Canare L-4E6S - Bulk Star Quad Microphone Cable (Red / 200 Meter Spool)
Availability:
In StockAvailable for shipment within one business day, or pickup from our Jamaica, NY warehouse during regular business hours.
Description
The premier Star Quad cable (in blue) from Canare is perfect for all handheld microphone applications. Other uses include portable applications, audio rack wiring, PA systems, and audio patch cords. Star Quad provides you with four 21 AWG wires, that act as two conductors. In a balanced line, instead of using one conductor for your Positive and Negative terminal, Star Quad supplies each terminal with two conductors. This creates a more reliable connection. Insulation and a braided copper shield surround the conductors, which is then housed in a flexible, satin smooth to the touch jacket. This extra strong cable fits perfectly in all XLR-type audio connectors. When tested along with other high end cable, Canare's Star Quad rejects more EMI and RFI noise. To eliminate breakage, forty separate strands are used in each conductor.
Available in 10 beautiful matte finish color jackets.
Features:
- Braided Copper Shield
- Flexible in Extreme Cold Weather
- Cross Linked PE Insulation
- Reduced Handling Noise
- Rejects EMI and RFI
| Standard Length | 656 ft (200 m) 1000 ft (305 m) |
| Weight Per Standard Length | 24 lbs (11 kg) 35 lbs (16 kg) |
| Nominal Outside Diameter | .236 in (6.00 mm) |
| Jacket Nominal Thickness | PVC .044 in (1.12 mm) |
| Brittle Point | -56 F (-49 C) |
| No. of Conductors | 4 2 Blue 2White |
| Insulation Type, Thickness | IPE 15.7 mil |
| Cond-AWG (Qty./mil) Cross Section Area mil.² | AC - #24 40/3.15 310 |
| Pitch Twist Quad | .79 in (20 mm) |
| Shield Coverage | >95% TAC Braid |
| Conductor DCR | <29.9 ohms/1000 ft (<9.8 ohms/100 m) |
| Shield DCR | <9.1 ohms/1000 ft (<3.0 ohms/100 m) |
| Nominal Capacitance (Conductor to Conductor) | 150 ohms |
| Nominal Capacitance (Conductor to Shield) | 185 ohms |
| Nominal Impedance | 44 ohms |
| Nominal Attentuation | 0.9 V/1000 ft (0.3 V/100 m) |
| Group Delay Time | 1.80 ns/ft (5.9 ns/m) |
| Colors | Black, Blue, Brown, Gray, Green, Orange, Purple, Red, White, Yellow |
The premier Star Quad cable (in blue) from Canare is perfect for all handheld microphone applications. Other uses include portable applications, audio rack wiring, PA systems, and audio patch cords. Star Quad provides you with four 21 AWG wires, that act as two conductors. In a balanced line, instead of using one conductor for your Positive and Negative terminal, Star Quad supplies each terminal with two conductors. This creates a more reliable connection. Insulation and a braided copper shield surround the conductors, which is then housed in a flexible, satin smooth to the touch jacket. This extra strong cable fits perfectly in all XLR-type audio connectors. When tested along with other high end cable, Canare's Star Quad rejects more EMI and RFI noise. To eliminate breakage, forty separate strands are used in each conductor.
Available in 10 beautiful matte finish color jackets.
Features:
- Braided Copper Shield
- Flexible in Extreme Cold Weather
- Cross Linked PE Insulation
- Reduced Handling Noise
- Rejects EMI and RFI
| Standard Length | 656 ft (200 m) 1000 ft (305 m) |
| Weight Per Standard Length | 24 lbs (11 kg) 35 lbs (16 kg) |
| Nominal Outside Diameter | .236 in (6.00 mm) |
| Jacket Nominal Thickness | PVC .044 in (1.12 mm) |
| Brittle Point | -56 F (-49 C) |
| No. of Conductors | 4 2 Blue 2White |
| Insulation Type, Thickness | IPE 15.7 mil |
| Cond-AWG (Qty./mil) Cross Section Area mil.² | AC - #24 40/3.15 310 |
| Pitch Twist Quad | .79 in (20 mm) |
| Shield Coverage | >95% TAC Braid |
| Conductor DCR | <29.9 ohms/1000 ft (<9.8 ohms/100 m) |
| Shield DCR | <9.1 ohms/1000 ft (<3.0 ohms/100 m) |
| Nominal Capacitance (Conductor to Conductor) | 150 ohms |
| Nominal Capacitance (Conductor to Shield) | 185 ohms |
| Nominal Impedance | 44 ohms |
| Nominal Attentuation | 0.9 V/1000 ft (0.3 V/100 m) |
| Group Delay Time | 1.80 ns/ft (5.9 ns/m) |
| Colors | Black, Blue, Brown, Gray, Green, Orange, Purple, Red, White, Yellow |
