Adaptive Technologies WP-16 - Wall Stud Adapter on 16" Center
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The wall stud adapter plate is used to bridge two structural studs offering a secure surface mounting for specific Adaptive Technologies mounting designs including SocketMount, Steerables Wall Mount, Multimount 120 and more. It bridges both standard 16Ó wood and metal construction wall stud spacing.
The wall stud adapter plate is made from rugged alloy steel with two horizontal flanges for added rigidity. The assembly is finished with a baked-on powder coat paint.
The WP-16 may be mounted over dry wall, plaster and other wall materials, as long as it is anchored into the structure. It can even be embedded underneath the wall material for a clean appearance.
Features:
- Mounts on 16Ó Stud Centers
- Black Powdered Coat Finish
- Fixed 3/8 Mount Studs
Compatible Mounts:
- SocketMount¨ SM-075-ASB
- Steerables¨ Wall Arm
- SAS-100-20 Steerables¨ Wall Mount
- SAS-100-WM MultiMount¨
- MM-060 MultiMount¨ MM-120
| Material | Structural Steel Alloy |
| Finish | Powder Coat |
| Color | Black |
| Pack Count | 1/carton |
| Load Rating | 120 lb / 54.5 Kg |
| Package Contents | 1 pc. Wall stud adapter plate 3 pcs. 3/8î Flat washers 3 pcs. 3/8-16 Flange nut Hardware for mounting to the wall structure is not included. |
The wall stud adapter plate is used to bridge two structural studs offering a secure surface mounting for specific Adaptive Technologies mounting designs including SocketMount, Steerables Wall Mount, Multimount 120 and more. It bridges both standard 16Ó wood and metal construction wall stud spacing.
The wall stud adapter plate is made from rugged alloy steel with two horizontal flanges for added rigidity. The assembly is finished with a baked-on powder coat paint.
The WP-16 may be mounted over dry wall, plaster and other wall materials, as long as it is anchored into the structure. It can even be embedded underneath the wall material for a clean appearance.
Features:
- Mounts on 16Ó Stud Centers
- Black Powdered Coat Finish
- Fixed 3/8 Mount Studs
Compatible Mounts:
- SocketMount¨ SM-075-ASB
- Steerables¨ Wall Arm
- SAS-100-20 Steerables¨ Wall Mount
- SAS-100-WM MultiMount¨
- MM-060 MultiMount¨ MM-120
| Material | Structural Steel Alloy |
| Finish | Powder Coat |
| Color | Black |
| Pack Count | 1/carton |
| Load Rating | 120 lb / 54.5 Kg |
| Package Contents | 1 pc. Wall stud adapter plate 3 pcs. 3/8î Flat washers 3 pcs. 3/8-16 Flange nut Hardware for mounting to the wall structure is not included. |
