Yamaha Unified Communications RM-CG - Ceiling Mount Microphone Array with Dante (Black)
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
Yamaha's Dante-enabled ceiling-mount microphone array is designed with innovative technologies to optimize collaboration in a variety of spaces. The unique dynamic beam tracking technology utilizes four beams to automatically track voices within the room simultaneously, allowing for lively conversations to be picked up and delivered clearly to the far end. Create a "touchless" and easy-to-use hybrid meeting or learning space with this highly intelligent microphone! Available in black or white.
Features:
- Dante Enabled
- Remote Monitoring
- Real-time DSP customization and audio routing
- PoE+ network cable connection
- Web UI configuration
- Sound tech within the mic
No Fixed Lobes
Dynamic beamforming technology eliminates the need to program fixed lobes which can often lead to dead spots within the meeting space. Design changes or room set up flexibility can also be done without the need to reprogram lobes.
Yamaha Technologies
Technologies within the microphone like Adaptive Echo Cancellation, Automatic Gain Control, Noise Reduction and Dereverberation help create the best-quality audio pickup.
3 mounting options
The ceiling microphone array supports ceiling mount, wire mount or pole mount options.
PoE+
Utilizes one PoE+ network cable connection avoiding troublesome wiring and enabling audio control via Dante
| NETWORK SPECIFICATIONS | |
| Ether1 | Dante Audio/Dante Control, Remote Control, WebUI, PoE |
| Cable requirements | Cat 5e or higher (STP Recommended) |
| AUDIO SPECIFICATIONS | |
| Frequency response | 160Hz Ð 16kHz(-10dB) |
| Sampling Rate | 48kHz |
| Bit depth | 24bit |
| Latency | 58 [ms] (including signal processing) |
| Audio I/O Dante | 1in x 2out In1=AEC reference signal/Out1=output of beam mix, Out2= output of beam mix simple processed |
| Maximum input level of SPL 0dB | 117.8 dB SPL |
| Self Noise | -0.8 dBA SPL |
| SNR Ref. 94 dB SPL at 1 kHz | 94.8 dBA |
| Sensitivity | -23.8 dBFS/Pa |
| Dynamic Range | 118.6 dBA |
| Signal Processing | Multi beam tracking, Adaptive Echo Canceler_Noise Reduction, Dereverberation_Auto Mixer, Auto Gain Control_Parametric EQ_Output Gain |
| GENERAL | |
| Description | Ceiling Microphone |
| Color | Black, White |
| Dimensions (WxDxH) | W560_D560mm_H90mm (including protrusions/microphone panel: H22mm) |
| Weight | 5.6kg |
| Power requirements | PoE(IEEE 802.3af), DC 48V |
| Maximum Power Consumption | 7.2 W |
| In Operation | Temperature 0__40_ Humidity 30%_90% (No condensation) |
| Storage | Temperature -20__60_ Humidity 20%_90% (No condensation) |
| Indicator | Front Indicator (Mute/Unmute / Status) _Network Port Indicator |
| Mount | Ceiling Mount (*canÕt replace a grid ceiling panel.) Wire hanging VESA mount |
| Max device number with RM-CR | 2 (Connection with other than RM-CR is not limited to this device) |
| Accessories | Construction description, (Guarantee), grillex1, screws for grille (M3x8mm)x5(*), screw coverx4, cutting template x1, Cringx1, screws for C ring x2, hanger anglex1, screws for hanger angle(M4x20mm)x5(*), terminal coverx1, safety wire x1,binding bandx1, clamp platex2 (*)including a spare respectively |
| Dust Protection | IP5X for dust protection (with junction cover) |
| Plenum Rating | UL2043 (with junction cover) |
Yamaha's Dante-enabled ceiling-mount microphone array is designed with innovative technologies to optimize collaboration in a variety of spaces. The unique dynamic beam tracking technology utilizes four beams to automatically track voices within the room simultaneously, allowing for lively conversations to be picked up and delivered clearly to the far end. Create a "touchless" and easy-to-use hybrid meeting or learning space with this highly intelligent microphone! Available in black or white.
Features:
- Dante Enabled
- Remote Monitoring
- Real-time DSP customization and audio routing
- PoE+ network cable connection
- Web UI configuration
- Sound tech within the mic
No Fixed Lobes
Dynamic beamforming technology eliminates the need to program fixed lobes which can often lead to dead spots within the meeting space. Design changes or room set up flexibility can also be done without the need to reprogram lobes.
Yamaha Technologies
Technologies within the microphone like Adaptive Echo Cancellation, Automatic Gain Control, Noise Reduction and Dereverberation help create the best-quality audio pickup.
3 mounting options
The ceiling microphone array supports ceiling mount, wire mount or pole mount options.
PoE+
Utilizes one PoE+ network cable connection avoiding troublesome wiring and enabling audio control via Dante
| NETWORK SPECIFICATIONS | |
| Ether1 | Dante Audio/Dante Control, Remote Control, WebUI, PoE |
| Cable requirements | Cat 5e or higher (STP Recommended) |
| AUDIO SPECIFICATIONS | |
| Frequency response | 160Hz Ð 16kHz(-10dB) |
| Sampling Rate | 48kHz |
| Bit depth | 24bit |
| Latency | 58 [ms] (including signal processing) |
| Audio I/O Dante | 1in x 2out In1=AEC reference signal/Out1=output of beam mix, Out2= output of beam mix simple processed |
| Maximum input level of SPL 0dB | 117.8 dB SPL |
| Self Noise | -0.8 dBA SPL |
| SNR Ref. 94 dB SPL at 1 kHz | 94.8 dBA |
| Sensitivity | -23.8 dBFS/Pa |
| Dynamic Range | 118.6 dBA |
| Signal Processing | Multi beam tracking, Adaptive Echo Canceler_Noise Reduction, Dereverberation_Auto Mixer, Auto Gain Control_Parametric EQ_Output Gain |
| GENERAL | |
| Description | Ceiling Microphone |
| Color | Black, White |
| Dimensions (WxDxH) | W560_D560mm_H90mm (including protrusions/microphone panel: H22mm) |
| Weight | 5.6kg |
| Power requirements | PoE(IEEE 802.3af), DC 48V |
| Maximum Power Consumption | 7.2 W |
| In Operation | Temperature 0__40_ Humidity 30%_90% (No condensation) |
| Storage | Temperature -20__60_ Humidity 20%_90% (No condensation) |
| Indicator | Front Indicator (Mute/Unmute / Status) _Network Port Indicator |
| Mount | Ceiling Mount (*canÕt replace a grid ceiling panel.) Wire hanging VESA mount |
| Max device number with RM-CR | 2 (Connection with other than RM-CR is not limited to this device) |
| Accessories | Construction description, (Guarantee), grillex1, screws for grille (M3x8mm)x5(*), screw coverx4, cutting template x1, Cringx1, screws for C ring x2, hanger anglex1, screws for hanger angle(M4x20mm)x5(*), terminal coverx1, safety wire x1,binding bandx1, clamp platex2 (*)including a spare respectively |
| Dust Protection | IP5X for dust protection (with junction cover) |
| Plenum Rating | UL2043 (with junction cover) |
