Electro-Voice TX1181 - 18-Inch Passive Subwoofer
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.

Description
The Electro-Voice TX1181 is a high power subwoofer that can be used to extend the low frequency performance of the TX1122 and TX1152 loudspeaker systems. The TX1181 uses the EVS-18S, a high excursion 18" woofer, coupled to well braced enclosure with large, low distortion ports, to add high impact bass response to any full-range loudspeaker. An integrated low pass filter allows the TX1181 to be connected in parallel with a TX1122 or TX1152 on a single amplifier channel, eliminating the need for additional amplifier channels and processing. The TX1181 has many features that make it a versatile subwoofer system. The enclosure is constructed out of a combination of MDF and plywood, and coated with EVCoatTM for maximum strength and durability. The unique grille design is very strong, dent resistant, and features a rotatable logo. Four way handles allow for gripping the TX1181 in a variety of positions. The recessed input panel with dual NL4 connectors keeps the connectors hidden and allows for closer placement to a wall or other boundary. An integrated pole mount allows for elevating a TX1122 or TX1152.
Features:
- High-power LF supplement to TX1122 and TX1152
- High-excursion EVS-18S woofer
- 6 dB/octave low-pass filter for parallel connection without added amp
- 100 dB sensitivity, 132 dB max SPL
- Power handling: 500 W continuous, 2000 W peak
- Top-side socket for speaker pole
- Braced plywood/MDF enclosure
- Black EVCoat finish
Frequency Range (-10 dB) | 45 - 700kHz |
Flying | No |
Minimum Impedance | 7.5½ |
Nominal Impedance (Passive) | 8½ |
Speaker Type | Subwoofer |
Woofer Size | 18inch |
Powered or Passive | Passive |
Frequency Response (-3 dB)_ | 50 - 160Hz |
Max. SPL/1m (calc)_ | 132dB |
LF Transducer | 18-inch EVS18S |
System Power Handling (Continuous/Program/Peak) | 500//2000Watts |
Power Rating | 2000W |
Enclosure Material | Plywood and MDF with EVCOAT |
Available Color | Black |
Sensitivity 1 W/1 m | 100dB |
Height | 30.28" (769mm) |
Recommended High-Pass Frequency | 30Hz |
Width | 20" (508mm) |
Depth | 23.27" (591mm) |
Internal Crossover | Low-pass filter |
Weight Net | 74.52lbs (33.8kg) |
Family | Tour X |
Input Connections | Parallel Neutrik¨ NL4 |
The Electro-Voice TX1181 is a high power subwoofer that can be used to extend the low frequency performance of the TX1122 and TX1152 loudspeaker systems. The TX1181 uses the EVS-18S, a high excursion 18" woofer, coupled to well braced enclosure with large, low distortion ports, to add high impact bass response to any full-range loudspeaker. An integrated low pass filter allows the TX1181 to be connected in parallel with a TX1122 or TX1152 on a single amplifier channel, eliminating the need for additional amplifier channels and processing. The TX1181 has many features that make it a versatile subwoofer system. The enclosure is constructed out of a combination of MDF and plywood, and coated with EVCoatTM for maximum strength and durability. The unique grille design is very strong, dent resistant, and features a rotatable logo. Four way handles allow for gripping the TX1181 in a variety of positions. The recessed input panel with dual NL4 connectors keeps the connectors hidden and allows for closer placement to a wall or other boundary. An integrated pole mount allows for elevating a TX1122 or TX1152.
Features:
- High-power LF supplement to TX1122 and TX1152
- High-excursion EVS-18S woofer
- 6 dB/octave low-pass filter for parallel connection without added amp
- 100 dB sensitivity, 132 dB max SPL
- Power handling: 500 W continuous, 2000 W peak
- Top-side socket for speaker pole
- Braced plywood/MDF enclosure
- Black EVCoat finish
Frequency Range (-10 dB) | 45 - 700kHz |
Flying | No |
Minimum Impedance | 7.5½ |
Nominal Impedance (Passive) | 8½ |
Speaker Type | Subwoofer |
Woofer Size | 18inch |
Powered or Passive | Passive |
Frequency Response (-3 dB)_ | 50 - 160Hz |
Max. SPL/1m (calc)_ | 132dB |
LF Transducer | 18-inch EVS18S |
System Power Handling (Continuous/Program/Peak) | 500//2000Watts |
Power Rating | 2000W |
Enclosure Material | Plywood and MDF with EVCOAT |
Available Color | Black |
Sensitivity 1 W/1 m | 100dB |
Height | 30.28" (769mm) |
Recommended High-Pass Frequency | 30Hz |
Width | 20" (508mm) |
Depth | 23.27" (591mm) |
Internal Crossover | Low-pass filter |
Weight Net | 74.52lbs (33.8kg) |
Family | Tour X |
Input Connections | Parallel Neutrik¨ NL4 |
