Shure UA834V Inline Remote Antenna Amplifier (174-216 MHz)
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
In-line antenna amplifier for remote mounting (174–216 MHz).
The UA834 provides more flexibility in wireless installations by increasing the allowable length of cable runs between a receiver and antenna. Antennas may be placed closer to the stage, or installed on ceilings and walls that maintain a better line of sight with the transmitter.
Features:
- Two-position gain selector switch +6 and +12 dB
- Overload LED indication
- Low-noise signal amplifier compensates for insertion loss in coaxial cable
- Compatible with Shure Wireless Systems. Also may be used with Shure UA845 and UA844 Antenna Distribution Systems
- Integrated threaded adapter mounts easily to microphone stands or the supplied surface-mount bracket
- Shure quality, ruggedness, and reliability
| Connector Type | BNC, Female |
| Impedance | 50 ½ |
| Power Requirements | 10 to 15 V DC bias from coaxial connection, 0.60Ð0.72 W |
| Signal Gain | ±2 dB, Switchable +6 dB +12 dB |
| Absolute Maximum RF Input | +5 dBm |
| RF Overload LED Threshold | ±2 dB -5 dBm |
| Input Third-Order Intercept Point (IIP3) | >10 dBm |
| Housing | Cast Aluminum, black painted finish |
| Dimensions | 67 x 32 x 112 mm (H x W x D) Dimensions with Stand: 108 x 32 x 112 mm |
| Net Weight | Without Mounting Stand 0.28 kg (9.8 oz.) With Mounting Stand 0.42 kg (14.8 oz.) |
In-line antenna amplifier for remote mounting (174–216 MHz).
The UA834 provides more flexibility in wireless installations by increasing the allowable length of cable runs between a receiver and antenna. Antennas may be placed closer to the stage, or installed on ceilings and walls that maintain a better line of sight with the transmitter.
Features:
- Two-position gain selector switch +6 and +12 dB
- Overload LED indication
- Low-noise signal amplifier compensates for insertion loss in coaxial cable
- Compatible with Shure Wireless Systems. Also may be used with Shure UA845 and UA844 Antenna Distribution Systems
- Integrated threaded adapter mounts easily to microphone stands or the supplied surface-mount bracket
- Shure quality, ruggedness, and reliability
| Connector Type | BNC, Female |
| Impedance | 50 ½ |
| Power Requirements | 10 to 15 V DC bias from coaxial connection, 0.60Ð0.72 W |
| Signal Gain | ±2 dB, Switchable +6 dB +12 dB |
| Absolute Maximum RF Input | +5 dBm |
| RF Overload LED Threshold | ±2 dB -5 dBm |
| Input Third-Order Intercept Point (IIP3) | >10 dBm |
| Housing | Cast Aluminum, black painted finish |
| Dimensions | 67 x 32 x 112 mm (H x W x D) Dimensions with Stand: 108 x 32 x 112 mm |
| Net Weight | Without Mounting Stand 0.28 kg (9.8 oz.) With Mounting Stand 0.42 kg (14.8 oz.) |
