Cloud MA60T Compact Installation Mixer/Amplifier

  • Dale #:

    CLOU-MA60T
  • Availability:

    Not in Stock - Reserve Yours
  • This item is not in stock, but we can usually ship it within 10-20 days after your order is placed. Your payment will be charged after completing checkout.

Description

The MA60 is an exciting new development from Cloud Electronics, combining for the first time the proven versatility of Cloud mixer-amplifiers in a single compact (2U, half-rack width) unit, and at a very competitive price point. The MA60 will find many applications in the Retail, Hospitality, Lic... Read More

Free Shipping (Continental US)

Have a Question?

Call Toll Free: 888-462-7828 Live Chat Email Us

Suggested Accessories

Description

The MA60 is an exciting new development from Cloud Electronics, combining for the first time the proven versatility of Cloud mixer-amplifiers in a single compact (2U, half-rack width) unit, and at a very competitive price point. The MA60 will find many applications in the Retail, Hospitality, Licensed Premises and other entertainment markets and is the most feature rich of the Utility Mixer/Amps on the market which also offers the best sound quality and the traditional Cloud reliable. Single Zone, 60w, 4Ω Output as Standard with Optional 50w, 70/100v Internal Transformer (CXL-50T)

Features

  • Four-input mixer-amplifier with integral 60w, 4Ω mono power amplifier
  • Optional 70/100v Internal Transformer (CXL-50T)
  • Gain trims on all inputs
  • Electronically-balanced mic input
  • 3.5 mm jack input (LINE 2) for MP3 player, laptop, etc.
  • Overall HF & LF EQ adjustment
  • Short-to-ground access connector or VOX-triggered paging on mic input
  • Selectable LINE 4 priority over other music inputs
  • Music Mute control input (NO or NC) for interface to emergency system
  • Compatible with standard Cloud remotes – RL-1 (music level) and RSL-4 (music level and source selection)
  • Electronically-balanced pre-amp output
  • Transformer-isolated auxiliary output with independent mic and music level control - for use with telephone MOH systems
  • Aux output source selection (internal jumper) – fixed source or follow main output
  • Dimensions (mm) - 213.0 wide x 88 high (2U) x 278 deep (+ connectors & knobs)
  • Optional Rack Kits (RE-S & RE-L)

More +

Product Specs

Line inputs
Frequency responseLow-Z output: +0 dB/-1 dB from 20 Hz – 20 kHz (65 Hz filter out)
100/70/50 V-line outputs (with CXL-60T transformer fitted): +0 dB/-3 dB from 20 Hz – 20 kHz (65 Hz filter switched out)
DistortionLow-Z output: <0.05% @ 1 kHz, 1 dB below full power (80 kHz bandwidth)
High voltage output: <0.05% @ 1 kHz, 1 dB below full power (80 kHz bandwidth)
Sensitivity195 mV (-12 dBu) to 2.0 V (+8 dBu)
Input Gain control20 dB range
Input impedance47k ohms
Headroom>20 dB
Noise-93 dB 22 Hz –22 kHz, at speaker output, relative to full power
Microphone Inputs
Frequency responseLow-Z output: -3 dB @ 100 Hz (3rd. order filter); -1 dB @ 20 kHz
High voltage output: -3 dB @ 100 Hz (3rd. order filter); -2 dB @ 20 kHz
Distortion<0.05% @ 1 kHz, 1 dB below full power (80 kHz bandwidth)
Gain range40 dB range
Input Impedance>2k ohms (balanced)
Phantom Power15 v, switchable per-input by jumpers
Headroom>20 dB
Noise-127 dB EIN 22 Hz - 22 kHz (150 W)
Outputs
Output Power60 watts @ 1 kHz & <0.07% THD+N Low impedance output
50 watts @ 1 kHz & <0.07% THD+N 50/70/100V line outputs (optional transformer fitted)
EqualisationHF: ±10 dB/5 kHz LF: ±10 dB/100 Hz
ProtectionDynamic level signal limiter max gain reduction of 20 dB, Thermal protection, IV limiting & short circuit protection, Switch on delay
Power input230 V, 115 V, 100 V versions available
Fuse rating230/120 V - T2A H
Fuse type20 mm x 5 mm
CoolingConvection cooled, vents top and bottom
Dimensions (mm)213.0 wide x 88 high (2U) x 278 deep (+ connectors & knobs)
Net weight (kg)4.65 kg (with CXL-60T transformer)
3.5 kg (without CXL-60T transformer)
