Ashly 24.24M Input - 4-Input Expansion Module for Protea 24.24M Matrix Processor
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The 24.24M Input from Ashley is a four-input expansion module for the Protea 24.24M Matrix Processor base unit. Each card provides an additional four channels of input and brings with it dedicated DSP and analog-to-digital converters.
The card is field installable and require no additional programming from the base unit. Up to five input cards can be installed for a total of twenty-four inputs. Because of the on-board DSP, the base unit's processing is not impacted by the addition of the cards.
- • Four-channel input expansion card for Protea 24.24M Matrix Processor
- • Includes its own dedicated DSP and analog-to-digital converters
- • Each input channel has fixed processing blocks that include a microphone preamp with +48V phantom power, gain, delay, fifteen EQ filters, gate, auto-leveler and ducker
- • The Hi-/Low-pass filter block offers Bessel, Butterworth and Linkwitz-Riley filters with 12, 18, 24 and 48dB/octave slopes
- • User installable
- • Base unit automatically recognizing presence of the card without requiring additional programming
- • Euroblock connectors
| Frequency Response | 20Hz to 20kHz, +/-0.25dB |
| Dynamic Range | >110dB unweighted, 20Hz to 20kHz B/W |
| Input Connections | Euroblock |
| Input Impedance | 18kΩ |
| Output Impedance | 112Ω |
| Maximum Input Level | +20dBu |
| Maximum Output Level | +20dBu |
| Sample Rate | 48kHz |
| THD / Noise | <0.01% @1kHz, +20dBu |
