Description
The Marantz AVS is an all-in-one broadcast system that offers the live streamer professional components in a compact, free-standing array.
The AVS features a full HD webcam compatible with H.264 video compression, a high-quality 48kHz/16-bit USB condenser boundary microphone conveniently integrated into the base of the unit, and an LED light ring, daylight-balanced, with both cool and warm filter accessories for the look of a studio production. The Marantz AVS is a unique, all-in-one broadcast tool that is designed for live-streaming, video calling and gaming applications. It is compact and simple, perfect on a desktop, and the lightweight design makes it portable enough to take on location.
To make the system truly self-contained and capable of handling any streaming/podcast task without the need for additional equipment, the AVS has a high-speed USB-C computer output for low latency and an internal USB hub. There is even an onboard headphone amplifier so audio monitoring is simple. Everything the demanding streaming/broadcasting enthusiast needs is right here, in one convenient, high-performance package.
Features:
- All-in-one, freestanding broadcasting system
- Full HD webcam with H.264 video compression
- High-quality USB condenser boundary microphone (48kHz/16-bit) built into base
- Dimmable LED light ring / daylight-balanced with cool, warm and diffusion filter accessories
- USB-C output to computer for high-speed, low-latency
- Internal USB hub
- Headphone amplifier
Camera | Fixed-focus CMOS Sensor |
Diagonal field of view | 70 ¡ |
Optical resolution | 2MP native |
Resolution | Full HD 1080p video (up to 1920 x 1080 pixels) recording |
Frame rate | 30 fps/1080p, 30 fps/720p H.264 video compression |
Controls | ON/OFF switch Automatic low-light and white balance correction |
Operating Systems | Compatible with Windows¨ XP, 7, 8, 10, Mac OS X, LINUX, Android Operates in USB Video Device Class (UVC) mode USB 2.0 Ð Class 2 Compliant Driver |
Boundary Microphone | |
Element | Back electret condenser |
Polar pattern | Half-cardioid (cardioid in hemisphere above mounting surface) |
Open Circuit Sensitivity | -44dB ± 3dB (0db = 1V/Pa @ 1KHZ) |
Output impedance | 2.2 k½ ± 30% (@ 1kHz) |
Sample rate | 32 kHz / 44.1 kHz / 48 kHz @16-bit |
Frequency response | 150 Hz - 10 kHz |
Signal-to-Noise Ratio | >60 dB (1kHz @ 1% THD) |
Max SPL | 100 dB |
Controls | ON/OFF switch |
Headphone Amplifier | |
Frequency Response | 20 Hz Ð 20 kHz |
Output power | 130mW |
Output connector | 3.5mm stereo output |
Controls | Level control Mix control to mix microphone audio with USB audio input |
LED Light Ring | |
Type | 4" dimmable LED light ring |
LED complement | (30) wide-angle white LEDs @ 5600K |
(3) accessory filters | Diffused daylight Cool Warm |
USB | |
Type | USB 1 / 2: (2) Type A USB 3.0, 0.75A total available current between two ports for powering devices To PC: (1) USB-C connector / USB 3.0 connection |
USB Audio In | Class 2 compliant speaker device for audio to be monitored in headphone output Ð set by user in the computer |
Microphone Auxiliary Output | Fixed line-level output on 3.5mm TRS jack |
Dimensions | Height: 19.1" (485mm) Width: 7.39" (188mm) Depth: 6.26" (159mm) |
Weight | 2.29 lbs (1.04kg) |
Power | AC-DC power supply 100 ~ 240 VAC compatible 12 VDC @ 1 amp output |
The Marantz AVS is an all-in-one broadcast system that offers the live streamer professional components in a compact, free-standing array.
The AVS features a full HD webcam compatible with H.264 video compression, a high-quality 48kHz/16-bit USB condenser boundary microphone conveniently integrated into the base of the unit, and an LED light ring, daylight-balanced, with both cool and warm filter accessories for the look of a studio production. The Marantz AVS is a unique, all-in-one broadcast tool that is designed for live-streaming, video calling and gaming applications. It is compact and simple, perfect on a desktop, and the lightweight design makes it portable enough to take on location.
To make the system truly self-contained and capable of handling any streaming/podcast task without the need for additional equipment, the AVS has a high-speed USB-C computer output for low latency and an internal USB hub. There is even an onboard headphone amplifier so audio monitoring is simple. Everything the demanding streaming/broadcasting enthusiast needs is right here, in one convenient, high-performance package.
Features:
- All-in-one, freestanding broadcasting system
- Full HD webcam with H.264 video compression
- High-quality USB condenser boundary microphone (48kHz/16-bit) built into base
- Dimmable LED light ring / daylight-balanced with cool, warm and diffusion filter accessories
- USB-C output to computer for high-speed, low-latency
- Internal USB hub
- Headphone amplifier
Camera | Fixed-focus CMOS Sensor |
Diagonal field of view | 70 ¡ |
Optical resolution | 2MP native |
Resolution | Full HD 1080p video (up to 1920 x 1080 pixels) recording |
Frame rate | 30 fps/1080p, 30 fps/720p H.264 video compression |
Controls | ON/OFF switch Automatic low-light and white balance correction |
Operating Systems | Compatible with Windows¨ XP, 7, 8, 10, Mac OS X, LINUX, Android Operates in USB Video Device Class (UVC) mode USB 2.0 Ð Class 2 Compliant Driver |
Boundary Microphone | |
Element | Back electret condenser |
Polar pattern | Half-cardioid (cardioid in hemisphere above mounting surface) |
Open Circuit Sensitivity | -44dB ± 3dB (0db = 1V/Pa @ 1KHZ) |
Output impedance | 2.2 k½ ± 30% (@ 1kHz) |
Sample rate | 32 kHz / 44.1 kHz / 48 kHz @16-bit |
Frequency response | 150 Hz - 10 kHz |
Signal-to-Noise Ratio | >60 dB (1kHz @ 1% THD) |
Max SPL | 100 dB |
Controls | ON/OFF switch |
Headphone Amplifier | |
Frequency Response | 20 Hz Ð 20 kHz |
Output power | 130mW |
Output connector | 3.5mm stereo output |
Controls | Level control Mix control to mix microphone audio with USB audio input |
LED Light Ring | |
Type | 4" dimmable LED light ring |
LED complement | (30) wide-angle white LEDs @ 5600K |
(3) accessory filters | Diffused daylight Cool Warm |
USB | |
Type | USB 1 / 2: (2) Type A USB 3.0, 0.75A total available current between two ports for powering devices To PC: (1) USB-C connector / USB 3.0 connection |
USB Audio In | Class 2 compliant speaker device for audio to be monitored in headphone output Ð set by user in the computer |
Microphone Auxiliary Output | Fixed line-level output on 3.5mm TRS jack |
Dimensions | Height: 19.1" (485mm) Width: 7.39" (188mm) Depth: 6.26" (159mm) |
Weight | 2.29 lbs (1.04kg) |
Power | AC-DC power supply 100 ~ 240 VAC compatible 12 VDC @ 1 amp output |
