Allen And Heath IP-6 Programmable Controller for dLive Series
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
IP6 is a next generation remote controller for dLive, ideal for many install applications and greatly enhancing the system's flexibility in live sound. It interfaces with the dLive mixing system via standard TCP/IP Network connections and can be networked with other controllers, computers and third party devices using a standard Ethernet infrastructure.
The IP6 controls and functions are programmed using a dLive Surface or dLive Director software for PC/Mac, and can suit a number of applications including:
PERSONAL MONITORING
The IP6 can be configured to control the Send levels, Pans and assignments of multiple channels to a specific mix on the dLive, e.g. for wireless IEM use, giving musicians the freedom to control their own monitor sound.
INSTALLATION
The installer or system integrator can configure the IP6 to provide the degree of control needed by the day to day operator, for example the levels of microphones and music sources in a room.
Features:
- 6 Push n Turn Rotary encoders
- 6x Layers
- PoE or external 12V PSU (supplied)
- Optional mic stand bracket available (AB8999)
- Optional headphone holder (AB8705)
| System | |
| Network | Fast Ethernet 100MBps |
| Ext DC In | +12V, 2.5A |
| PoE | 802.3af (15.4W at source) |
| Max power consumption | 5W |
| Operating Temperature Range | 0 deg C to 35 deg C (32 deg F to 95 deg F) |
| Dimensions and Weights | Width x Depth x Height x Weight |
| IP6 | 227 x 150 x 55 mm x 1.5kg (3.3lbs) |
| IP6 (boxed) | 300 x 330 x 170 mm x 1.6kg (3.5lbs) |
IP6 is a next generation remote controller for dLive, ideal for many install applications and greatly enhancing the system's flexibility in live sound. It interfaces with the dLive mixing system via standard TCP/IP Network connections and can be networked with other controllers, computers and third party devices using a standard Ethernet infrastructure.
The IP6 controls and functions are programmed using a dLive Surface or dLive Director software for PC/Mac, and can suit a number of applications including:
PERSONAL MONITORING
The IP6 can be configured to control the Send levels, Pans and assignments of multiple channels to a specific mix on the dLive, e.g. for wireless IEM use, giving musicians the freedom to control their own monitor sound.
INSTALLATION
The installer or system integrator can configure the IP6 to provide the degree of control needed by the day to day operator, for example the levels of microphones and music sources in a room.
Features:
- 6 Push n Turn Rotary encoders
- 6x Layers
- PoE or external 12V PSU (supplied)
- Optional mic stand bracket available (AB8999)
- Optional headphone holder (AB8705)
| System | |
| Network | Fast Ethernet 100MBps |
| Ext DC In | +12V, 2.5A |
| PoE | 802.3af (15.4W at source) |
| Max power consumption | 5W |
| Operating Temperature Range | 0 deg C to 35 deg C (32 deg F to 95 deg F) |
| Dimensions and Weights | Width x Depth x Height x Weight |
| IP6 | 227 x 150 x 55 mm x 1.5kg (3.3lbs) |
| IP6 (boxed) | 300 x 330 x 170 mm x 1.6kg (3.5lbs) |
