Crown IT5000HD Stereo Power Amplifier (with Networking and DSP)
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Crown IT5000HD Stereo Power Amplifier (with Networking and DSP)
Sale price$7,519.00
Description
Inside and out, the Crown I-TECH HD is one of the most technologically advanced professional touring amplifiers on the market today. Building on the decades of innovation, invention, and insight Crown is known for, the I-TECH HD features five new patents - three on the power supply alone - giving you an amp that goes well beyond the expected. At the heart of the new I-TECH HD is the BSS OMNIDRIVEHD processing engine. Four times faster than its predecessor and featuring Linear Phase FIR filters and LevelMAX™ limiters, OMNIDRIVEHD provides unmatched clarity and sonically pure signal processing.
Features:
- Global Power Supply with PFC (Power Factor Correction) works anywhere in the world.
- High power density, up to 8000 watts in a 2U chassis.
- Highest output voltage in the industry (200V peak) provides clean transient peaks.
- 3rd-generation patented Class I (BCA®) circuitry couples power efficiently to the load and provides low AC current draw
- Onboard high-definition DSP with 24-bit, 192 kHz Cirrus Logic SHARC A/D and D/A converters. Advanced IIR filters and linearphase FIR filters.
- Pushbutton presets simplify setup. Custom presets for various loudspeakers can be downloaded.
- AES/EBU digital audio input.
- EtherCon® Ethernet connector for HiQnet™ control or CobraNet digital audio transport. This "Single Plug" connection allows HiQnet protocol and CobraNet digital audio through the same CAT 5 cable.
- Analog and digital thru connectors.
- LCD Control Screen is used to adjust the amplifier's attenuation and muting, configure the amp, set up and view error monitoring, and recall DSP presets to reconfigure the amp for various applications.
- Comprehensive array of indicators provide accurate diagnostics: Power, Data, along with Ready, Signal, Clip, Thermal and Fault for each channel.
- AC mains indicator in power switch glows green when AC power is present.
- Front-panel USB connector accepts a USB drive to transfer presets from the drive to the amplifier DSP, and vice versa.
- Light weight due to aluminum chassis, special internal construction and switching power supply.
- Thermal management controller and two discrete thermal zones with variable-speed fans, forced-air cooling.
- Advanced protection circuitry guards against: shorted outputs, DC, mismatched loads, general overheating, under/over voltage, highfrequency overloads and internal faults.
- Three-Year, No-Fault, Fully Transferable Warranty completely protects your investment and guarantees its specifications.
| Minimum Guaranteed Power | |
| 20 Hz - 20 kHz with 0.35% THD Stereo, 2 ohms (per ch.) Stereo, 4 ohms (per ch.) Stereo, 8 ohms (per ch.) Bridge mono, 4 ohms Bridge mono, 8 ohms | 1800W 2000W 1250W 3600W 4000W |
| Input Sensitivity (volts RMS) for rated output | Adjustable in 0.1V steps from 1.28V to 8V |
| Voltage Gain for full rated power at 8 ohms | 37.1 dB to 22.2 dB |
| Frequency Response (at 1 watt, 20Hz - 20 kHz) | ± 0.25 dB |
| Signal to Noise Ratio below rated full-bandwidth power, A-weighted | > 108 dB |
| Total Harmonic Distortion (THD) at full rated power at 1 kHz | < 0.1% |
| Intermodulation Distortion (IMD) 60 Hz and 7 kHz at 4:1, from full rated output to Ð35 dB | < 0.35% |
| Maximum Input Level | +15 dBu or +21 dBu, depending on setting of maximum input level |
| Latency | 1.16 mS at 48 kHz, 529 µS at 96 kHz |
| A/D, D/A Converters | 24-bit 96 kHz Cirrus Logic |
| Digital Input | AES/EBU, 24-bit, 32-96 kHz. Onboard sample rate converter. |
| Network | Onboard HiQnet and TCP/IQ, compatible with standard 100Mb Ethernet hardware |
| DSP | 24-bit conversion with 32-bit, floatingpoint DSP processing |
| Attenuators | Speed-sensitive rotary encoders, 0.5 dB steps, range 0 to Ð100 dB. |
| Damping Factor (8 ohms): 20 Hz to 100 Hz | > 5000 |
| Crosstalk (below rated power, 20 Hz to 1 kHz) | > 80 dB |
| Common Mode Rejection (CMR) (20 Hz to 1 kHz) | > 55 dB, typically> 70 dB |
| DC Output Offset (Shorted input) | < ± 3 mV |
| Input Impedance (nominal) | 20 kilohms balanced, 10 kilohms unbalanced |
| Load Impedance (Note: Safe with all types of loads) Stereo Bridge Mono | 1-2-4-8-16 ohms 2-4-8 ohms |
| Required AC Mains | Universal AC input, 100-240VAC (±15%), 50/60 Hz. Max. AC mains voltage 277VAC |
| AC Line Connector | USA, UK, European, Australia, India |
| Construction | |
| Ventilation | Flow-through ventilation from front to back |
| Cooling | Dual-zone, microprocessor controlled, continuously variable speed fans |
| Dimensions | EIA Standard 19-inch rack mount width (EIA RS-310B), 3.5-inch (8.9-cm) height, 16.2-inch (41.1-cm) depth behind front mounting surface |
| Weight Net Shipping | 28 pounds (12.7 kg) 36 pounds (16.3 kg) |
Inside and out, the Crown I-TECH HD is one of the most technologically advanced professional touring amplifiers on the market today. Building on the decades of innovation, invention, and insight Crown is known for, the I-TECH HD features five new patents - three on the power supply alone - giving you an amp that goes well beyond the expected. At the heart of the new I-TECH HD is the BSS OMNIDRIVEHD processing engine. Four times faster than its predecessor and featuring Linear Phase FIR filters and LevelMAX™ limiters, OMNIDRIVEHD provides unmatched clarity and sonically pure signal processing.
