Description
Quad-channel receiver with power and RF accessories included.
Dual and quad receiver options open the gateway to the full range of features, from high-performance RF and transparent digital audio to software control.
Features:
- Wide tuning range up to 184 MHz
- True digital diversity reception per channel for drop-out resistance
- Networked control with Wireless Workbench software and ShurePlus Channels app
- Optional DC module available to support redundant power
- Front panel headphone jack enables Dante Cue and Dante Browse monitoring
- ocking AC connectors
- 3Configurable Ethernet switch for redundant Dante digital output
- AES3 output
- Switchable XLR and AES3 outputs
- Channel Quality meter displays RF signal-to-noise
Axient® Digital makes everything perfectly clear.
Incorporating the most innovative wireless audio technology in the world, Axient Digital was engineered from the ground up for professional productions that demand flawless execution.
With an unprecedented level of signal stability and audio clarity, plus flexible hardware options, advanced connectivity, and comprehensive control, it's a wireless system built to take on the challenges of today-and tomorrow.
One System. Powerful Possibilities.
Both AD series and ADX series transmitters are compatible with a shared Axient Digital receiver platform. This scalable wireless system includes a groundbreaking micro-bodypack and provides incomparable sound for a wide range of applications and settings.
Reliability Is In The Air.
With outstanding signal quality in even the most complex, crowded environments, Axient Digital ensures maximum stability, range, and clarity for uncompromising audio you can trust - anywhere, every time.
-
Next-Gen Digital Radio
A high-performance modulation scheme provides maximum signal stability. -
Wide Tuning
Up to 184 MHz across all receivers and transmitters for broad strategic spectrum coverage. -
Spectral Efficiency
A robust High Density mode dramatically increases system channel count. -
Frequency Diversity
Two identical signals transmit on independent frequencies, with one taking over automatically should the other degrade.
The Sound Of Quality.
Axient Digital defies limitations for both RF and audio quality. With industry-leading low latency, transparent frequency response, and wide dynamic range, Axient Digital lets nothing get in the way of true, pure sound. No matter the setting, you'll hear Shure audio quality you can count on.
See Through The Noise.
ShowLink® remote control, Shure Wireless Workbench® software, the ShurePlus™ Channels app, and networked battery monitoring provide unmatched control and insight for seamless performance.
-
ShowLink
Real-time remote control of ADX transmitter parameters so settings can be changed right from the control booth. -
Wireless Workbench
Robust control software with advanced RF spectrum and Timeline plotting, frequency coordination, and live monitoring. -
ShurePlus Channels
Convenient mobile monitoring and control for iOS devices. -
Networked Charging
Smart batteries and chargers provide remote monitoring of critical parameters.
Right Sized Receiver Options.
Dual and quad receiver options open the gateway to the full range of features, from high-performance RF and transparent digital audio to software control. With Quadversity™, the AD4Q can assign four antennas to a single channel for greater coverage and signal quality.
Dimensions | 44 mm _ 483 mm _ 333 mm (1.7 in. _ 19.0 in. _ 13.1 in.), H _ W _ D |
Weight | 4.8 kg (10.6 lbs), without antennas |
Housing | Steel; Extruded aluminum |
Power Requirements | 100 to 240 V AC, 50Ð60 Hz; 0.68 A max |
Thermal Dissipation | Maximum: 31 W (106 BTU/hr) Idle: 21 W (72 BTU/hr) |
Audio Output | |
Gain Adjustment Range | Ð18 to +42 dB in 1 dB steps (plus Mute setting) |
Configuration | 1/4" (6.35 mm): Transformer-coupled Balanced (Tip=audio, Ring=no audio, Sleeve=ground) XLR: Transformer-coupled Balanced (1=ground, 2=audio +, 3=audio -) |
Impedance | Typical, XLR Line out 100½ |
Full Scale Output 200 k½ load |
1/4" (6.35 mm): +8 dBV XLR: LINE setting= +18 dBV, MIC setting= Ð12 dBV |
Mic/Line Switch | 30 dB pad |
Phantom Power Protection | Yes |
Networking | |
Network Interface | 10/100 Mbps, 1 Gbps, Dante Digital Audio |
Network Addressing Capability | DHCP or Manual IP address |
Maximum Ethernet Cable Length | 100 m (328 ft) |
Cascade output | |
Connector Type | BNC Note: For connection of one additional receiver in the same band |
Configuration | Unbalanced, passive |
Impedance | 50 ½ |
Insertion Loss | 0 dB, typical |
RF Input | |
Spurious Rejection | >80 dB, typical |
Connector Type | BNC |
Impedance | 50 ½ |
Bias Voltage | 12Ð13.5 V DC, 150 mA maximum, per antenna, switchable on/off |
RF Carrier Frequency Range | AD4Q=A: 470Ð636 MHz AD4Q=B: 606Ð810 MHz AD4Q=C: 750Ð960 MHz |
