Description
INGENIA IG4T is a vertical 2-way speaker, equipped with four 6.5" woofers and one 1.4" compression driver exit (voice coil: 3"), controlled by a latest generation 900 W RMS DIGIPRO G3 amplifier. Combined XLR-TR-TRS audio signal input. It allows to use a balanced XLR connector, or a 1/4" TS or TRS jack input. Balanced "XLR" output, allowing to send the input audio signal to another amplified speaker.
Features:
- An accurate design of the horn, featuring an asymmetric directivity, specifically designed to provide excellent acoustic coverage, ensuring an uncompromising sound definition in different indoor and outdoor applications
- Digital steering controlled by the powerful internal DSP, with the use of 2 stacked speakers, allowing to combine wider coverage and greater sound power with uncompromising accuracy and clarity
- Immediate automatic detection of the 2-speaker configuration, thanks to the infra-red communication system installed on the handles (EPD technology) and to the fast, customizable, DSP-controlled management. In this configuration the OLED displays orientate automatically. Just operating the control section of one of the two speakers allows to drive the whole system
- An innovative shape, with the use of 2 woofers and 1 driver, in a cabinet combining ruggedness, sound performances, compactness and easy handling
- Extreme versatility, allowing to quickly and easily save and recall one's settings, protecting them with a settable password
| Type | Vertical 2 Way Speaker |
| Frequency Response [-10dB] | 74 - 20.000 Hz |
| Frequency Response [-6dB] | 88 - 19200 Hz |
| Max SPL | 132 dB |
| RMS Amplification Power | 900 W |
| Peak Power | 1800 W |
| Interface | Push rotary encoder + OLED display |
| Internal Controller | DSP 56 bit |
| A/D D/A Converter | 24 bit/48 kHz |
| Settings | Factory settings and customisable settings that can be saved and recalled |
| Limiter | Peak, RMS, Thermal |
| Inputs | 1x Combo (XLR/Jack) balanced/unbalanced |
| Outputs | 1x XLR link OUT |
| USB | Mini US, B type |
| Ready for Fly-Bar | Yes |
| Handles | 1 upper / 1 lower with IR interface |
| Installation on Pole | Yes, 36 mm |
| Dimensions (W x H x D) | 7.68 x 21.1 x 10.67 inches |
| Weight | 40 lbs |
INGENIA IG4T is a vertical 2-way speaker, equipped with four 6.5" woofers and one 1.4" compression driver exit (voice coil: 3"), controlled by a latest generation 900 W RMS DIGIPRO G3 amplifier. Combined XLR-TR-TRS audio signal input. It allows to use a balanced XLR connector, or a 1/4" TS or TRS jack input. Balanced "XLR" output, allowing to send the input audio signal to another amplified speaker.
Features:
- An accurate design of the horn, featuring an asymmetric directivity, specifically designed to provide excellent acoustic coverage, ensuring an uncompromising sound definition in different indoor and outdoor applications
- Digital steering controlled by the powerful internal DSP, with the use of 2 stacked speakers, allowing to combine wider coverage and greater sound power with uncompromising accuracy and clarity
- Immediate automatic detection of the 2-speaker configuration, thanks to the infra-red communication system installed on the handles (EPD technology) and to the fast, customizable, DSP-controlled management. In this configuration the OLED displays orientate automatically. Just operating the control section of one of the two speakers allows to drive the whole system
- An innovative shape, with the use of 2 woofers and 1 driver, in a cabinet combining ruggedness, sound performances, compactness and easy handling
- Extreme versatility, allowing to quickly and easily save and recall one's settings, protecting them with a settable password
| Type | Vertical 2 Way Speaker |
| Frequency Response [-10dB] | 74 - 20.000 Hz |
| Frequency Response [-6dB] | 88 - 19200 Hz |
| Max SPL | 132 dB |
| RMS Amplification Power | 900 W |
| Peak Power | 1800 W |
| Interface | Push rotary encoder + OLED display |
| Internal Controller | DSP 56 bit |
| A/D D/A Converter | 24 bit/48 kHz |
| Settings | Factory settings and customisable settings that can be saved and recalled |
| Limiter | Peak, RMS, Thermal |
| Inputs | 1x Combo (XLR/Jack) balanced/unbalanced |
| Outputs | 1x XLR link OUT |
| USB | Mini US, B type |
| Ready for Fly-Bar | Yes |
| Handles | 1 upper / 1 lower with IR interface |
| Installation on Pole | Yes, 36 mm |
| Dimensions (W x H x D) | 7.68 x 21.1 x 10.67 inches |
| Weight | 40 lbs |
