Crane Song Interstellar - Stereo Quantum Analog to Digital Converter with USB


  • Dale #:

    CRAN-INTERSTELLAR
  • Availability:

    Special Order Item
  • Crane Song products are made to order in the USA - please contact us for lead times.

Description

INTERSTELLAR is a stereo ADC using Crane Song's Quantum, sub Pico second clocking technology. Included in Interstellar is dsp emulation for Triode and Pentode tubes, Tape emulation, dithering to 24 or 16 bits and word clock outputs. The Word Clock outputs allow Interstellar to function as a mas... Read More

Free Shipping (Continental US)

Have a Question?

Call Toll Free: 888-462-7828 Live Chat Email Us

Suggested Accessories

Description

INTERSTELLAR is a stereo ADC using Crane Song's Quantum, sub Pico second clocking technology. Included in Interstellar is dsp emulation for Triode and Pentode tubes, Tape emulation, dithering to 24 or 16 bits and word clock outputs. The Word Clock outputs allow Interstellar to function as a master clock.

When used as an USB interface, there is a SPDIF output that can be used to connect to a DAC. Making Interstellar a USB bi directional interface. In the USB mode the computer will set the sample rate and thus the sample rate of the Word Clock outputs. The AES, SPDIF and Optical outputs are active and can be used at the same time as the USB connection. The level of the dsp functions is set by front panel controls.

When the USB connection is not in use, The clock rate is set by the front panel controls.

More +

Product Specs

Analog Input Transformerless balanced stereo input on XLR-fm connectors.
The default calibration is +20 dBu = Digital zero.
Gain Gain adjust trims are on the back panel.
The analog input range for 0 dbfs is adjustable form +16 to +26 dBu
Word Clock Outputs 8 BNC connectors are a TTL level square wave that can be used to provide sync to other equipment.
The WC outputs will be at the selected sample
Internal Sample Rate 44.1KHz to 192KHz determined by front panel switch or the USB daw setting
S/PDIF Output Unbalanced digital output 75 ohms RCA connector
AES Output Balanced digital output 110 ohms XLR connector
Optical Out toslink format, stereo
Power 25 watts at 115 or 230 volts, 50 or 60 Hz.
Fuse size MDL .3A for 115 volts; MDL .25A for 230 volts
Pilot Lamp #7335 lamp
Shipping Weight 15lbs (6.7kg)
Depth Behind Panel 10 inches (25.4cm) plus user input/output connectors
