Stewart Audio PA-50B Half Rack 100 Watt 2 Channel Power Amplifier
Contact us
Availability:
Not in Stock - Reserve YoursThis item is not in stock and needs to be ordered from the manufacturer. Your payment will be charged after completing checkout. We will strive to ship as soon as possible, pending availability.
Description
Stewart Audio's Half Rack PA Series Power Amplifiers are designed specifically for high quality Commercial, Industrial and Professional Audio sound installations. The PA Series was specifically designed to meet the rigorous requirements of Sonic Accuracy, High Efficiency, Low Power consumption and extended duty cycles in a very compact Half Rack Package.
Features- Compact Half Rack Package
- Two Channel Amplifier, optimized to drive 4 Ohm and 8 Ohm loads
- Convection Cooled (No Fans)
- Clean Full-Range Dynamic Power
- World Class Reliability
- Bridgeable
- Ultra Efficient Switch Mode Power Supply
- 3 Years Parts and Labor Warranty
| 8 Ohm Stereo Power | 25 Watts/Ch |
| 4Ohm Stereo Power | 50 Watts/Ch |
| Bridged Mono | 100W@8Ohm 100W@4Ohm |
| Freq. Response(+0, -.5dB,1W) | 20 Hz-20kHz |
| Bandwidth +/- | 3dB5Hz-100kHz |
| Signal to Noise | >100dB |
| THD+N | < .1% |
| Input Sensitivity | 1V (0 dBV) |
| Input Impedance (Bal/Unbal.) | 20k Ohms/10k Ohms |
| Slew Rate | >30V / microsecond |
| Damping Factor | >200 / 8 Ohm |
| Class | AB |
| Input Connectors | 1/4 TRS |
| Output Connectors | Terminal Strip |
| Power Supply | High Speed Switching |
| Cooling | Convection-Cooling (No Fans) |
| Controls | Pwr on/off, Channel Gain, stereo/Bridge |
| LED Indicators | Power Clip |
| Construction | Steel Aluminum Chassis |
| Operating Voltage | 120 VAC |
| Dimensions(h, w, d) | 1.7H x 8.5W x 6.2 D |
| Weight | 3.5 lbs (1.6kg) |
Stewart Audio's Half Rack PA Series Power Amplifiers are designed specifically for high quality Commercial, Industrial and Professional Audio sound installations. The PA Series was specifically designed to meet the rigorous requirements of Sonic Accuracy, High Efficiency, Low Power consumption and extended duty cycles in a very compact Half Rack Package.
Features- Compact Half Rack Package
- Two Channel Amplifier, optimized to drive 4 Ohm and 8 Ohm loads
- Convection Cooled (No Fans)
- Clean Full-Range Dynamic Power
- World Class Reliability
- Bridgeable
- Ultra Efficient Switch Mode Power Supply
- 3 Years Parts and Labor Warranty
| 8 Ohm Stereo Power | 25 Watts/Ch |
| 4Ohm Stereo Power | 50 Watts/Ch |
| Bridged Mono | 100W@8Ohm 100W@4Ohm |
| Freq. Response(+0, -.5dB,1W) | 20 Hz-20kHz |
| Bandwidth +/- | 3dB5Hz-100kHz |
| Signal to Noise | >100dB |
| THD+N | < .1% |
| Input Sensitivity | 1V (0 dBV) |
| Input Impedance (Bal/Unbal.) | 20k Ohms/10k Ohms |
| Slew Rate | >30V / microsecond |
| Damping Factor | >200 / 8 Ohm |
| Class | AB |
| Input Connectors | 1/4 TRS |
| Output Connectors | Terminal Strip |
| Power Supply | High Speed Switching |
| Cooling | Convection-Cooling (No Fans) |
| Controls | Pwr on/off, Channel Gain, stereo/Bridge |
| LED Indicators | Power Clip |
| Construction | Steel Aluminum Chassis |
| Operating Voltage | 120 VAC |
| Dimensions(h, w, d) | 1.7H x 8.5W x 6.2 D |
| Weight | 3.5 lbs (1.6kg) |
