DALE SKU # DAS-ARTEC508AW115

DAS ARTEC-508A-W - Active Two-Way 8-Inch Point Source Loudspeaker (White)

Contact us

  • Availability:

    Special Order Item
  • This item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.


  • LET OUR TEAM OF EXPERTS ASSIST YOU

    Description

    The ARTEC-508A incorporates a single 8" loudspeaker for low frequency reproduction. The 720 W peak power of the Class D amplifier provides extended bandwith, improved dynamic range and exceptionally low distortion-features hard to find on other systems in this market segment. The DAS 8C loudspeaker provides accurate low frequency reproduction. High frequencies are handled by the M-34 compression driver with 1? exit offering excellent HF performance. The birch plywood cabinet construction offers an ultra-compact design which is available in black or white.

    Features:

    • Powered, 500 W, 8", 2 way full-range
    • 80×80 horn
    • Available in black or white
    • SPL Max: 122 dB
    • Dispersion: 80º x 80º
    • Weight: 9,9 kg ( 21,8 lb )
    Performance
    Frequency Range (-10 dB) 55 Hz Ð 20 kHz
    Horizontal Coverage (-6 dB) 80¼
    Vertical Coverage 80¼
    Maximum Peak SPL at 1 m 122 dB
    Electronics and Connectors
    Nominal Amplifier Power LF (continuous) 360 W
    Nominal Amplifier Power LF (peak) 720 W
    Nominal Amplifier Power HF (continuous) 180 W
    Nominal Amplifier Power HF (peak) 360 W
    Input Type Balanced
    Input Impeadance 20 kohms
    Input Sensitivity 1.95 V (+8 dBu)
    Audio Signal Input Connector 1 x Female XLR
    Audio Signal Loop Thru Connector 1 x Male XLR
    Recommended Signal Processing INTEGRAL-M88
    Current Draw 230 V / 115 V 1.2 A/-
    Enclosure
    Enclosure Construction Birch Plywood
    Enclosure Geometry Trapezoidal
    Rigging M10 Rigging Points
    Finish ISO-flex Paint
    Color Black
    Dimensions ( H x W x D ) 450 x 245 x 290 mm
    17,7 x 9,6 x 11,4 in
    Net Weight 9,9 kg ( 21,8 lb )
    Components
    LF Driver 8C
    HF Driver M-34
    Horn/Waveguide BC-88
    Shipping
    Carton Dimensions ( H x W x D ) 541 x 310 x 355 mm
    21,3 x 12,2 x 14,0 in
    Shipping Weight 13,6 kg ( 30,0 lb )
