Shure P3T Transmitter for PSM300 Systems (J13 Band - 566-590 MHz)



Have a Question? Call Toll Free: 888-462-7828

Live Chat Email Us
Dale #:SHUR-P3TJ13

Availability: Usually ships in 5 - 10 Days

This item usually ships within 5-10 days after your order is placed. Your payment will be charged after completing checkout.
Free Shipping (Continental US)
  • Dependable wireless transmission and 24-bit digital audio combine to deliver a superior personal monitoring mix for every performance. Send 2 channels of audio to a bodypack receiver up to 300 feet (90 m) away, with patented Audio Reference Companding to ensure transparent sound quality with no artifacts or dropouts.

    Features:

    • Transmitter sends a stereo or mono mix wirelessly to performers onstage
    • One-touch IR sync on user-friendly front-panel controls instantly links transmitter to receiver
    • Rear-panel 1/4" (6.3 mm) TRS balanced inputs and loop outputs provide versatile connectivity to audio sources and other P3T units
    • Up to 30 mW output power (regionally dependent)
    • High-contrast LCD screen with left / right audio output meters
    • Selectable line / aux level

    PSM300 Stereo Personal Monitor Systems deliver reliable wireless freedom to every corner of the stage. Patented Audio Reference Companding ensures the clearest sound, with ultra-low noise and no artifacts. Easy to setup and operate, PSM 300 systems offer one-touch frequency scan and sync to find and assign a clean wireless channel. Adjust the volume and use MixMode technology or stereo mode to create a personal mix from two channels of audio.

  • RF Output Power 10, 20, 30 mW
    Note: varies by region
    RF Output Impedance 50 (typical)
    Net Weight 783 g (27.6oz.)
    Dimensions 43 × 198 × 172 mm (1.7 × 7.8 × 6.8 in.), H × W × D
    Power Requirements 12–15 V DC, 260 mA maximum
    Audio Input
    Connector Type 6.35 mm (1/4") TRS
    Polarity Tip positive with respect to ring
    Configuration Electronically balanced
    Impedance 40 k (actual)
    Nominal Input Level Switchable, +4 dBu, -10 dBV
    Maximum Input Level +4 dBu: +22 dBu
    -10 dBV: +12.2 dBu
    Pin Assignments Tip=hot, Ring=cold, Sleeve=ground
    Phantom Power Protection Up to 60 V DC
    Audio Output
    Connector Types 6.35 mm (1/4") TRS
    Configuration Electronically balanced
    Impedance Connected directly to inputs
