with the additional features offered by the TSS, the ease of operation will allow for a smooth installation within a broadcast workflow.

    - Flexibility, Reliability, Simplicity... at an affordable price.

    Video

    • Record and play in 720p, 1080i or SD on any channel
    • Various standard codec and file formats are accepted for playout, such as H.264 or MPEG-2 in .mxf, .mp4, .mpg or .mov containers.
    • Independently configure each output to broadcast in 720p, 1080i, 1080p or SD
    • Perform jog and shuttle for rapid movement within a clip
    • Smooth slow motion playout
    • 16 channels of embedded audio per video channel
    • Configurable for 29.97/59.94 or 25/50
    • High quality 10 bit video and 24 bit audio support

    Reliability

    • Redundant cooling and power
    • Redundant RAID 5 storage
    • Linux based operating system

    Connectivity

    • HD-SDI, SD-SDI compatibility
    • Gigabit Ethernet
    • Serial port control for each channel via the VDCP or Odetics protocols for use with automation or remote controls
    • Independent GPI inputs and outputs (12 each) for external triggering or control

    Software

    • Automatic conversion plays SD and HD files back-to-back
    • Local software GUI
    • Remote control from a PC
    • Record & playlisting

    TSS Applications

    • Program storage/Play-to-air
    • Satellite cache
    • File exchange with NLEs
    • Multi- screen projection displays
    • Corporate & Educational Displays
    • Theme parks and attractions
    • Remote workstations for ingest, trim, playlisting
    VIDEO
    Video Input1 Channel
    Video Outputs3 Channels
    Simultaneous video streams3 (1 record 2 playout or 3 playout)
    HD Input/OutputHD-SDI (SMPTE 292M), SD-SDI (SMPTE 259M)
    Video Format1080p @ 59.94 or 50 Hz (output only); 1080i at 29.97 or 25 Hz; 720p atÊ59.94 or 50 fps; 525/60 NTSC; 625/50 PAL
    Encoding FormatH.264 or MPEG2
    HS/SD ScalingUp, Down, and Cross Conversion of Any File Format to Selected Output
    Jog/ShuttleZero to 128X, forward/reverse
    Slow Motion Play with audioZero toÊ+/-Ê2X, forward/reverse
    Frame AccuracyFrame accurate play, pause and stop
    Genlock InputBlackburst or tri-level
    ANCILLARY DATA
    Ancillary DataHD Ð 608/708 in VANC; SD Ð Line 21 VBI
    AUDIO INPUTS / OUTPUTS (per video channel)
    SDI Embedded Audio16 channels
    STORAGE
    Disk Storage SystemSATA array, four Ð 1,2 or 3 Terabyte drives, RAID 5 controller
    Total Capacityup to 16 Terabytes (4 Terabytes standard model)
    Drive ReplacementHot Swappable, removable from behind front panel
    CONNECTIVITY
    NetworkingGigabit Ethernet
    File TransferFTP or secure network file share
    Serial Control3, VDCP or Odetics protocols, 9-pin on CXP-5 module (optional).
    GPI Control12 Inputs, Outputs, Programmable on CXP-5 module (optional)
    MISCELLANEOUS
    Fault Monitoring LEDsFront Panel LEDs, power, system, network
    Fault Monitoring OutputGPI output, open collector
    Software UpdatesUSB
    Power SupplyDual Redundant, 100-250V Ð 50/60 Hz. 460W, rear panel plug-in
    CoolingRedundant fans
    Chassis1-RU x 19Ó x 20? Rack, Weight: approx 48 lb. (22 kg)
    EXPANSION MODULES
    CXP-5Serial and GPI control module. 1 RU (optional)

    Specifications and availability are subject to change without notice.
