DAS WR-151S-DX - Passive 15-Inch Compact Arrayable Subwoofer (Black / Direct Exposure)
Contact us
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The WR (weather resistant) series expands with a compact subwoofer designed to provide extended range for the WR series full-range cabinets. The WR-151SDX incorporates a single 800 Wrms 15" loudspeaker. The WR-151SDX offers identical cabinet dimensions as the WR-6415DXW for easy combination in tight packed arrays. Threaded rigging points and optional mounting hardware are available.
The WR-151S offers two exposure ratings: CX (covered exposure) for applications where cabinets are covered or protected, and DX (direct exposure) where cabinets are unprotected and directly exposed to the environment. The CX versions are protected with a thick ISO-flex polyurea coating on the exterior surface. The DX versions augment the protection rating by employing a fiberglass exterior. Stainless steel fittings and mounting hardware are offered on both versions.
Features:
- Passive, 800 W, 15", compact arrayable subwoofer
- DX, IP54
- Available in black or white
- SPL Max: 133 dB
- Dispersion: Omnidirectional
- Weight: 33,0 kg ( 72,8 lb )
| Performance | |
| Frequency Range (-10 dB) | 45 Hz Ð 125 Hz |
| Nominal Impedance | Passive: 4 ohms Biamp: 8 ohms |
| RMS Power Handling | 800 W |
| Peak Power Handling | 3200 W |
| On-axis Sensitivity 1W/1 m | 98 dB SPL |
| Maximum Peak SPL at 1 m | 133 dB |
| Connectors | |
| Audio Input Connector | Covered Barrier Strip Terminals |
| Audio Output Connector | Covered Barrier Strip Terminals |
| Enclosure | |
| Enclosure Construction | Birch Plywood |
| Enclosure Geometry | Rectangular |
| Rigging | M10 Rigging Points |
| Finish | Fiberglass |
| Color | Black |
| IP Rating | IP54 |
| Depth | 460 mm (18,1 in) |
| Dimensions ( H x W x D ) | 775 x 465 x 460 mm 30,5 x 18,3 x 18,1 in |
| Net Weight | 33,0 kg ( 72,8 lb ) |
| Components | |
| LF Driver | 15SX |
| Shipping | |
| Carton Dimensions ( H x W x D ) | 870 x 550 x 530 mm 34,3 x 21,7 x 20,9 in |
| Shipping Weight | 40,0 kg ( 88,0 lb ) |
The WR (weather resistant) series expands with a compact subwoofer designed to provide extended range for the WR series full-range cabinets. The WR-151SDX incorporates a single 800 Wrms 15" loudspeaker. The WR-151SDX offers identical cabinet dimensions as the WR-6415DXW for easy combination in tight packed arrays. Threaded rigging points and optional mounting hardware are available.
The WR-151S offers two exposure ratings: CX (covered exposure) for applications where cabinets are covered or protected, and DX (direct exposure) where cabinets are unprotected and directly exposed to the environment. The CX versions are protected with a thick ISO-flex polyurea coating on the exterior surface. The DX versions augment the protection rating by employing a fiberglass exterior. Stainless steel fittings and mounting hardware are offered on both versions.
Features:
- Passive, 800 W, 15", compact arrayable subwoofer
- DX, IP54
- Available in black or white
- SPL Max: 133 dB
- Dispersion: Omnidirectional
- Weight: 33,0 kg ( 72,8 lb )
| Performance | |
| Frequency Range (-10 dB) | 45 Hz Ð 125 Hz |
| Nominal Impedance | Passive: 4 ohms Biamp: 8 ohms |
| RMS Power Handling | 800 W |
| Peak Power Handling | 3200 W |
| On-axis Sensitivity 1W/1 m | 98 dB SPL |
| Maximum Peak SPL at 1 m | 133 dB |
| Connectors | |
| Audio Input Connector | Covered Barrier Strip Terminals |
| Audio Output Connector | Covered Barrier Strip Terminals |
| Enclosure | |
| Enclosure Construction | Birch Plywood |
| Enclosure Geometry | Rectangular |
| Rigging | M10 Rigging Points |
| Finish | Fiberglass |
| Color | Black |
| IP Rating | IP54 |
| Depth | 460 mm (18,1 in) |
| Dimensions ( H x W x D ) | 775 x 465 x 460 mm 30,5 x 18,3 x 18,1 in |
| Net Weight | 33,0 kg ( 72,8 lb ) |
| Components | |
| LF Driver | 15SX |
| Shipping | |
| Carton Dimensions ( H x W x D ) | 870 x 550 x 530 mm 34,3 x 21,7 x 20,9 in |
| Shipping Weight | 40,0 kg ( 88,0 lb ) |
