Bogen WV150 Wall Mount 150-Watt Mixer Amplifier


  • Dale #:

    BOGE-WV150
  • Availability:

    Not in Stock - Reserve Yours
  • This item is not in stock, but we can usually ship it within 10-20 days after your order is placed. Your payment will be charged after completing checkout.

Description

Bogen's Wall-Mount Power Vector modular amplifiers offer a wide range of power from which to choose from, with three models ranging from 100W to 250W. The amplifiers are designed to work with both high- (70/25V) and low- (4/8-ohm) impedance speaker systems. Each model includes eight module bays f... Read More

Free Shipping (Continental US)

Have a Question?

Call Toll Free: 888-462-7828 Live Chat Email Us

Suggested Accessories

Description

Bogen's Wall-Mount Power Vector modular amplifiers offer a wide range of power from which to choose from, with three models ranging from 100W to 250W. The amplifiers are designed to work with both high- (70/25V) and low- (4/8-ohm) impedance speaker systems. Each model includes eight module bays for plug-in input modules and allows for up to four levels of priority between modules. Two module bays are capable of accepting signal processing plug-in output modules. Each module is controlled by an independent volume control with an associated signal/clip LED for signal status. An 11-segment LED-output meter monitors output signal level. Each model includes a motorized master volume control that can be controlled using a remote volume control panel (RVCP, sold separately).

Features:

  • 150-watts, with a large power reserve
  • Capable of handling 70V, 25V, 8-ohm, and 4-ohm speaker loads
  • 8 module bays
  • Wide selection of advanced plug-in modules
  • 2 module bays capable of handling signal processing plug-in output modules
  • 4 levels of priority between modules
  • 11-segment LED-output level meter monitors the output level of the power amplifier with Peak and Average meter switch
  • Adjustable output level limiter with limit indicator
  • Tape output available on front of unit
  • Optional front-mounted input combo jack with 1/4" stereo phone and female XLR capabilities
  • Motorized master volume control can be remotely operated
  • Bass and treble controls with center detent
  • Two-color LED for each channel indicates input active/clipping
  • Switch permits user to select either transformer coupled outputs or a direct low-impedance output
  • Bass and treble control bypass switch (located in module bay 6)
  • 125 Hz Lo-cut feature (switch located in module bay 6)
  • 5-position barrier strip, with clamping washers, provides connections for speaker loads
  • Master mute function overrides all audio from the mixer section of the amplifier
  • Screw terminal for master mute and remote volume control functions
  • Each of the 8 module bays has an associated independent volume control
  • Remote volume control panel (RVCP) (sold separately)
  • Requires flush-mount (Model BBF) or surfacemount (Model BBS) back boxes (sold separately)
  • Requires front cover door (WMAD-sold separately)
  • Listed to UL Standard 60065 for US and Canada

More +

Product Specs

Power Output (RMS) 150W (200W Typical, @1 kHz/0.1%/4W)
Frequency Response Transformer: 45 Hz to 20 kHz; 0/-2 dB @ FRP
Direct: 20 Hz to 20 kHz; 0/-1 dB @ FRP
Distortion Transformer: 0.5% THD+N, Maximum,
Full-rated bandwidth @ FRP
Direct: 0.1% THD+N, Maximum,
Full-rated bandwidth @ FRP
Signal-to-Noise Fundamental: -94 dB*
With Aux Module: -70 dB*
With Mic Module: -60 dB*
With Tel Module: -70 dB*
* Referenced to full-rated power (FRP) output level, 20 Hz to 20 kHz bandwidth limited.
Tone Controls Bass Frequency: 100 Hz (+/- 10 dB minimum)
Treble Frequency: 10 kHz (+/- 10 dB minimum)
Low Cut Frequency: 125 Hz @ -6 dB/octave
Sensitivity 0.4V (at backplane connector)
Output Regulation 2 dB or better, no load to full load
Output Impedance Transformer-Coupled: 70V, 25V, 8 ohms; balanced or unbalanced
Direct Coupled: 4 ohms unbalanced
Tape Out Output Level: 4 VRMS @ FRP
Output Impedance: 50 ohms maximum
Overload Protection Electronic overload protection (auto reset)
Thermal Protection Thermistor attached to heat sink
Line Fusing Resettable circuit breaker
Cooling Thermally controlled 3-speed fan
Power Consumption 3.5A @ 120V AC, 60 Hz
Thermal Emissions 696.7 BTU/hr.
Dimensions 14-1/8" W x 21" H
Product Weight 29 lb.
