Warm Audio EQP-WA Classic Style Tube Equalizer
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The EQP-WA is a re-creation of the most renown tube Equalizer in studio history, the Pultec EQP-1A. Not only does the look and feel of the EQP-WA match the classic Pultec units, but the sonic quality has been carefully considered by using top-end components such as CineMag transformers and premium tubes. This fully discrete Tube EQ can pull euphoric sonics from any track and bring a brilliance and luster to mixes that's nearly impossible to achieve inside-the-box. We are proud to have once again redefined the industry standard by bringing a fully professional-grade equalizer to the market at a price that's just as remarkable as the unit.
Features:
- Tube Equalizer based on the classic "Pultec" EQP-1A
- CineMag input and output transformers - Made in U.S.A.
- Premium high voltage 12AX7 and 12AU7 tubes
- CineMag inductor EQ section
- EQ section is bypassable - signal still passes through tubes and transformers for warming effect
- No insertion loss - loss restored by tube amplifier
| Connection | XLR and TRS transformer balanced inputs XLR and TRS transformer balanced outputs |
| Frequency Response | Flat frequency response from 20 Hz - 50 kHz |
| Controls | Boost and Cut controls can be used simultaneously for phase effect Low frequency boost - 20, 30, 60, 100, 200, 400, 800 Hz - 12 db Low frequency cut - 20, 30, 60, 100, 200, 400, 800 Hz - 18 db High frequency boost - 3, 4, 5, 8, 10, 12, 16 kHz - 18 db High frequency cut - 3, 4, 5, 10, 20 kHz - 14 db 5 added frequency points for greater flexibility |
| Power | Switchable 115/230 volt IEC power inlet |
| Dimensions | 19 x 3.5 x 6 inches - 2RU rack mountable |
The EQP-WA is a re-creation of the most renown tube Equalizer in studio history, the Pultec EQP-1A. Not only does the look and feel of the EQP-WA match the classic Pultec units, but the sonic quality has been carefully considered by using top-end components such as CineMag transformers and premium tubes. This fully discrete Tube EQ can pull euphoric sonics from any track and bring a brilliance and luster to mixes that's nearly impossible to achieve inside-the-box. We are proud to have once again redefined the industry standard by bringing a fully professional-grade equalizer to the market at a price that's just as remarkable as the unit.
Features:
- Tube Equalizer based on the classic "Pultec" EQP-1A
- CineMag input and output transformers - Made in U.S.A.
- Premium high voltage 12AX7 and 12AU7 tubes
- CineMag inductor EQ section
- EQ section is bypassable - signal still passes through tubes and transformers for warming effect
- No insertion loss - loss restored by tube amplifier
| Connection | XLR and TRS transformer balanced inputs XLR and TRS transformer balanced outputs |
| Frequency Response | Flat frequency response from 20 Hz - 50 kHz |
| Controls | Boost and Cut controls can be used simultaneously for phase effect Low frequency boost - 20, 30, 60, 100, 200, 400, 800 Hz - 12 db Low frequency cut - 20, 30, 60, 100, 200, 400, 800 Hz - 18 db High frequency boost - 3, 4, 5, 8, 10, 12, 16 kHz - 18 db High frequency cut - 3, 4, 5, 10, 20 kHz - 14 db 5 added frequency points for greater flexibility |
| Power | Switchable 115/230 volt IEC power inlet |
| Dimensions | 19 x 3.5 x 6 inches - 2RU rack mountable |
