Description
The new Engineered Sound¨. Contractor-exclusive innovations for every acoustical challenge. And safe haven from RFI.
The ES905CL is designed for quality sound reinforcement, professional recording, television and other demanding sound pickup applications. Its rigid-pipe design with ball-in-socket base permits flexible positioning, while its durable metal base mounts to a table, desk or podium with included hardware. The attached wire mesh windscreen with internal pop protection effectively reduces noise from P-pops, wind, and ventilation air currents. The microphone offers unsurpassed immunity from radio frequency interference thanks to UniGuard¨ innovations. The ES905CL also offers an 80 Hz low-cut UniSteep¨ filter that reduces pickup of low-frequency ambient noise. The microphone's low-profile element provides a uniform cardioid polar pattern with a 120¼ acceptance angle. Power module included.
Features:
- Designed for high-quality sound reinforcement, professional recording and broadcasting
- Low-profile element provides uniform cardioid polar pattern with 120¼ acceptance angle
- Rigid-pipe design with ball-in-socket base permits flexible positioning
- Sturdy metal base mounts to table, desk or podium with included hardware
- Superior off-axis rejection for maximum gain before feedback
- Requires 11V to 52V DC phantom power
- UniGuard¨ RFI-shielding technology offers outstanding rejection of radio frequency interference (RFI)
- Integral UniSteep¨ filter provides a steep low-frequency attenuation to improve sound pickup without affecting voice quality
- RoHS compliant-free from all substances specified in the EU directive on hazardous substances
| ELEMENT | Fixed-charge back plate permanently polarized condenser |
| POLAR PATTERN | Cardioid |
| FREQUENCY RESPONSE | 60-20,000 Hz |
| LOW FREQUENCY ROLL-OFF | 80 Hz, 18 dB/octave |
| OPEN CIRCUIT SENSITIVITY | -38 dB (12.5 mV) re 1V at 1 Pa |
| IMPEDANCE | 250 ohms |
| MAXIMUM INPUT SOUND LEVEL | 138 dB SPL, 1 kHz at 1% T.H.D. |
| DYNAMIC RANGE (typical) | 111 dB, 1 kHz at Max SPL |
| SIGNAL-TO-NOISE RATIO | 67 dB, 1 kHz at 1 Pa |
| PHANTOM POWER REQUIREMENTS | 11-52V DC, 2 mA typical |
| WEIGHT (MICROPHONE) | 330 g (11.6 oz) |
| WEIGHT (POWER MODULE) | 81 g (2.9 oz) |
| DIMENSIONS (MICROPHONE) | 523.4 mm (20.61") long, 24.6 mm (0.97") head diameter |
| DIMENSIONS (POWER MODULE) | 92.9 mm (3.66") long, 18.9 mm (0.74") diameter |
| OUTPUT CONNECTOR (POWER MODULE) | Integral 3-pin XLRM-type |
| CABLE | 2.9 m (9.5') long, (permanently attached to microphone) 3.2 mm (0.13") diameter, 2-conductor, shielded cable terminated with TA3F-type connector |
| OPTIONAL INTERCHANGEABLE ELEMENTS | ESE-H hypercardioid (100Á); ESE-O omnidirectional (360Á) |
| ACCESSORIES FURNISHED | AT8538 power module; (3) #8 x 1" black oxide wood screws for microphone mount |
| AUDIO-TECHNICA CASE STYLE | M37 |
