Shure MX180/N Microflex Lavalier Microphone Housing with Preamp (for Microflex Capsules)


  • Dale #:

    SHUR-MX180N
  • Availability:

    Not in Stock - Reserve Yours
  • This item is not in stock and needs to be ordered from the manufacturer. Your payment will be charged after completing checkout. We will strive to ship as soon as possible, pending availability.

Description

Microflex® Lavalier microphones bring a new level of sophistication to personal voice reproduction. Like all Microflex family microphones, the Lavaliers use Shure's interchangeable condenser cartridges, available in cardioid, supercardioid or omnidirectional polar patterns. That means you can be ... Read More

Free Shipping (Continental US)

Have a Question?

Call Toll Free: 888-462-7828 Live Chat Email Us

Suggested Accessories

Description

Microflex® Lavalier microphones bring a new level of sophistication to personal voice reproduction. Like all Microflex family microphones, the Lavaliers use Shure's interchangeable condenser cartridges, available in cardioid, supercardioid or omnidirectional polar patterns. That means you can be sure there is a Microflex Lavalier that's right for your application. Compatible with all Shure wireless bodypack transmitters, their high sensitivity and wide frequency response guarantee great sound.

Features

  • Wide dynamic range and frequency response for accurate sound reproduction across the audio spectrum
  • Interchangeable cartridges that provide an optimal choice for each application
  • Rotatable tie-clip that pivots in 90 degree increments for placement flexibility
  • Supplied snap-fit foam windscreen that controls breath noise and stays on securely
  • Balanced, transformerless output for increased immunity to noise over long cable runs
  • Supplied dual tie clip holds two microphones for dual miking applications

More +

Product Specs

TypeCondenser (electret bias)
Frequency Response50 to 17,000 Hz
Polar PatternMX183: Omnidirectional
MX184: Supercardioid
MX185: Cardioid
Output ImpedanceEIA rated at 150 ohms (180 ohms actual)
Open Circuit Sensitivity (at 1 kHz, ref. 1V/Pascal*)MX183: -27.5 dB (42.2 mV)
MX184: -33.5 dB (21.1 mV)
MX185: -35.0 dB (17.0 mV)
All settings -12 dB at 0 gain *1 Pascal = 94 dB SPL
Max SPL (1kHz at 1%THD, 1 k ohm load)MX183: 116.7 dB
MX184: 122.7 dB
MX185: 124.2 dB
All settings +6 dB at 0 gain
Equivalent Output Noise (A-weighted)MX183: 20.5 dB
MX184: 26.5 dB
MX185: 28.0 dB
Signal to Noise Ratio (referenced at 94 dB SPL)MX183: 73.5 dB
MX184: 67.5 dB
MX185: 66.0 dB
Dynamic Range at 1 k ohm load96.2 dB
100 dB at 0 gain
Power Requirements11 to 52 Vdc phantom, 2.0 mA
Common Mode Rejection45.0 dB minimum
PolarityPositive sound pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector.
Environmental ConditionsOperating Temperature Range: -18 to 57 degrees C (0 to 135 degrees F)
Storage Temperature Range: -29 to 74 degrees C (-20 to 165 degrees F)
CableShielded 1.2 meter (4 ft.) cable terminated with a 4-Pin Female Mini Connector (TA4F)
