Yellowtec YT4211 PUC2 High Definition USB Audio Interface (AES3 / Analog Mic/Line XLR)
Contact us
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The PUC2 is a hi-definition USB audio interface with breakthrough horse power, unmatched operating reliability, plug-n-play installation, breakthrough AES-3 and balanced analog audio quality with up to 192 kHz @ 24 bit and a sensational dynamic range of 105 dB.
Installation made easy
With support for Windows and OSX, simply connect PUC2 Mic to the USB port of your PC or Mac and watch the automatic installation. In only a few seconds you'll be enjoying the highest standard of USB audio performance. There are no drivers to install, and since it's USB-powered, you don't need a separate power supply.
Quality comes first
Featuring one of the highest quality mic preamps available, PUC2 Mic ensures pristine audio quality for your microphone signal. The unit also offers AES3 digital audio (XLR) inputs and outputs, so it's a brilliant cost-saving solution when your application doesn't call for analog audio interfacing. And most importantly, PUC2 Mic delivers the same exceptional specs as the PUC2. For enhanced ease-of-use and functionality, we even offer a proprietary ASIO driver available for download free of charge.
Anything but average - the superior audio quality you deserve
Just like PUC2, PUC2 Mic delivers the highest available audio standards - up to 192 kHz at 24-bit - with a sensational dynamic range of 105dB. It combines simple, seamless setup with a clever modular design, providing the flexible ease-of-use you demand and the audio quality you deserve.
Real-time monitoring
Zero Latency Monitoring is a unique feature that allows you to monitor your recording signal in real-time, without any kind of delay. You can choose between listening to the input signal, or the return path arriving via USB.
Intelligent power management
Since PUC2 Mic is powered via USB, there's no bulky power supply and fewer cables to connect, so it delivers exceptional performance without cluttering your workspace.
| Power (via Dual USB) | < 1000 mA |
| Clocking | Jitter: < 15 mUI peak |
| Input Selection | Automatic with AES Detection |
| Digital Input | |
| Format | AES 3 + SPF/DIF |
| Connectors | XLR |
| SUB-D Module Connections | SUB-D 25 pin |
| Sampling Rate | 44,1 kHz, 48 kHz, 88,2 kHz, 96 kHz, 176,4 kHz, 192 kHz |
| Bit Depth | 24 Bit |
| Digital Output | |
| Format | AES 3 |
| Connectors | XLR |
| SUB-D Module Connections | SUB-D 25 pin |
| Sampling Rate | 44,1 kHz, 48 kHz, 88,2 kHz, 96 kHz, 176,4 kHz, 192 kHz |
| Bit Depth | 24 Bit |
| Analog Input | ... +18 dBu |
| Impedance | Mic typ 1,2 kOhm Live typ 10 kOhm |
| Analog Output | Not Balanced |
| Impedance | < 16 Ohm, Headphones with up to 600 Ohm can be used |
| USB Connector | USB 2.0 Type B |
| Phantom Power | 48 V 5 mA |
| Headphone Output | Adjustable Volume, < 16 Ohm, Headphones up to 600 Ohm can be used |
| Microphone Input | Gain: 0.05% Input Referred Noise: -127 dBu @ 150 Ohm Impedance: 1,2 kOhm |
| AD/DA Converter | |
| Dynamic | 108 dB |
| THD+N ADC | -107 dB THD+N |
| THD+N DAC | -103 dB THD+N |
| Sampling Rate DAC | 44,1 kHz, 48 kHz, 88,2 kHz, 96 kHz, 176,4 kHz, 192 kHz |
| Bit Depth | 24 Bit |
| Length | 185mm |
| Width | 127mm |
| Height | 41,5mm |
| Weight | 600g |
The PUC2 is a hi-definition USB audio interface with breakthrough horse power, unmatched operating reliability, plug-n-play installation, breakthrough AES-3 and balanced analog audio quality with up to 192 kHz @ 24 bit and a sensational dynamic range of 105 dB.
Installation made easy
With support for Windows and OSX, simply connect PUC2 Mic to the USB port of your PC or Mac and watch the automatic installation. In only a few seconds you'll be enjoying the highest standard of USB audio performance. There are no drivers to install, and since it's USB-powered, you don't need a separate power supply.
Quality comes first
Featuring one of the highest quality mic preamps available, PUC2 Mic ensures pristine audio quality for your microphone signal. The unit also offers AES3 digital audio (XLR) inputs and outputs, so it's a brilliant cost-saving solution when your application doesn't call for analog audio interfacing. And most importantly, PUC2 Mic delivers the same exceptional specs as the PUC2. For enhanced ease-of-use and functionality, we even offer a proprietary ASIO driver available for download free of charge.
Anything but average - the superior audio quality you deserve
Just like PUC2, PUC2 Mic delivers the highest available audio standards - up to 192 kHz at 24-bit - with a sensational dynamic range of 105dB. It combines simple, seamless setup with a clever modular design, providing the flexible ease-of-use you demand and the audio quality you deserve.
Real-time monitoring
Zero Latency Monitoring is a unique feature that allows you to monitor your recording signal in real-time, without any kind of delay. You can choose between listening to the input signal, or the return path arriving via USB.
Intelligent power management
Since PUC2 Mic is powered via USB, there's no bulky power supply and fewer cables to connect, so it delivers exceptional performance without cluttering your workspace.
| Power (via Dual USB) | < 1000 mA |
| Clocking | Jitter: < 15 mUI peak |
| Input Selection | Automatic with AES Detection |
| Digital Input | |
| Format | AES 3 + SPF/DIF |
| Connectors | XLR |
| SUB-D Module Connections | SUB-D 25 pin |
| Sampling Rate | 44,1 kHz, 48 kHz, 88,2 kHz, 96 kHz, 176,4 kHz, 192 kHz |
| Bit Depth | 24 Bit |
| Digital Output | |
| Format | AES 3 |
| Connectors | XLR |
| SUB-D Module Connections | SUB-D 25 pin |
| Sampling Rate | 44,1 kHz, 48 kHz, 88,2 kHz, 96 kHz, 176,4 kHz, 192 kHz |
| Bit Depth | 24 Bit |
| Analog Input | ... +18 dBu |
| Impedance | Mic typ 1,2 kOhm Live typ 10 kOhm |
| Analog Output | Not Balanced |
| Impedance | < 16 Ohm, Headphones with up to 600 Ohm can be used |
| USB Connector | USB 2.0 Type B |
| Phantom Power | 48 V 5 mA |
| Headphone Output | Adjustable Volume, < 16 Ohm, Headphones up to 600 Ohm can be used |
| Microphone Input | Gain: 0.05% Input Referred Noise: -127 dBu @ 150 Ohm Impedance: 1,2 kOhm |
| AD/DA Converter | |
| Dynamic | 108 dB |
| THD+N ADC | -107 dB THD+N |
| THD+N DAC | -103 dB THD+N |
| Sampling Rate DAC | 44,1 kHz, 48 kHz, 88,2 kHz, 96 kHz, 176,4 kHz, 192 kHz |
| Bit Depth | 24 Bit |
| Length | 185mm |
| Width | 127mm |
| Height | 41,5mm |
| Weight | 600g |