Features:
- Global Power Supply with PFC (Power Factor Correction) works anywhere in the world.
- High power density, up to 8000 watts in a 2U chassis.
- Highest output voltage in the industry (200V peak) provides clean transient peaks.
- 3rd-generation patented Class I (BCA®) circuitry couples power efficiently to the load and provides low AC current draw
- Onboard high-definition DSP with 24-bit, 192 kHz Cirrus Logic SHARC A/D and D/A converters. Advanced IIR filters and linearphase FIR filters.
- Pushbutton presets simplify setup. Custom presets for various loudspeakers can be downloaded.
- AES/EBU digital audio input.
- EtherCon® Ethernet connector for HiQnet™ control or CobraNet digital audio transport. This "Single Plug" connection allows HiQnet protocol and CobraNet digital audio through the same CAT 5 cable.
- Analog and digital thru connectors.
- LCD Control Screen is used to adjust the amplifier's attenuation and muting, configure the amp, set up and view error monitoring, and recall DSP presets to reconfigure the amp for various applications.
- Comprehensive array of indicators provide accurate diagnostics: Power, Data, along with Ready, Signal, Clip, Thermal and Fault for each channel.
- AC mains indicator in power switch glows green when AC power is present.
- Front-panel USB connector accepts a USB drive to transfer presets from the drive to the amplifier DSP, and vice versa.
- Light weight due to aluminum chassis, special internal construction and switching power supply.
- Thermal management controller and two discrete thermal zones with variable-speed fans, forced-air cooling.
- Advanced protection circuitry guards against: shorted outputs, DC, mismatched loads, general overheating, under/over voltage, highfrequency overloads and internal faults.
- Three-Year, No-Fault, Fully Transferable Warranty completely protects your investment and guarantees its specifications.
| Minimum Guaranteed Power | |
| 20 Hz - 20 kHz with 0.35% THD Stereo, 2 ohms (per ch.) Stereo, 4 ohms (per ch.) Stereo, 8 ohms (per ch.) Bridge mono, 4 ohms Bridge mono, 8 ohms | 1800W 2000W 1250W 3600W 4000W |
| Input Sensitivity (volts RMS) for rated output | Adjustable in 0.1V steps from 1.28V to 8V |
| Voltage Gain for full rated power at 8 ohms | 37.1 dB to 22.2 dB |
| Frequency Response (at 1 watt, 20Hz - 20 kHz) | ± 0.25 dB |
| Signal to Noise Ratio below rated full-bandwidth power, A-weighted | > 108 dB |
| Total Harmonic Distortion (THD) at full rated power at 1 kHz | < 0.1% |
| Intermodulation Distortion (IMD) 60 Hz and 7 kHz at 4:1, from full rated output to Ð35 dB | < 0.35% |
| Maximum Input Level | +15 dBu or +21 dBu, depending on setting of maximum input level |
| Latency | 1.16 mS at 48 kHz, 529 µS at 96 kHz |
| A/D, D/A Converters | 24-bit 96 kHz Cirrus Logic |
| Digital Input | AES/EBU, 24-bit, 32-96 kHz. Onboard sample rate converter. |
| Network | Onboard HiQnet and TCP/IQ, compatible with standard 100Mb Ethernet hardware |
| DSP | 24-bit conversion with 32-bit, floatingpoint DSP processing |
| Attenuators | Speed-sensitive rotary encoders, 0.5 dB steps, range 0 to Ð100 dB. |
| Damping Factor (8 ohms): 20 Hz to 100 Hz | > 5000 |
| Crosstalk (below rated power, 20 Hz to 1 kHz) | > 80 dB |
| Common Mode Rejection (CMR) (20 Hz to 1 kHz) | > 55 dB, typically> 70 dB |
| DC Output Offset (Shorted input) | < ± 3 mV |
| Input Impedance (nominal) | 20 kilohms balanced, 10 kilohms unbalanced |
| Load Impedance (Note: Safe with all types of loads) Stereo Bridge Mono | 1-2-4-8-16 ohms 2-4-8 ohms |
| Required AC Mains | Universal AC input, 100-240VAC (±15%), 50/60 Hz. Max. AC mains voltage 277VAC |
| AC Line Connector | USA, UK, European, Australia, India |
| Construction | |
| Ventilation | Flow-through ventilation from front to back |
| Cooling | Dual-zone, microprocessor controlled, continuously variable speed fans |
| Dimensions | EIA Standard 19-inch rack mount width (EIA RS-310B), 3.5-inch (8.9-cm) height, 16.2-inch (41.1-cm) depth behind front mounting surface |
| Weight Net Shipping | 28 pounds (12.7 kg) 36 pounds (16.3 kg) |
