PreSonus Studio 24c - 2x2, 192 kHz, USB-C Audio Interface
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
Great for solo vocalists/rappers, mobile musicians, guitarists, podcasters, and live streaming, the Studio 24c 2x2 USB-C bus-powered audio interface for macOS® and Windows® can record at up to 192 kHz and features 2 front-panel combo mic/line/instrument inputs with PreSonus XMAX-L solid-state mic preamps; two rear-panel, balanced line outputs; and MIDI I/O. A Mixer knob blends analog input and computer playback for low-latency direct monitoring. A complete recording solution, the Studio 24c comes with PreSonus' award-winning Studio One® Artist recording software for macOS® and Windows®, and the Studio Magic Plug-in Suite. USB-C to USB-C and USB-C to USB-A cables are included for compatibility with most computers.
Features:
- USB-C bus-powered, 2x2 audio interface with MIDI for macOS® and Windows®
- 24-bit resolution; 44.1, 48, 88.2, 96, 176.4 and 192 kHz sampling rates
- 2 mic/instrument/line inputs with XMAX-L solid-state mic preamps
- +48V phantom power (global)
- 2 balanced 1/4" TRS main outputs with front-panel level control
- 4 ladder-style LED level meters (2 input, 2 main output)
- Stereo headphone output
- Mixer knob for low-latency direct input monitoring
- Kensington lock security hole
- Studio One® Artist and Studio Magic Plug-in Suite included
- USB-C to C and USB-C to A cables included
| Electronics | |
| Connectivity | USB-C¨ |
| Headphone Jack | 1/4" Stereo |
| Inputs | Two - Combo Mic/Instrument/Line Inputs (XLR Female Balanced, 1/4" TS Female Unbalanced (Inst) or TRS Female Balance (Line)) |
| Line Out | Two - 1/4" Balanced (Left and Right) |
| Phantom Power | +48 VDC, 10 mA |
| Voltage Requirements | 100-240 VAC, 50-60 Hz |
| Inputs | |
| Instrument Inputs Dynamic Range | 105 dB (A-Weighted, Unity Gain) |
| Instrument Inputs Frequency Response | 20 Hz Ð 20 kHz (±0.1 dBu, Unity Gain, Unweighted) |
| Instrument Inputs Gain Range | 50 dB |
| Instrument Inputs Maximum Level | +19 dBu (Minimum Gain) |
| Microphone Input Connection Type | Combo Locking XLR Mic - 1/4Ó TRS Line |
| Microphone Preamp Dynamic Range | 106 dB (A-Weighted, Minimum Gain) |
| Microphone Preamp Equivalent Input Noise | -126 dBu (A-Weighted, 150½, Maximum Gain) |
| Microphone Preamp Frequency Response | 20 Hz - 20 kHz (±0.3 dBu, Unity Gain, Unweighted) |
| Microphone Preamp Gain Control Range | 50 dB |
| Output | |
| Headphone Outputs Dynamic Range | 83 dB (A-Weighted, 56½ Load) |
| Headphone Outputs Frequency Response | 20 Hz Ð 20 kHz (±0.5 dBu, Unity Gain, Unweighted) |
| Headphone Outputs Impedance Working Range | 32½ to 300½ |
| Headphone Outputs Maximum Output | 47 mW/Channel @56½ |
| Headphone Outputs Total Harmonic Distortion | 0.01% (1 kHz, 0 dBFS, Loaded) |
| Line Outputs Connection Type | 1/4" TRS, Balanced |
| Main And Line Outputs Dynamic Range | 104 dB (Unity Gain, Unweighted) |
| Main And Line Outputs Frequency Response | 20 Hz - 20 kHz (±0.3 dBu, Unity Gain, Unweighted) |
| Main And Line Outputs Maximum Level | +10 dBu (1 kHz, Unity Gain, Balanced) |
| Main And Line Outputs Total Harmonic Distortion | 0.001% (1 kHz, -1 dBFS, Unity Gain) |
| Main Outputs Connection Type | 1/4" TRS, Balanced |
| Performance | |
| Digital Audio Bit Depth | 24 Bit |
| Digital Audio Dynamic Range | 108 dB |
| Measurements | |
| Product Depth | 5.5" (139.7 mm) |
| Product Height | 1.75" (44.45 mm) |
| Product Width | 7" (17.8 cm) |
| Miscellaneous | |
| Commodity Code | 8517.62.0090 |
| Power Cable | USB-C Cable - Bus Powered |
| Supported Sample Rates | 44.1, 48, 88.2, 96, 176.4, or 192 kHz (kHz) |
Great for solo vocalists/rappers, mobile musicians, guitarists, podcasters, and live streaming, the Studio 24c 2x2 USB-C bus-powered audio interface for macOS® and Windows® can record at up to 192 kHz and features 2 front-panel combo mic/line/instrument inputs with PreSonus XMAX-L solid-state mic preamps; two rear-panel, balanced line outputs; and MIDI I/O. A Mixer knob blends analog input and computer playback for low-latency direct monitoring. A complete recording solution, the Studio 24c comes with PreSonus' award-winning Studio One® Artist recording software for macOS® and Windows®, and the Studio Magic Plug-in Suite. USB-C to USB-C and USB-C to USB-A cables are included for compatibility with most computers.
