Comtek BS T25-216 Base Station Transmitter


  • Dale #:

    COMT-BST25216
  • Availability:

    Not in Stock - Reserve Yours
  • This item is not in stock, but we can usually ship it within 10-20 days after your order is placed. Your payment will be charged after completing checkout.

Description

The BST-25/216 MHz is a professional quality, auxiliary base station transmitter designed to operate with the PR-216 and PR-216 Option 7 synthesized receivers in the newly assigned 216-217 MHz band under Part 95 of the FCC regulations.Features: 57 user-selectable channels in the 216-217 MHz range... Read More

Free Shipping (Continental US)

Have a Question?

Call Toll Free: 888-462-7828 Live Chat Email Us

Suggested Accessories

Description

The BST-25/216 MHz is a professional quality, auxiliary base station transmitter designed to operate with the PR-216 and PR-216 Option 7 synthesized receivers in the newly assigned 216-217 MHz band under Part 95 of the FCC regulations.

Features:

  • 57 user-selectable channels in the 216-217 MHz range: 38 standard narrow-band, non-companded channels; 19 high-fidelity narrow-band channels with companded audio processing.
  • Single-window, bright LED display for exact frequency and channel, VU bar graph meter, antenna condition and lock-out indicator.
  • Test tone generator for receiver testing and audio level referencing.
  • Balanced mic or line level with 60 dB of control range to accommodate any audio level.
  • Micro controller automatically sets the modulation deviation, the audio mode for companding processing, and the EQ when corresponding channels are selected.
  • Can be rack mounted for AC or 12 volt DC power and can accommodate a variety of remote antennas.

More +

Product Specs

Audio InputsMic XLR, 600 ohm balanced -40 dBV (nominal)
Line XLR, 10 k ohm balanced 0 dBV (nominal)
ConnectorsXLR-3 Female audio input connector for mic and line input
XLR-4 Male power input 12 volts
BNC type RF output connector
Operation IndicatorsLED Bargraph VU Meter displays audio input (modulation)
Two-Digit Alpha Numeric Display shows operating channel
Five-Digit Numeric Display shows operating frequency
Antenna Indicator displays deficient antenna condition
Lock Out Indicator shows tuning has been disabled
AntennaTelescopic antenna mounts directly into top of transmitter
BNC RF output connector for optional external antenna
FCC ComplianceType Accepted under Part 95
Power Requirements12 Volts DC, 300 mA max
Frequency Response80 Hz to 8 kHz
Audio DistortionLess than 1% at 80% modulation
Modulation LimiterSoft compressor type with high (25 dB) linear overload protection,
attack time less than 1 ms,
recovery time 10 ms
Audio Gain ControlGreater than 40 dB
Test Tone Generator400 Hz 0.05% distortion
Frequency Modulation5 and 10 KHZ deviation
RF Output PowerSet for 100 mW for FCC Part 95
Frequency StabilityBetter than 20 ppm. digitally synthesized, crystal controlled
Operating Frequency216 to 217 MHz
Harmonic and Spurious EmissionsBetter than 55 dB below carrier
Dimensions6 1/2" wide x 1 3/4" high x 5 5/8" deep
Weight44 oz.
