AKG PT420 Handheld Transmitter for WMS420 Wireless (A Band / 530 - 559 MHz)
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The WMS420 wireless microphone system provides a highly flexible as well as easy to use solution. The ultra high frequency system is set up within seconds and is equally suitable on stage as well as in locations where a single- or multi-channel solution is needed.
The PT420 is a bodypack transmitter for this system. The transmitters are shipped with charging contacts that enable the use of rechargeable batteries. Moreover the transmitters offer exceptional eight hours of operation time from a single AA size battery, which dramatically reduces the operating costs in day-to-day use.
Features:
-
Integrated charging contacts (Optional Accessory: CU400)
Saves money in day-to-day use and preserves the environment -
Compatible with all AKG MicroMics
Allows the transmitter to be used in a wide range of applications -
Up to eight hours with a single AA battery
Long operation time and a low battery indicator guarantee a secure operation -
Noiseless on/off/mute switch
For easy operation -
Gain control on transmitter
For immediate volume adjustment
| Type | Three pin mini XLR connector (female) |
| Maximum audio level | 12dB |
| Rated Impedance | 1 Ohms |
| Audio bandwidth | 40 Ð 20 000 Hz (+/- 3dB) |
| Signal to noise | 105 dB-A |
| THD at 1kHz | 0.8% |
| Transmitter synchronization | Manual |
| Battery type | AA battery (LR 6 AA alkaline battery or HR 6 AA (NiHM) rechargeable battery) |
| Operating time | Up to eight hours with one AA battery |
| Dimensions | 60 x 75,5 x 30 mm |
| Weight | 214g |
