Bose MB210-WR Outdoor Surface Mount Subwoofer (Black)
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
Bose Professional MB210-WR compact subwoofers are designed for outdoor installations of background/ foreground music and small sound-reinforcement systems that require low-frequency extension down to 37 Hz. The MB210-WR subwoofer features two (2) 10-inch high- excursion woofers, derived from the award-winning Bose Professional F1 subwoofer, in a compact, exterior-grade plywood enclosure optimized for outdoor, fixed-installation applications. Featuring outstanding performance to size ratio, the MB210-WR is designed to complement Bose Professional loudspeaker lines, in outdoor applications, such as ArenaMatch Utility, Panaray, DesignMax, and Freespace, with additional bass impact.
Features:
- 2 x 10" high-excursion woofers for high-output bass in a compact enclosure. Transducers derived from award-winning Bose F1 portable, powered subwoofer
- 500 W long-term power handling for high sound output and reliability
- Low-frequency extension down to 37 Hz for impactful, deep-bass music reinforcement
- 123 dB maximum continuous SPL, 129 dB peak SPL
- Exterior-grade plywood enclosure with compact size for installations
- Install outdoors with an IP55 weather rating, three-layer stainless steel grille, water-resistant coating on woofer cone, industrial polyurea exterior coating, and molded cover to protect inputs
U-bracket included for easy mounting to walls or ceilings
| Single Subwoofer Performance | |
| Frequency Response (-3 dB) | 45 Ð 180 Hz |
| Frequency Range (-10 dB) | 37 Ð 270 Hz |
| Recommended High-Pass Protection Filter | 40 Hz with 24-dB / octave filter |
| Nominal Coverage Pattern | Omnidirectional below 200 Hz |
| Power Handling, long-term continuous | Bose extended-lifecycle test (4) AES transducer test (5) 500 W 625 W |
| Power Handling, peak | Bose extended-lifecycle test (4) AES transducer test (5) 2000 W 2500 W |
| Sensitivity (SPL) / 1 W @ 1m) | Free Field Wall/Ceiling Free Field Wall/Ceiling 90 dB 96 dB 90 dB 96 dB |
| Calculated Maximum SPL 1m) | Free Field Wall/Ceiling Free Field Wall/Ceiling 117 dB 123 dB 118 dB 124 dB |
| Calculated Maximum SPL 1m),peak | Free Field Wall/Ceiling Free Field Wall/Ceiling 123 dB 129 dB 124 dB 130 dB |
| Transducers | 2 x Bose 10-inch, high-excursion woofers |
| Nominal Impedance | 8 ohms |
| Physical | |
| Enclosure Material | Exterior-grade plywood |
| Finish | Two-part polyurea coating, black or white |
| Grille | Powder-coated perforated stainless steel, acoustic foam, stainless steel mesh |
| Environmental | Rated for direct-exposure outdoor installations (IEC 60529: IP55) |
| Connectors | 1 _ barrier strip (accepts 10 to 18 wire gauge) |
| Suspension / Mounting | 3 _ M8 threaded inserts for U-bracket (per side) |
| Dimensions (H _ W _ D) | 291 _ 685 _ 517 mm (11.5 _ 27.0 _ 20.4 in) |
| Dimensions without U-bracket (H _ W _ D) | 291 _ 659 _ 484 mm (11.5 _ 26.0 _ 19.1 in) |
| Net Weight (loudspeaker only) | 19.4 kg (42.8 lb) |
| Net Weight (with U-bracket) | 23.0 kg (50.6 lb) |
| Shipping Weight | 27.7 kg (61.1 lb) |
| Accessories Included | stainless-steel U-bracket |
Bose Professional MB210-WR compact subwoofers are designed for outdoor installations of background/ foreground music and small sound-reinforcement systems that require low-frequency extension down to 37 Hz. The MB210-WR subwoofer features two (2) 10-inch high- excursion woofers, derived from the award-winning Bose Professional F1 subwoofer, in a compact, exterior-grade plywood enclosure optimized for outdoor, fixed-installation applications. Featuring outstanding performance to size ratio, the MB210-WR is designed to complement Bose Professional loudspeaker lines, in outdoor applications, such as ArenaMatch Utility, Panaray, DesignMax, and Freespace, with additional bass impact.
Features:
- 2 x 10" high-excursion woofers for high-output bass in a compact enclosure. Transducers derived from award-winning Bose F1 portable, powered subwoofer
- 500 W long-term power handling for high sound output and reliability
- Low-frequency extension down to 37 Hz for impactful, deep-bass music reinforcement
- 123 dB maximum continuous SPL, 129 dB peak SPL
- Exterior-grade plywood enclosure with compact size for installations
- Install outdoors with an IP55 weather rating, three-layer stainless steel grille, water-resistant coating on woofer cone, industrial polyurea exterior coating, and molded cover to protect inputs
U-bracket included for easy mounting to walls or ceilings
| Single Subwoofer Performance | |
| Frequency Response (-3 dB) | 45 Ð 180 Hz |
| Frequency Range (-10 dB) | 37 Ð 270 Hz |
| Recommended High-Pass Protection Filter | 40 Hz with 24-dB / octave filter |
| Nominal Coverage Pattern | Omnidirectional below 200 Hz |
| Power Handling, long-term continuous | Bose extended-lifecycle test (4) AES transducer test (5) 500 W 625 W |
| Power Handling, peak | Bose extended-lifecycle test (4) AES transducer test (5) 2000 W 2500 W |
| Sensitivity (SPL) / 1 W @ 1m) | Free Field Wall/Ceiling Free Field Wall/Ceiling 90 dB 96 dB 90 dB 96 dB |
| Calculated Maximum SPL 1m) | Free Field Wall/Ceiling Free Field Wall/Ceiling 117 dB 123 dB 118 dB 124 dB |
| Calculated Maximum SPL 1m),peak | Free Field Wall/Ceiling Free Field Wall/Ceiling 123 dB 129 dB 124 dB 130 dB |
| Transducers | 2 x Bose 10-inch, high-excursion woofers |
| Nominal Impedance | 8 ohms |
| Physical | |
| Enclosure Material | Exterior-grade plywood |
| Finish | Two-part polyurea coating, black or white |
| Grille | Powder-coated perforated stainless steel, acoustic foam, stainless steel mesh |
| Environmental | Rated for direct-exposure outdoor installations (IEC 60529: IP55) |
| Connectors | 1 _ barrier strip (accepts 10 to 18 wire gauge) |
| Suspension / Mounting | 3 _ M8 threaded inserts for U-bracket (per side) |
| Dimensions (H _ W _ D) | 291 _ 685 _ 517 mm (11.5 _ 27.0 _ 20.4 in) |
| Dimensions without U-bracket (H _ W _ D) | 291 _ 659 _ 484 mm (11.5 _ 26.0 _ 19.1 in) |
| Net Weight (loudspeaker only) | 19.4 kg (42.8 lb) |
| Net Weight (with U-bracket) | 23.0 kg (50.6 lb) |
| Shipping Weight | 27.7 kg (61.1 lb) |
| Accessories Included | stainless-steel U-bracket |
