Description
Powering this remarkable amplifier is the pioneering technology of DriveCore™, which integrates the amplifier drive stage into the power output stage fusing everything into a chip the size of a dime. DriveCore's front-end drive circuits leverage the inherent efficiency of Class D output stages wh... Read MoreOur Price: $1,730.00
Shipping Charges Apply
Suggested Accessories
Description
Powering this remarkable amplifier is the pioneering technology of DriveCore™, which integrates the amplifier drive stage into the power output stage fusing everything into a chip the size of a dime. DriveCore's front-end drive circuits leverage the inherent efficiency of Class D output stages while also maintaining superb sonic characteristics. The end result is an audio amplifier circuit that exhibits the exemplary audio quality of a highly evolved Class AB design.
Features:
More +
Product Specs
Channels | 4 |
Power Rating | 4 Ohms: 125W 8 Ohms: 125W |
Sensitivity | 1.4 V |
Rated Power Output (all channels driven) | 125W per CH @ 4 ohms, 125W per CH @ 8 ohms |
Signal to Noise Ratio (below rated power 20 Hz to 20 kHz, A-Weighted) | 110 dB |
THD (full rated power, 20 Hz - 20 kHz) | < 0.05% |
Intermodulation Distortion (from 0 dB down to -30 dB) | < 0.05% |
Frequency Response (at 1W, 4/8 ohms) | +/- 0.5 dB |
Crosstalk (below rated power) 20 Hz to 1 kHz | > 70 dB |
Common Mode Rejection (20 Hz to 1 kHz) | > 55 dB, typically > 70 dB |
Voltage Gain | 27 dB |
DC Offset | +/- 20mV |
Idle Power Consumption (Standard Mode) | 17.5W |
Dimensions | 1.75" x 19" x 15.19" |
Weight | 10lbs/4.54kg |
Shipping Weight | 15 lbs/6.8 kg |
IEC Power Connector | 15A |
