Shure A400MB - Mute Button Adapter for MicroFlex Series
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The Shure A400MB mute button accessory adds local or remote mute control via a programmable button for use with the Microflex MX395-LED low profile boundary microphones and MX400SMP-compatible modular gooseneck microphones (MX405/MX410/MX415). With an unobtrusive design ideal for surface mounting into boardroom tables, the A400MB adapter converts the 5-pin XLR output to a standard block connector for easy, no solder termination and hassle-free installation.
Features:
- Configurable as toggle, push-to-talk and push-to-mute functionality
- Onboard programmable switches configure logic settings, LED, and mute button behavior, including touch surface sensitivity
- Compatible with third-party control systems
- Included color rings to match black, aluminum or white finish microphones
- Easy table installation in 1 1/8" (30mm) hole
| Connector Type | 6-pin block connector |
| Power Requirements | Phantom Power |
| Power Consumption | 5 mW, maximum |
| Weight | 113 g (0.25 lbs) |
| Output Configuration | Active Balanced |
| Logic Connections | LED IN Active low (²1.0V), TTL compatible. Absolute maximum voltage: -0.7V to 50V. LOGIC-OUT Active low (²0.5V), sinks up to 20mA, TTL compatible. Absolute maximum voltage: -0.7V to 24V (up to 50V through 3k½). |
| Environmental Conditions | Operating Temperature 5 to 45 ¡C (41 to 113 ¡F) Storage Temperature -29 to 74 ¡C (-20.2 to 165 ¡F) Relative Humidity 0-95% |
| Dimensions | Base 3.74 x 3.74 x 1.06 in. (94.96 x 94.96 x 27.04 mm) H x W x D Mute Button 1.54 x 1.54 x 0.2 in. (39.02 x 39.02 x 5.02 mm) H x W x D Mute Button Tube 0.87 x 0.87 x 3.03 in. (22 x 22 x 76.98 mm) H x W x D Grommet 1.97 x 1.97 x 0.31 in. (49.97 x 49.97 x 8 mm) H x W x D Spacer 1.93 x 1.93 x 0.05 in. (49 x 49 x 1.2 mm) H x W x D |
| What's in the Box | Mute button Plug-on adapter Spacer Color rings (3) Assembly kit (90A48840): Flathead screwdriver Cable ties (2) Strain reliefs (2) Terminal plug |
The Shure A400MB mute button accessory adds local or remote mute control via a programmable button for use with the Microflex MX395-LED low profile boundary microphones and MX400SMP-compatible modular gooseneck microphones (MX405/MX410/MX415). With an unobtrusive design ideal for surface mounting into boardroom tables, the A400MB adapter converts the 5-pin XLR output to a standard block connector for easy, no solder termination and hassle-free installation.
Features:
- Configurable as toggle, push-to-talk and push-to-mute functionality
- Onboard programmable switches configure logic settings, LED, and mute button behavior, including touch surface sensitivity
- Compatible with third-party control systems
- Included color rings to match black, aluminum or white finish microphones
- Easy table installation in 1 1/8" (30mm) hole
| Connector Type | 6-pin block connector |
| Power Requirements | Phantom Power |
| Power Consumption | 5 mW, maximum |
| Weight | 113 g (0.25 lbs) |
| Output Configuration | Active Balanced |
| Logic Connections | LED IN Active low (²1.0V), TTL compatible. Absolute maximum voltage: -0.7V to 50V. LOGIC-OUT Active low (²0.5V), sinks up to 20mA, TTL compatible. Absolute maximum voltage: -0.7V to 24V (up to 50V through 3k½). |
| Environmental Conditions | Operating Temperature 5 to 45 ¡C (41 to 113 ¡F) Storage Temperature -29 to 74 ¡C (-20.2 to 165 ¡F) Relative Humidity 0-95% |
| Dimensions | Base 3.74 x 3.74 x 1.06 in. (94.96 x 94.96 x 27.04 mm) H x W x D Mute Button 1.54 x 1.54 x 0.2 in. (39.02 x 39.02 x 5.02 mm) H x W x D Mute Button Tube 0.87 x 0.87 x 3.03 in. (22 x 22 x 76.98 mm) H x W x D Grommet 1.97 x 1.97 x 0.31 in. (49.97 x 49.97 x 8 mm) H x W x D Spacer 1.93 x 1.93 x 0.05 in. (49 x 49 x 1.2 mm) H x W x D |
| What's in the Box | Mute button Plug-on adapter Spacer Color rings (3) Assembly kit (90A48840): Flathead screwdriver Cable ties (2) Strain reliefs (2) Terminal plug |
