360 Systems TSS-4000 - 4 Channel HD / SD Server, 4TB Storage


Special Trade-Up Offer!
Trade-Up any old legacy server for a NEW IP Ready 360 Systems TSS Series with great savings until December 31st, 2018!.
Contact us now for more details
.

Have a Question? Call Toll Free: 888-462-7828

Live Chat Email Us
Dale #:360S-TSS4000

Availability: Usually ships in 5 - 10 Days

This item usually ships within 5-10 days after your order is placed. Your payment will be charged after completing checkout.

Call for Price

Shipping Charges Apply
  • More channels for the same price* = lower cost per channel. For those customers requiring high playout channel counts, the TSS-4000 provides exceptional cost per channel. The TSS-4000 is a compact 1U server with up to 8TB of storage and offers 4 simultaneous HD or SD playout channels. With the same software and the core reliability of the TSS line of server, the TSS-4000 is the choice for broadcast quality playout.

    *When compared to the TSS-3100

    Features

    • 4 Playout Channels
    • 16 Channels Embedded Audio
    • H.264 and MPEG2 Encoding / Decoding
    • Automatic Up/Down/Cross Conversion of HD or SD content
    • Remote Control From PC’s via Ethernet
    • Redundant Power / Cooling
    • 1U Form Factor

    360 Systems’ TSS class servers are designed and built with reliability as the primary focus. It is understood that broadcasters rely on their equipment to perform trouble free for years. With this in mind, 360 Systems’ servers are built utilizing server grade components to insure quality performance.

    TSS servers offer an intuitive user interface that allows quick access to the most common day to day functions. Those familiar with previous generations of 360 Systems’ servers will find the transition to the TSS very simple. Even with the additional features offered by the TSS, the ease of operation will allow for a smooth installation within a broadcast workflow.

    - Flexibility, Reliability, Simplicity… at an affordable price.

    Video

    • Playout in 720p, 1080i or SD on any channel
    • Various standard codec and file formats are accepted for playout, such as H.264 or MPEG-2 in .mxf, .mp4, .mpg or .mov containers.
    • Independently configure each output to broadcast in 720p, 1080i or SD
    • Perform jog and shuttle for rapid movement within a clip
    • Smooth slow motion playout
    • 16 channels of embedded audio per video channel
    • Configurable for 29.97/59.94 or 25/50
    • High quality 10 bit video and 24 bit audio support

    Reliability

    • Redundant cooling and power
    • Redundant RAID 5 storage
    • Linux based operating system

    Connectivity

    • HD-SDI, SD-SDI compatibility
    • Gigabit Ethernet
    • Serial port control for each channel via the VDCP or Odetics protocols for use with automation or remote controls
    • Independent GPI inputs and outputs (12 each) for external triggering or control

    Software

    • Automatic conversion plays SD and HD files back-to-back
    • Local software GUI
    • Remote control from a PC
    • Record & playlisting

    TSS Applications

    • Program storage/Play-to-air
    • Satellite cache
    • File exchange with NLEs
    • Multi- screen projection displays
    • Corporate & Educational Displays
    • Theme parks and attractions
    • Remote workstations for ingest, trim, playlisting
  • VIDEO
         Video Outputs4 Channels
         Simultaneous video streams4 playout
         HD Input/OutputHD-SDI (SMPTE 292M), SD-SDI (SMPTE 259M)
         Video Format1080i at 29.97 or 25 Hz; 720p at 59.94 or 50 fps; 525/60 NTSC; 625/50 PAL
         Encoding FormatH.264 or MPEG2
         HS/SD ScalingUp, Down, and Cross Conversion of Any File Format to Selected Output
         Jog/ShuttleZero to 128X, forward/reverse
         Slow Motion Play with audioZero to +/- 2X, forward/reverse
         Frame AccuracyFrame accurate play, pause and stop
         Genlock InputBlackburst or tri-level
    ANCILLARY DATA
         Ancillary DataHD – 608/708 in VANC; SD – Line 21 VBI
    AUDIO INPUTS / OUTPUTS (per video channel)
         SDI Embedded Audio16 channels
    STORAGE
         Disk Storage SystemSAS array, four – 1 or 2 Terabyte drives, Hardware RAID 5 controller
         Total Capacity8 Terabytes (4 Terabytes standard model)
         Drive ReplacementHot Swappable, removable from behind front panel
    CONNECTIVITY
         NetworkingGigabit Ethernet
         Serial Control3, VDCP or Odetics protocols, 9-pin on CXP-5 module (optional).
         GPI Control12 Inputs, Outputs, Programmable on CXP-5 module (optional)
    MISCELLANEOUS
         Fault Monitoring LEDsFront Panel LEDs, power, system, network
         Fault Monitoring OutputGPI output, open collector
         Software UpdatesUSB
         Power SupplyDual Redundant, 100-250V – 50/60 Hz. 460W, rear panel plug-in
         CoolingRedundant fans
         Chassis1-RU x 19” Rack, Weight  approx 48 lb. (22 kg)
    EXPANSION MODULES
         CXP-5Serial and GPI control module. 1 RU (optional)

    Specifications and availability are subject to change without notice.
