Stewart Audio AV30MX-2 Plenum Rated Subcompact Stereo Mixer Amplifier
Contact us
Availability:
Not in Stock - Reserve YoursThis item is not in stock and needs to be ordered from the manufacturer. Your payment will be charged after completing checkout. We will strive to ship as soon as possible, pending availability.
Description
Stewart Audio AV30MX-2 is a sub-compact 2 channel stereo amplifier. Provides 30 watts at 8ohm per channel. This amplifier is plenum rated for above-ceiling applications and uses Signal Sense Technology for Energy Star compliance. Features:
- Music and fire alarm muting
- Clean full-range dynamic power
- Signal Detect trigger for sleep & wake up
- 2 channel mixer built-in
- External inline power supply
The Stewart Audio sub compact AV30MX-2 is built to meet the rigorous demands of high quality commercial, industrial and Pro Audio sound installations. Low cost, lightweight and convection cooling make this Class D mixer amplifier flexible enough for a broad range of applications requiring quiet amplification. With an extremely compact form factor, the AV30MX-2 allows amplification to be located in places off limits to normal mixer amplifiers without compromising sound or power. Like all Stewart products, the AV30MX-2 is designed for sonic accuracy, high efficiency and extended duty cycles. Our Signal Sense Power Technology™ (SSPT ™) ensures the amplifier is only powered when there is a signal present, saving energy and extending product life.
| 4 Ohm Stereo Power | 30 Watts |
| 8 Ohm Stereo Power | 30 Watts |
| Frequency Response (+0, -3 dB, 1W) | 30Hz - 20kHz |
| Power Bandwidth (+3, -3 dB) | 30Hz - 30kHz |
| THD+N | less than .1% |
| Signal to noise ratio | greater than 100dB |
| External Mute | 5-12VDC |
| Slew Rate | 30V/microsecond |
| Input Sensitivity | .5V (-3 dBV) |
| Standard Voltage Gain | 28X (26.5dB) |
| Input Impedance (Unbalanced) | 10k |
| Standby, Idle Current Draw, 1/8 Power Draw | 0.005/0.01/0.15 Amps |
| Class | D |
| Input Connectors | 3.5 MM stereo, dual RCA |
| Output Connectors | Euro Block |
| Power Supply | External in-line 48VDC (Included) |
| Cooling | Convection-Cooling (No fans) |
| Controls | 2 Independent Level Controls |
| LED Indicators | Power, Signal Present, & Clip |
| Construction | Aluminum Chassis |
| Dimensions (H,W,D) | 1.25H x 4.35W x 3.2D |
| Weight | .37 lbs (0.16kg) |
| Warranty | 3 Years |
| Plenum Rating | UL 2043 Approved |