Features:
- USB-C bus-powered, 2x2 audio interface with MIDI for macOS® and Windows®
- 24-bit resolution; 44.1, 48, 88.2, 96, 176.4 and 192 kHz sampling rates
- 2 mic/instrument/line inputs with XMAX-L solid-state mic preamps
- +48V phantom power (global)
- 2 balanced 1/4" TRS main outputs with front-panel level control
- 4 ladder-style LED level meters (2 input, 2 main output)
- Stereo headphone output
- Mixer knob for low-latency direct input monitoring
- Kensington lock security hole
- Studio One® Artist and Studio Magic Plug-in Suite included
- USB-C to C and USB-C to A cables included
| Electronics | |
| Connectivity | USB-C¨ |
| Headphone Jack | 1/4" Stereo |
| Inputs | Two - Combo Mic/Instrument/Line Inputs (XLR Female Balanced, 1/4" TS Female Unbalanced (Inst) or TRS Female Balance (Line)) |
| Line Out | Two - 1/4" Balanced (Left and Right) |
| Phantom Power | +48 VDC, 10 mA |
| Voltage Requirements | 100-240 VAC, 50-60 Hz |
| Inputs | |
| Instrument Inputs Dynamic Range | 105 dB (A-Weighted, Unity Gain) |
| Instrument Inputs Frequency Response | 20 Hz Ð 20 kHz (±0.1 dBu, Unity Gain, Unweighted) |
| Instrument Inputs Gain Range | 50 dB |
| Instrument Inputs Maximum Level | +19 dBu (Minimum Gain) |
| Microphone Input Connection Type | Combo Locking XLR Mic - 1/4Ó TRS Line |
| Microphone Preamp Dynamic Range | 106 dB (A-Weighted, Minimum Gain) |
| Microphone Preamp Equivalent Input Noise | -126 dBu (A-Weighted, 150½, Maximum Gain) |
| Microphone Preamp Frequency Response | 20 Hz - 20 kHz (±0.3 dBu, Unity Gain, Unweighted) |
| Microphone Preamp Gain Control Range | 50 dB |
| Output | |
| Headphone Outputs Dynamic Range | 83 dB (A-Weighted, 56½ Load) |
| Headphone Outputs Frequency Response | 20 Hz Ð 20 kHz (±0.5 dBu, Unity Gain, Unweighted) |
| Headphone Outputs Impedance Working Range | 32½ to 300½ |
| Headphone Outputs Maximum Output | 47 mW/Channel @56½ |
| Headphone Outputs Total Harmonic Distortion | 0.01% (1 kHz, 0 dBFS, Loaded) |
| Line Outputs Connection Type | 1/4" TRS, Balanced |
| Main And Line Outputs Dynamic Range | 104 dB (Unity Gain, Unweighted) |
| Main And Line Outputs Frequency Response | 20 Hz - 20 kHz (±0.3 dBu, Unity Gain, Unweighted) |
| Main And Line Outputs Maximum Level | +10 dBu (1 kHz, Unity Gain, Balanced) |
| Main And Line Outputs Total Harmonic Distortion | 0.001% (1 kHz, -1 dBFS, Unity Gain) |
| Main Outputs Connection Type | 1/4" TRS, Balanced |
| Performance | |
| Digital Audio Bit Depth | 24 Bit |
| Digital Audio Dynamic Range | 108 dB |
| Measurements | |
| Product Depth | 5.5" (139.7 mm) |
| Product Height | 1.75" (44.45 mm) |
| Product Width | 7" (17.8 cm) |
| Miscellaneous | |
| Commodity Code | 8517.62.0090 |
| Power Cable | USB-C Cable - Bus Powered |
| Supported Sample Rates | 44.1, 48, 88.2, 96, 176.4, or 192 kHz (kHz) |
