Electro-Voice X2-212/120 - High-Performance Compact 12-Inch Verical Line Array Loudspeaker
Contact us
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The high-performance X2-212/120 is two-way vertical line-array loudspeaker element providing 120-degree horizontal coverage, expanding the flexibility of the X-Line Advance family.
It is ideal for use as a wide-coverage system for live sound using all 120-degree elements, or as the near-field element in a combined line array positioned below 90-degree elements, bi-amplified only.
The X-Line Advance family is designed for a wide variety of applications where wide bandwidth, vertical and horizontal directivity control, and high efficiency are required in a compact, cost-effective package.
Features:
- Integrated Rigging System - (IRS)
- Mid-Band Hydra Line Source Technology - (MBH)
- Pin Diffraction Hydra - (PDH)
- Proprietary Electro-Voice FIR-Drive settings
- Compatible with all grids and dollies currently available for 90-degree versions
- New IRIS-Net speaker settings, EASE files, EDS documents, and LAPS 3.3 are available
| Freq. Response (-3 dB) |
52 Hz - 19 kHz1 |
| Horizontial Coverage | 120¡ |
| Vertical Coverage | Array dependent |
| Recommended High-Pass Freq. |
50 Hz |
| Max Calculated SPL | 145 db Peak2 |
| Configuration | Bi-amp |
| LF Transducer | DVN3125, 12-in (305 mm) driver |
| LF Axial Sensitivity | 101 db (1 W/1 m)4 |
| LF Power Handling | 500 W Continuous, 2000 W Peak |
| LF Impedance | 8 ? (nominal), 6.1 ? (min) |
| HF Transducer | 2 x ND6A, 3-in (76.2 mm) diaphragm compression driver |
| HF Axial Sensitivity | 111 db (1 W/1 m)4 |
| HF Power Handling | 150 W Continuous, 600 W Peak3 |
| HF Impedance | 8 ? (nominal), 6.0 ? (min) |
| Connectors | Dual NL8 type connector |
| Enclosure | 13-ply weather resistant plywood with EVCoat |
| Grille | 16 GA powder coated galvanneal |
| Suspension | IRS Ñ Integrated Rigging System |
| Dimensions (H x W x D) | 13.5 in x 28.77 in x 12.04 in (342.9 mm x 730.8 mm x 534.4 mm) |
| Net Weight | 93 lb (42.2 kg) |
| Shipping Weight | 107 lb (48.5 kg) |
The high-performance X2-212/120 is two-way vertical line-array loudspeaker element providing 120-degree horizontal coverage, expanding the flexibility of the X-Line Advance family.
It is ideal for use as a wide-coverage system for live sound using all 120-degree elements, or as the near-field element in a combined line array positioned below 90-degree elements, bi-amplified only.
The X-Line Advance family is designed for a wide variety of applications where wide bandwidth, vertical and horizontal directivity control, and high efficiency are required in a compact, cost-effective package.
Features:
- Integrated Rigging System - (IRS)
- Mid-Band Hydra Line Source Technology - (MBH)
- Pin Diffraction Hydra - (PDH)
- Proprietary Electro-Voice FIR-Drive settings
- Compatible with all grids and dollies currently available for 90-degree versions
- New IRIS-Net speaker settings, EASE files, EDS documents, and LAPS 3.3 are available
| Freq. Response (-3 dB) |
52 Hz - 19 kHz1 |
| Horizontial Coverage | 120¡ |
| Vertical Coverage | Array dependent |
| Recommended High-Pass Freq. |
50 Hz |
| Max Calculated SPL | 145 db Peak2 |
| Configuration | Bi-amp |
| LF Transducer | DVN3125, 12-in (305 mm) driver |
| LF Axial Sensitivity | 101 db (1 W/1 m)4 |
| LF Power Handling | 500 W Continuous, 2000 W Peak |
| LF Impedance | 8 ? (nominal), 6.1 ? (min) |
| HF Transducer | 2 x ND6A, 3-in (76.2 mm) diaphragm compression driver |
| HF Axial Sensitivity | 111 db (1 W/1 m)4 |
| HF Power Handling | 150 W Continuous, 600 W Peak3 |
| HF Impedance | 8 ? (nominal), 6.0 ? (min) |
| Connectors | Dual NL8 type connector |
| Enclosure | 13-ply weather resistant plywood with EVCoat |
| Grille | 16 GA powder coated galvanneal |
| Suspension | IRS Ñ Integrated Rigging System |
| Dimensions (H x W x D) | 13.5 in x 28.77 in x 12.04 in (342.9 mm x 730.8 mm x 534.4 mm) |
| Net Weight | 93 lb (42.2 kg) |
| Shipping Weight | 107 lb (48.5 kg) |
