DALE SKU # DAS-WR9606DX

DAS WR-9606-DX - Passive 2-Way 8-Inch Install Loudspeaker (Black / Direct Exposure)

Contact us

  • Availability:

    Special Order Item
  • This item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.


  • LET OUR TEAM OF EXPERTS ASSIST YOU

    Description

    The WR-9606 is a 2-way full-range passive system incorporating a 6B loudspeaker to reproduce low frequencies and the M-26 compression driver (1" diaphragm ) providing brilliant high-end reproduction.

    The ultra-compact enclosures are made from birch plywood and are available in black, white or military grey depending on the exterior finish. The WR-9606 is an IP56 system and offers two exposure ratings: CX (covered exposure) for applications where cabinets are covered or protected, and DX (direct exposure) where cabinets are unprotected and directly exposed to the environment. The CX versions are protected with a thick ISO-flex polyurea coating.

    The DX versions augment the protection rating by employing a fiberglass exterior. Stainless steel fittings and mounting hardware are offered on both versions.

    Features:

    • Passive, 200 W, 2×6?, 2 way full-range
    • 80×80 horn
    • DX, IP56
    • Available in black or white
    • SPL Max: 118 dB
    • Dispersion: 90º x 60º
    • Weight: 9,0 kg ( 19,9 lb )
    Performance
    Frequency Range (-10 dB) 70 Hz Ð 22 kHz
    Horizontal Coverage (-6 dB) 90¼
    Vertical Coverage 60¼
    Nominal Impedance 8 ohms
    RMS Power Handling 100 W
    Peak Power Handling 400 W
    On-axis Sensitivity 1W/1 m 92 dB SPL
    Maximum Peak SPL at 1 m 118 dB
    Recommended Amplifier INTEGRAL-A402
    INTEGRAL-A404
    INTEGRAL-A1002
    INTEGRAL-A1004
    INTEGRAL-A1602
    INTEGRAL-A1604
    INTEGRAL-MA1004
    INTEGRAL-MA1604
    Recommended Processor INTEGRAL-M88
    INTEGRAL-MA1604
    INTEGRAL-MA1004
    Connectors
    Audio Input Connector Covered Barrier Strip Terminals
    Audio Output Connector Covered Barrier Strip Terminals
    Enclosure
    Enclosure Construction Birch Plywood
    Enclosure Geometry Trapezoidal
    Rigging M10 Rigging Points
    Finish Fiberglass
    Color Black
    IP Rating IP56
    Depth 255 mm (10,0 in)
    Dimensions ( H x W x D ) 385 x 220 x 255 mm
    15,2 x 8,7 x 10,0 in
    Net Weight 9,0 kg ( 19,9 lb )
    Components
    LF Driver 6B
    HF Driver M-26
    Horn/Waveguide BCT-96

    The WR-9606 is a 2-way full-range passive system incorporating a 6B loudspeaker to reproduce low frequencies and the M-26 compression driver (1" diaphragm ) providing brilliant high-end reproduction.

    The ultra-compact enclosures are made from birch plywood and are available in black, white or military grey depending on the exterior finish. The WR-9606 is an IP56 system and offers two exposure ratings: CX (covered exposure) for applications where cabinets are covered or protected, and DX (direct exposure) where cabinets are unprotected and directly exposed to the environment. The CX versions are protected with a thick ISO-flex polyurea coating.

    The DX versions augment the protection rating by employing a fiberglass exterior. Stainless steel fittings and mounting hardware are offered on both versions.

    Features:

    • Passive, 200 W, 2×6?, 2 way full-range
    • 80×80 horn
    • DX, IP56
    • Available in black or white
    • SPL Max: 118 dB
    • Dispersion: 90º x 60º
    • Weight: 9,0 kg ( 19,9 lb )
    Performance
    Frequency Range (-10 dB) 70 Hz Ð 22 kHz
    Horizontal Coverage (-6 dB) 90¼
    Vertical Coverage 60¼
    Nominal Impedance 8 ohms
    RMS Power Handling 100 W
    Peak Power Handling 400 W
    On-axis Sensitivity 1W/1 m 92 dB SPL
    Maximum Peak SPL at 1 m 118 dB
    Recommended Amplifier INTEGRAL-A402
    INTEGRAL-A404
    INTEGRAL-A1002
    INTEGRAL-A1004
    INTEGRAL-A1602
    INTEGRAL-A1604
    INTEGRAL-MA1004
    INTEGRAL-MA1604
    Recommended Processor INTEGRAL-M88
    INTEGRAL-MA1604
    INTEGRAL-MA1004
    Connectors
    Audio Input Connector Covered Barrier Strip Terminals
    Audio Output Connector Covered Barrier Strip Terminals
    Enclosure
    Enclosure Construction Birch Plywood
    Enclosure Geometry Trapezoidal
    Rigging M10 Rigging Points
    Finish Fiberglass
    Color Black
    IP Rating IP56
    Depth 255 mm (10,0 in)
    Dimensions ( H x W x D ) 385 x 220 x 255 mm
    15,2 x 8,7 x 10,0 in
    Net Weight 9,0 kg ( 19,9 lb )
    Components
    LF Driver 6B
    HF Driver M-26
    Horn/Waveguide BCT-96
