DALE SKU # DIOU-DOCTRL002

DirectOut HCONTROL.16 - 16-Fader Control Surface for PRODIGY Series

Sale price$18,365.00 Regular price$20,405.00
Save $2,040.00
  • Availability:

    Special Order Item
  • This item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.


  • LET OUR TEAM OF EXPERTS ASSIST YOU

    Description

    HCONTROL.16 is a remote controller with eight bays that is designed around the PRODIGY Series. It brings all the flexibility of 'globcon controller' to a hardware front-end with comfortable feel.

    Use it for mixing and monitoring along with the multifunction processor PRODIGY.MP or the modular converter PRODIGY.MC or the multi-format matrix PRODIGY.MX - a mobile and easy to transport solution. Or combine the control of several DirectOut devices on a single hardware front-end.

    Mapping
    Free mapping of any audio channels and device functions. Assign FlexChannels, Groups, and Matrix Mixers to 12 layers and recall them easily via buttons (blue). Link customized display layouts of globcon to individual layers. 12 function buttons (pink) are assigned freely to execute device functions such as snapshot recalls or GPIO trigger on the device.

    FlexFaders
    The 100 mm motorised faders allow HCONTROL.16 to receive data from PRODIGY displaying fader status and level meter information in a tailored and fully integrated way. Their behaviour adapts on the type of channel which is assigned to them. For example, when MatMix masters are assigned to the faders, the SPILL function is available. Using the SPILL button all sources of the master become accessible for immediate level mixing while the rotary encoders are used for panning within the stereo master.

    Applications
    Applications vary between fixed installations, where one PRODIGY is controlled by several HCONTROL.16 throughout a conference set-up, and remote productions, where several PRODIGYs in different locations are remotely controlled by only one HCONTROL.16.

    Fader 16 x Fader (100 mm), touch-sensitive, motorized
    Buttons 16 x Solo, 16 x Mute, 12 x Layer, 16 x Function, 4 x Control
    Rotary 16 x Rotary encoder, touch-sensitive
    Display 16 x OLED, high-resolution display
    USB 1 x USB, type C
    Network 1 x RJ45 (10/100 Mbit/s)
    Power 12 V DC, 3A, external power supply with DC barrel connector 5.5 x 2.1 mm (center positive)
    Dimensions width 550 mm, depth 360 mm, height 80 mm
    Weight 4900 g (net), 6970 g (gross, including PSU and packaging)

    HCONTROL.16 is a remote controller with eight bays that is designed around the PRODIGY Series. It brings all the flexibility of 'globcon controller' to a hardware front-end with comfortable feel.

    Use it for mixing and monitoring along with the multifunction processor PRODIGY.MP or the modular converter PRODIGY.MC or the multi-format matrix PRODIGY.MX - a mobile and easy to transport solution. Or combine the control of several DirectOut devices on a single hardware front-end.

    Mapping
    Free mapping of any audio channels and device functions. Assign FlexChannels, Groups, and Matrix Mixers to 12 layers and recall them easily via buttons (blue). Link customized display layouts of globcon to individual layers. 12 function buttons (pink) are assigned freely to execute device functions such as snapshot recalls or GPIO trigger on the device.

    FlexFaders
    The 100 mm motorised faders allow HCONTROL.16 to receive data from PRODIGY displaying fader status and level meter information in a tailored and fully integrated way. Their behaviour adapts on the type of channel which is assigned to them. For example, when MatMix masters are assigned to the faders, the SPILL function is available. Using the SPILL button all sources of the master become accessible for immediate level mixing while the rotary encoders are used for panning within the stereo master.

    Applications
    Applications vary between fixed installations, where one PRODIGY is controlled by several HCONTROL.16 throughout a conference set-up, and remote productions, where several PRODIGYs in different locations are remotely controlled by only one HCONTROL.16.

    Fader 16 x Fader (100 mm), touch-sensitive, motorized
    Buttons 16 x Solo, 16 x Mute, 12 x Layer, 16 x Function, 4 x Control
    Rotary 16 x Rotary encoder, touch-sensitive
    Display 16 x OLED, high-resolution display
    USB 1 x USB, type C
    Network 1 x RJ45 (10/100 Mbit/s)
    Power 12 V DC, 3A, external power supply with DC barrel connector 5.5 x 2.1 mm (center positive)
    Dimensions width 550 mm, depth 360 mm, height 80 mm
    Weight 4900 g (net), 6970 g (gross, including PSU and packaging)
