Description
Favorites with discerning contractors and engineers, these speakers feature Uni-Phase design and matching sound - even between different models - for easy system setup and tuning. Features: 12" and 15" woofer models available. Three horn dispersion patterns available for each model: 60º ... Read MoreSuggested Accessories
Description
Favorites with discerning contractors and engineers, these speakers feature Uni-Phase design and matching sound - even between different models - for easy system setup and tuning.
Features:
The Quest for the Best in Pro Sound
Yamaha's new Installation Series Speakers address a number of important issues that give them unprecedented performance and handling characteristics for live sound applications, including permanent installations. In particular, phase characteristics have been kept smooth and consistent throughout the entire series, so you can mix and match speakers to suit any system and venue without ending up with hot and dead spots due to phase interference. And of course sonic quality is superb throughout the entire reproduction range so the full impact of the source material reaches the audience undiluted.
This approach to design is evident in every Yamaha Commercial Audio product. The proof is in the enormous success of the groundbreaking PM1D and PM5D digital consoles, digital signal processing products, and industry-standard analog live consoles and related gear. Yamaha is simply dedicated to delivering the best sonic performance available anywhere, at any price, from system input to output. The Installation Series breaks new ground once again with performance and convenience that can take the sound at any venue to a higher level.
More +
Product Specs
Speaker type | High power 2-way full-range speaker | |
Frequency range (-10dB) | 45Hz-20kHz (Bi-amp mode) | |
Frequency response (-3dB) | 55Hz-20kHz (Bi-amp mode) | |
Nominal coverage | H | 90 or 50 |
V | 50 or 90 | |
Components | LF | 15" (38cm) woofer, 4" (100mm) voice coil |
HF | Rotatable constant directivity horn, 1.4" (36mm) exit, 3" (76mm) voice coil compression driver | |
Drive mode options (*default) | Passive* / Bi-amp | |
Power rating | NOISE | 600W (IEC, 2h) |
PGM | 1200W | |
PEAK | 2400W | |
Nominal impedance | 8ohms | |
SPL | Sensitivity (1W; 1m on axis) | 97dB SPL |
Continuous (Calculated) | 125dB SPL | |
Peak (Calculated) | 131dB SPL | |
I/O connectors | 1x Neutrik NL4 and barrier strip, wired in parallel | |
Shape | 30 degrees trapezoidal | |
Cabinet material | 5/8" (16mm), 11-ply Finnish birch | |
Finish | Textured black | |
Handle | 2 | |
Flying and mounting hardware | 15x M10 for shoulder eyebolts and U-bracket; 4x M8 for 3rd party speaker mount hardware | |
Dimensions | W | 448mm; 17-5/8in |
H | 770mm; 30-3/8in | |
D | 534mm; 21in | |
Net weight | 39kg; 86lbs | |
Pole socket | - |
