Description
Standard CAT6 UTP cable.
Features:
- 23 AWG solid conductors
- Length markings on jacket
- UL 444 type CM
- Packaged in a pull box
Shield Type | N/A (U/UTP) |
Nominal Outer Diameter | 6.0 mm |
Weight per 100 meters | 4 kg |
Conductors | 0.23 mm2 (23 AWG) |
Conductor quantity per mm | 1/0.55A |
DCR | 8.2 ohms per 100m |
Impedance | 100 ohms |
Insertion Loss at 100 MHz | 19.8 dB per 100m |
Insertion Loss at 250 MHz | 32.8 dB per 100m |
Standard CAT6 UTP cable.
Features:
- 23 AWG solid conductors
- Length markings on jacket
- UL 444 type CM
- Packaged in a pull box
Shield Type | N/A (U/UTP) |
Nominal Outer Diameter | 6.0 mm |
Weight per 100 meters | 4 kg |
Conductors | 0.23 mm2 (23 AWG) |
Conductor quantity per mm | 1/0.55A |
DCR | 8.2 ohms per 100m |
Impedance | 100 ohms |
Insertion Loss at 100 MHz | 19.8 dB per 100m |
Insertion Loss at 250 MHz | 32.8 dB per 100m |
