Crown CDI 6000 - Solid-State 2-Channel Power Amplifier with EQ + Delay
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
Crown CDi Series amplifiers are professional tools designed and built for installed sound applications. The series includes four models which are identical except for output power: CDi 1000, CDi 2000, CDi 4000, and CDi 6000. All are rugged and lightweight, and offer unmatched value in their class.
CDi-Series amplifiers feature an intuitive front-panel LCD screen to guide installers through their confi gurations. CDi amplifiers also offer onboard DSP for loudspeaker signal processing. Other features include a switch-mode universal power supply, useful function indicators, proportional-speed fanassisted cooling, removable Phoenix-style inputs, barrier strip outputs for low-Z or 70V/100V/140V loads, short-circuit protection and more.
CDI6000:
- 2 ohm Dual (per channel): 3,000W
- 4 ohm Dual (per channel): 2,100W
- 8 ohm Dual (per channel): 1,200W
- 4 ohm Bridge-Mono:6,000W
- 70V Dual (per channel):2,500W
- 140V Bridge-Mono:5,000W
Features:
- Extremely versatile; rated for 2-, 4-, 8-ohm loads and 70V and 140V outputs.
- Switch-mode universal power supply.
- Intuitive front-panel LCD screen for quick, easy configuration.
- Onboard digital signal processing includes crossovers, EQ filters, delay, and output limiting.
- Up to 20 user defined DSP presets are available.
| Frequency Response (at 1 watt into 4 ohms, 20Hz - 20 kHz) | +0/Ð1 dB | ||||||||||||||||||||||||
| Signal to Noise Ratio (below rated 8-ohm power at 1 kHz, A-weighted) | 100 dB | ||||||||||||||||||||||||
| Damping Factor (8 ohm): 20 Hz to 400 Hz | > 500 | ||||||||||||||||||||||||
| Input Stage | Input is electronically balanced and employs precision 1% resistors | ||||||||||||||||||||||||
| Crosstalk (below rated power) 20 Hz to 1 kHz | > 70 dB | ||||||||||||||||||||||||
| Input Impedance (nominal) | 20 kilohms balanced, 10 kilohms unbalanced | ||||||||||||||||||||||||
| Load impedance (note: safe with all types of loads) | Dual: 2Ð8 ohms; Bridge mono: 4Ð16 ohms | ||||||||||||||||||||||||
| Sensitivity (at 8 ohm rated output) | 1.4V | ||||||||||||||||||||||||
| Maximum Input Signal | +22 dBu typical | ||||||||||||||||||||||||
| Operating Temperature | 0¡ C to 40¡ C at 95% relative humidity (non-condensing) | ||||||||||||||||||||||||
| AC Line Voltage and Frequency Configurations Available (± 10%) | 100V, 120V-240V, 50/60 Hz | ||||||||||||||||||||||||
| Ventilation |
