Sound Devices PowerStation-8M - Docking Station for Astral Mini Bodypacks
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The PowerStation-8M provides simultaneous battery charging, file transfer, and timecode jamming of up to eight Astral Minis or four Astral Minis fitted with the A20-BatteryDoubler accessory. Powered via DC (TA4) or USB-C (USB-PD).
-
Power
- USB-C: PD (Power Delivery), 36 W or higher, or
- TA-4: 10 – 18 VDC, 36 W or higher
- Pin-4 hot, pin-1 ground, pin-2 and pin-3 data for smart batteries. Leave pins-2 and pin-3 disconnected if not using smart batteries.
-
LTC Input
- Input impedance: 5k ohm
- Signal level: 0.3 – 5 Vp-p
-
USB-C
- USB 3.0 SuperSpeed, internal hub
-
Dimensions (HxWxD)
- 40 mm x 220 mm x 136 mm (without feet)
- 1.58 in x 8.66 in x 5.35 in (without feet)
-
Weight
- 670 g
- 1.5 lb
-
Included Accessories
- Power Supply
- 2x USB-C to USB-C Cables, USB 3.0
The PowerStation-8M provides simultaneous battery charging, file transfer, and timecode jamming of up to eight Astral Minis or four Astral Minis fitted with the A20-BatteryDoubler accessory. Powered via DC (TA4) or USB-C (USB-PD).
-
Power
- USB-C: PD (Power Delivery), 36 W or higher, or
- TA-4: 10 – 18 VDC, 36 W or higher
- Pin-4 hot, pin-1 ground, pin-2 and pin-3 data for smart batteries. Leave pins-2 and pin-3 disconnected if not using smart batteries.
-
LTC Input
- Input impedance: 5k ohm
- Signal level: 0.3 – 5 Vp-p
-
USB-C
- USB 3.0 SuperSpeed, internal hub
-
Dimensions (HxWxD)
- 40 mm x 220 mm x 136 mm (without feet)
- 1.58 in x 8.66 in x 5.35 in (without feet)
-
Weight
- 670 g
- 1.5 lb
-
Included Accessories
- Power Supply
- 2x USB-C to USB-C Cables, USB 3.0
