DALE SKU # DAS-WR322SDXW

DAS WR-322S-DXW - Passive Dual 12-Inch Installation Array Subwoofer (White / Direct Exposure)

Contact us

  • Availability:

    Special Order Item
  • This item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.


  • LET OUR TEAM OF EXPERTS ASSIST YOU

    Description

    The WR-322S-DX is a compact twin 12" subwoofer designed to provide low frequency reinforcement for the WR-320S-DX installation line array. The bass-reflex system configuration incorporates two DAS 12P loudspeakers with 3" voice coils for ample power handling.

    The Birch plywood enclosure is equipped with rigging points and finished in the durable fiber glass protective coating. The WR-322S-DX is compatible with the WR-320-DX and allows units to be flown from the subwoofers with a simple joining plate to form flown arrays.

    Features:

    • Passive, 800 W, 2x 12", compact arrayable band-pass subwoofer
    • DX for direct exposure
    • Available in black or white
    • SPL Max: 134 dB
    • Dispersion: Omnidirectional
    • Weight: 48,5 kg ( 106,9 lb )
    Performance
    Frequency Range (-10 dB) 37 Hz Ð 300 Hz
    Nominal Impedance 4 ohms
    RMS Power Handling 800 W
    Peak Power Handling 3200 W
    On-axis Sensitivity 1W/1 m 99 dB SPL
    Maximum Peak SPL at 1 m 134 dB
    Connectors
    Audio Input Connector Covered Barrier Strip Terminals
    Audio Output Connector Covered Barrier Strip Terminals
    Enclosure
    Enclosure Construction Birch Plywood
    Enclosure Geometry Rectangular
    Rigging M10 Rigging Points
    Finish Fiberglass
    Color Black
    IP Rating IP54
    Depth 690 mm (27,2 in)
    Dimensions ( H x W x D ) 365 x 700 x 690 mm
    14,4 x 27,6 x 27,2 in
    Net Weight 48,5 kg ( 106,9 lb )
    Components
    LF Driver 12P
    Shipping
    Carton Dimensions ( H x W x D ) 470 x 800 x 740 mm
    18,5 x 31,5 x 29,1 in
    Shipping Weight 52,5 kg ( 115,7 lb )

    The WR-322S-DX is a compact twin 12" subwoofer designed to provide low frequency reinforcement for the WR-320S-DX installation line array. The bass-reflex system configuration incorporates two DAS 12P loudspeakers with 3" voice coils for ample power handling.

    The Birch plywood enclosure is equipped with rigging points and finished in the durable fiber glass protective coating. The WR-322S-DX is compatible with the WR-320-DX and allows units to be flown from the subwoofers with a simple joining plate to form flown arrays.

    Features:

    • Passive, 800 W, 2x 12", compact arrayable band-pass subwoofer
    • DX for direct exposure
    • Available in black or white
    • SPL Max: 134 dB
    • Dispersion: Omnidirectional
    • Weight: 48,5 kg ( 106,9 lb )
    Performance
    Frequency Range (-10 dB) 37 Hz Ð 300 Hz
    Nominal Impedance 4 ohms
    RMS Power Handling 800 W
    Peak Power Handling 3200 W
    On-axis Sensitivity 1W/1 m 99 dB SPL
    Maximum Peak SPL at 1 m 134 dB
    Connectors
    Audio Input Connector Covered Barrier Strip Terminals
    Audio Output Connector Covered Barrier Strip Terminals
    Enclosure
    Enclosure Construction Birch Plywood
    Enclosure Geometry Rectangular
    Rigging M10 Rigging Points
    Finish Fiberglass
    Color Black
    IP Rating IP54
    Depth 690 mm (27,2 in)
    Dimensions ( H x W x D ) 365 x 700 x 690 mm
    14,4 x 27,6 x 27,2 in
    Net Weight 48,5 kg ( 106,9 lb )
    Components
    LF Driver 12P
    Shipping
    Carton Dimensions ( H x W x D ) 470 x 800 x 740 mm
    18,5 x 31,5 x 29,1 in
    Shipping Weight 52,5 kg ( 115,7 lb )
