Bogen V100 100 Watt Power Vector Modular Input Amplifier with 8 Bays and LED Meter
Availability:
In StockAvailable for shipment within one business day, or pickup from our Jamaica, NY warehouse during regular business hours.
Description
V100 is designed to work with both high- (70/25V) and low- (4/8-ohm) impedance speaker systems.V100 includes eight module bays for plug-in input modules and allows up to four levels of priority between modules. Two module bays are capable of accepting plug-in signal-processing output modules. Each module is controlled by an independent volume control with an associated signal/clip LED for signal status. An 11-segment LED output meter monitors output signal level.V100 includes a motorized master volume control that can be controlled using a remote volume control panel (RVCP, sold separately).
Features:- 8 module bays for inputs and outputs Each input has a independant volume control
- 4 levels of priority between modules
- 125Hz Lo-cut filter for module 6
- 11-segment LED output level meter monitors the output level of the power amplifier with peak and average meter switch
- Grounded, un-switched AC convenience receptacle with a 500W maximum capacity provided for external equipment
- Remote volume control panel can operate motorized volume control (RVCP sold separately)
| Power Output | 100W |
| Distortion | <0.5% |
| Frequency Response | |
| Transformer | 45-20,000Hz |
| Direct output | 20-20,000Hz |
| Signal to Noise Ratio | |
| Fundamental | -94 dB |
| With Aux Module | -70 dB |
| With Mic Module | -60 dB |
| With Tel Module | -70 dB |
| Output Impedance | |
| Transformer-Coupled | 70V, 25V, 8 ohms (balanced or unbalanced) |
| Direct Coupled | 4 ohms |
| Muting | |
| 4 Steps | -60, -21, -10, 0dB |
| Output Connections | Pre-EQ (RCA) x 1, Signal Processor (RCA) x 1, 2 module bays |
| Input Connections | 8 module bays |
| Specialties | 500W unswitched grounded outlet |
| Dimensions | 16.5 x 3.5 x 12 (419.1 x 88.9 x 304.8mm) |
| Weight | 32 lbs (14.5kg) |
V100 is designed to work with both high- (70/25V) and low- (4/8-ohm) impedance speaker systems.V100 includes eight module bays for plug-in input modules and allows up to four levels of priority between modules. Two module bays are capable of accepting plug-in signal-processing output modules. Each module is controlled by an independent volume control with an associated signal/clip LED for signal status. An 11-segment LED output meter monitors output signal level.V100 includes a motorized master volume control that can be controlled using a remote volume control panel (RVCP, sold separately).
Features:- 8 module bays for inputs and outputs Each input has a independant volume control
- 4 levels of priority between modules
- 125Hz Lo-cut filter for module 6
- 11-segment LED output level meter monitors the output level of the power amplifier with peak and average meter switch
- Grounded, un-switched AC convenience receptacle with a 500W maximum capacity provided for external equipment
- Remote volume control panel can operate motorized volume control (RVCP sold separately)
| Power Output | 100W |
| Distortion | <0.5% |
| Frequency Response | |
| Transformer | 45-20,000Hz |
| Direct output | 20-20,000Hz |
| Signal to Noise Ratio | |
| Fundamental | -94 dB |
| With Aux Module | -70 dB |
| With Mic Module | -60 dB |
| With Tel Module | -70 dB |
| Output Impedance | |
| Transformer-Coupled | 70V, 25V, 8 ohms (balanced or unbalanced) |
| Direct Coupled | 4 ohms |
| Muting | |
| 4 Steps | -60, -21, -10, 0dB |
| Output Connections | Pre-EQ (RCA) x 1, Signal Processor (RCA) x 1, 2 module bays |
| Input Connections | 8 module bays |
| Specialties | 500W unswitched grounded outlet |
| Dimensions | 16.5 x 3.5 x 12 (419.1 x 88.9 x 304.8mm) |
| Weight | 32 lbs (14.5kg) |
