Electro-Voice R300-RX - Receiver for RE300 Wireless Systems (C Band / 516-532 MHz)
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The Electro-Voice R300 opens a new category of wireless microphone in today’s market; Entry Level Professional. With one-touch ClearScan and EZ sync transmitter update the R300 is as easy to setup and use as any entry level wireless microphone. But the R300 also a true rack mountable metal receiver, metal body pack and handheld transmitters, and remote mountable antennas normally found in higher priced professional systems.
Features:
- ClearScan automatically finds the clearest channel
- EZsync one-step channel setup
- Metal receiver chassis with optional rack mount
| Receiver Type | Synthesized PLL |
| Frequency Range (RF) | A Band 618 Ð 634 MHz B Band 678 Ð 694 MHz C Band 516 Ð 532 MHz E Band 850 Ð 865 MHz |
| Number of Channels | 32 |
| Modulation | ± 40 kHz |
| Diversity | True |
| Antenna RF Sensitivity | <1.0 _V for 12 dB |
| SINAD Image Rejection | > 55 dB |
| Squelch | Tone Code plus Amplitude |
| Power Requirements | 12Ð16 VDC, 500mA max |
| Operating Temperature | 5¡C to 45¡C (41¡F to 113¡F) |
| Dimensions | 43 mm H x 206 mm W x 210 mm D (1.72 in H x 7.8 in W x 8.0 in D) |
| Audio Parameters | |
| Frequency Response | 80 Hz Ð 18 kHz ± 2 dB |
| Balanced Output | 20 dBV (max @ 40 kHz deviation) |
| Unbalanced Output | Adjustable 8 mV to 0.755V RMS |
| Distortion | < 1.0%, 0.4% typical (ref 1 kHz, 40 kHz deviation) |
| Signal-to-Noise Ratio | > 100 dB A-Weighted |
| Dynamic Range | > 95 dB |
The Electro-Voice R300 opens a new category of wireless microphone in today’s market; Entry Level Professional. With one-touch ClearScan and EZ sync transmitter update the R300 is as easy to setup and use as any entry level wireless microphone. But the R300 also a true rack mountable metal receiver, metal body pack and handheld transmitters, and remote mountable antennas normally found in higher priced professional systems.
Features:
- ClearScan automatically finds the clearest channel
- EZsync one-step channel setup
- Metal receiver chassis with optional rack mount
| Receiver Type | Synthesized PLL |
| Frequency Range (RF) | A Band 618 Ð 634 MHz B Band 678 Ð 694 MHz C Band 516 Ð 532 MHz E Band 850 Ð 865 MHz |
| Number of Channels | 32 |
| Modulation | ± 40 kHz |
| Diversity | True |
| Antenna RF Sensitivity | <1.0 _V for 12 dB |
| SINAD Image Rejection | > 55 dB |
| Squelch | Tone Code plus Amplitude |
| Power Requirements | 12Ð16 VDC, 500mA max |
| Operating Temperature | 5¡C to 45¡C (41¡F to 113¡F) |
| Dimensions | 43 mm H x 206 mm W x 210 mm D (1.72 in H x 7.8 in W x 8.0 in D) |
| Audio Parameters | |
| Frequency Response | 80 Hz Ð 18 kHz ± 2 dB |
| Balanced Output | 20 dBV (max @ 40 kHz deviation) |
| Unbalanced Output | Adjustable 8 mV to 0.755V RMS |
| Distortion | < 1.0%, 0.4% typical (ref 1 kHz, 40 kHz deviation) |
| Signal-to-Noise Ratio | > 100 dB A-Weighted |
| Dynamic Range | > 95 dB |
