ART USBMix6 - Six-Channel Mixer with USB Interface
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The ART USBMIX6 Microphone, Instrument, and Line Mixer / Computer Interface is a compact versatile audio interface for your computer that converts analog signals from a variety of audio sources to a digital audio. The built-in low latency stereo digital effects add to the versatility. It can also be used as a standalone mixer through the main mix outputs. The USBMIX6 provides a great starting point for personal home studio recording or for anyone wanting to do mobile location recording. Use the USBMIX6 to record podcasts, capture your latest idea for a song, make voiceovers for your home movies, or record a jam with a friend – whenever and wherever your creativity takes you!
Features:
- High Performance Low Noise Design
- Six Discrete Inputs (2 x Mic / 2 x Stereo Line Level)
- Switchable +48v Phantom Power (CH1 and CH2)
- High and Low EQ on Each Input Channel
- Integrated Stereo Multi-FX with Adjustable Sends and Returns
- Stereo LED Metering
- Independent Level Controls for Main and Headphone/Monitor Outputs
- Integrated Class Compliant Plug-and-Play USB Audio for Mac or PC
| Input Connections | XLR and _-inch Balanced Combi-jack (CH 1 and CH2) _-inch TRS Balanced (CH3 and CH4) RCA Unbalanced (CH5 and CH6), RCA Aux Loop In (L and R) |
| Output Connections | _-inch TRS Balanced Main Mix Outputs _-inch TRS Stereo Output and Monitor Outputs RCA Loop Out (L and R) |
| Signal to Noise Ratio | >90dB Typical (Ref 0dBu) |
| Maximum Input Level | +4dBu (Mic), +20dBu (1/4-inch Input) |
| Maximum Output Level | +15dBu Main Mix Outputs |
| Maximum Gain | >54dB (Mic),>39dB (Instrument), 10dB (Stereo Monitor and Line Out) |
| USB Computer Interface | USB Class Compliant plug-and-play Mac / PC Interface |
| Power | 15VAC @ 500mA (Adaptor Included) |
| Dimensions | 1.9_H x 7.4_W x 8.5_D (47mm x 186mm x 215mm) |
| Weight | 3.24 lbs (1.47 kg) |
The ART USBMIX6 Microphone, Instrument, and Line Mixer / Computer Interface is a compact versatile audio interface for your computer that converts analog signals from a variety of audio sources to a digital audio. The built-in low latency stereo digital effects add to the versatility. It can also be used as a standalone mixer through the main mix outputs. The USBMIX6 provides a great starting point for personal home studio recording or for anyone wanting to do mobile location recording. Use the USBMIX6 to record podcasts, capture your latest idea for a song, make voiceovers for your home movies, or record a jam with a friend – whenever and wherever your creativity takes you!
Features:
- High Performance Low Noise Design
- Six Discrete Inputs (2 x Mic / 2 x Stereo Line Level)
- Switchable +48v Phantom Power (CH1 and CH2)
- High and Low EQ on Each Input Channel
- Integrated Stereo Multi-FX with Adjustable Sends and Returns
- Stereo LED Metering
- Independent Level Controls for Main and Headphone/Monitor Outputs
- Integrated Class Compliant Plug-and-Play USB Audio for Mac or PC
| Input Connections | XLR and _-inch Balanced Combi-jack (CH 1 and CH2) _-inch TRS Balanced (CH3 and CH4) RCA Unbalanced (CH5 and CH6), RCA Aux Loop In (L and R) |
| Output Connections | _-inch TRS Balanced Main Mix Outputs _-inch TRS Stereo Output and Monitor Outputs RCA Loop Out (L and R) |
| Signal to Noise Ratio | >90dB Typical (Ref 0dBu) |
| Maximum Input Level | +4dBu (Mic), +20dBu (1/4-inch Input) |
| Maximum Output Level | +15dBu Main Mix Outputs |
| Maximum Gain | >54dB (Mic),>39dB (Instrument), 10dB (Stereo Monitor and Line Out) |
| USB Computer Interface | USB Class Compliant plug-and-play Mac / PC Interface |
| Power | 15VAC @ 500mA (Adaptor Included) |
| Dimensions | 1.9_H x 7.4_W x 8.5_D (47mm x 186mm x 215mm) |
| Weight | 3.24 lbs (1.47 kg) |
