Electro-Voice EVID PC6.2 - Premium Ceiling Speaker (White / Pair)
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The PC6.2 (6.5-inch two-way) is designed to be the most advanced ceiling speaker available today, with superior performance across every detail. Each self-contained unit features a dedicated compression driver for enhanced high-frequency performance and coverage control in comparison to current EVID ceiling speaker offerings. Simplified wiring and innovative new integrated mounting hardware allows for quicker installation into a wide range of ceiling cavities and construction formats.
The model adds increased power handling (100 W), higher output (113 dB / 114 dB), and wider coverage angles (120˚ / 105˚) to the user-friendly installation and low-profile looks that contractors expect from EVID products, complimenting the range as a new, high-end option. Ideal for retail spaces, restaurants, theater and stadium concourses, shopping malls, and a wide range of applications where premium-quality distributed audio is required.
Features:
- High-performance EV-engineered compression driver. Ultra-wide HF dispersion provides extremely even coverage through room.
- High-excursion woofer provides dramatic low-end frequency extension. Reinforced steel back can provides rigid enclosure to minimize acoustic loss.
- Four-point clamp mechanism and integrated mounting legs enable quick ceiling installation.
- Detachable pass-thru Phoenix-style signal connections simplify installation wiring. Tap selector with 8Ω / 70 V / 100 V operation.
- Fully reinforced ABS UL-rated baffle ensures long life. Fully compliant with EN 54 (pending), UL 1480, and 2043 standards.
| Frequency Range (-10 db) | 50 Hz Ð 20 kHz |
| Nominal Coverage (Conical) | 100¡ |
| Power Handling | 200 W Program, 100 W Pink Noise |
| Sensitivity (SPL 1 W/1 m) | 87 dB |
| Max Calculated SPL | 107 dB Avg, 113 dB Peak |
| Impedance | 10 ohms |
| LF Transducer | 165 mm (6.5 in) |
| HF Transducer | 35 mm Compression Driver |
| Transformer Taps | 70V: 60W, 30W, 15W, 7.5W, 8 ohm 100V: 60W, 30W, 15W, 8 ohm |
| Connectors | Removable locking 4-pin (Phoenix) 2.5 mm (12 AWG) max wire size |
| Enclosure | ABS Plastic (UL94V-O) Baffle, steel back can |
| Grille | Color matched steel grille with fabric |
| Dimensions (H x Dia) | 260 mm x 280 mm (10.2 in x 11.0 in) |
| Cutout Size | 248 mm (9.76 in) |
| Net Weight | 7.0 kg (15.4 lb) |
| Shipping Weight (pair) |
16.83 kg (37.1 lb) |
| Support Hardware | C Ring, Tile Bridge |
| Approvals | UL1480, 2043; CE |
The PC6.2 (6.5-inch two-way) is designed to be the most advanced ceiling speaker available today, with superior performance across every detail. Each self-contained unit features a dedicated compression driver for enhanced high-frequency performance and coverage control in comparison to current EVID ceiling speaker offerings. Simplified wiring and innovative new integrated mounting hardware allows for quicker installation into a wide range of ceiling cavities and construction formats.
The model adds increased power handling (100 W), higher output (113 dB / 114 dB), and wider coverage angles (120˚ / 105˚) to the user-friendly installation and low-profile looks that contractors expect from EVID products, complimenting the range as a new, high-end option. Ideal for retail spaces, restaurants, theater and stadium concourses, shopping malls, and a wide range of applications where premium-quality distributed audio is required.
Features:
- High-performance EV-engineered compression driver. Ultra-wide HF dispersion provides extremely even coverage through room.
- High-excursion woofer provides dramatic low-end frequency extension. Reinforced steel back can provides rigid enclosure to minimize acoustic loss.
- Four-point clamp mechanism and integrated mounting legs enable quick ceiling installation.
- Detachable pass-thru Phoenix-style signal connections simplify installation wiring. Tap selector with 8Ω / 70 V / 100 V operation.
- Fully reinforced ABS UL-rated baffle ensures long life. Fully compliant with EN 54 (pending), UL 1480, and 2043 standards.
| Frequency Range (-10 db) | 50 Hz Ð 20 kHz |
| Nominal Coverage (Conical) | 100¡ |
| Power Handling | 200 W Program, 100 W Pink Noise |
| Sensitivity (SPL 1 W/1 m) | 87 dB |
| Max Calculated SPL | 107 dB Avg, 113 dB Peak |
| Impedance | 10 ohms |
| LF Transducer | 165 mm (6.5 in) |
| HF Transducer | 35 mm Compression Driver |
| Transformer Taps | 70V: 60W, 30W, 15W, 7.5W, 8 ohm 100V: 60W, 30W, 15W, 8 ohm |
| Connectors | Removable locking 4-pin (Phoenix) 2.5 mm (12 AWG) max wire size |
| Enclosure | ABS Plastic (UL94V-O) Baffle, steel back can |
| Grille | Color matched steel grille with fabric |
| Dimensions (H x Dia) | 260 mm x 280 mm (10.2 in x 11.0 in) |
| Cutout Size | 248 mm (9.76 in) |
| Net Weight | 7.0 kg (15.4 lb) |
| Shipping Weight (pair) |
16.83 kg (37.1 lb) |
| Support Hardware | C Ring, Tile Bridge |
| Approvals | UL1480, 2043; CE |
