Canare BCJ-XJ-TRC XLR-3 Female to BNC Female 11 Ohm to 75 Ohm Digital Audio Impedance Transformer
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Canare BCJ-XJ-TRC XLR-3 Female to BNC Female 11 Ohm to 75 Ohm Digital Audio Impedance Transformer
Sale price$33.65
Regular price$35.42
Description
110 - 75 ohm Impedance Transformer. XLR3: Female BNC: Female
Features:
- SMPTE 276M and AES3 Transmission Standard
- Coaxial transmission of 2 Channel Digital Audio
- Allows longer cable runs than 110 ohm twisted pair
- AES/EBU Signal distribution using Canare 75 ohm Video Patchbays
Applications:
- Post Production Suites
- Recording Studios
- AES/EBU Digital Audio Routing
| Model | BCJ-XJ-TRB |
| Bandwidth | 0.1 - 6MHz |
| Maximum Voltage | 5Vp-p |
| VSWR | <1.1 |
| Insertion Loss | <0.3dB |
| 110 ohm Port (Balanced) | XLR3 Female 1: Shell 2: Hot 3:Cold |
| 75 ohm Port (Unbalanced) | Canare 75 ohm BNC Receptacle |
110 - 75 ohm Impedance Transformer. XLR3: Female BNC: Female
Features:
- SMPTE 276M and AES3 Transmission Standard
- Coaxial transmission of 2 Channel Digital Audio
- Allows longer cable runs than 110 ohm twisted pair
- AES/EBU Signal distribution using Canare 75 ohm Video Patchbays
Applications:
- Post Production Suites
- Recording Studios
- AES/EBU Digital Audio Routing
| Model | BCJ-XJ-TRB |
| Bandwidth | 0.1 - 6MHz |
| Maximum Voltage | 5Vp-p |
| VSWR | <1.1 |
| Insertion Loss | <0.3dB |
| 110 ohm Port (Balanced) | XLR3 Female 1: Shell 2: Hot 3:Cold |
| 75 ohm Port (Unbalanced) | Canare 75 ohm BNC Receptacle |
