Description
The new ZLX-G2 professional audio loudspeaker series is the next generation of the best-selling speakers from Electro-Voice, which raises the standard for performance and features in its class. The ZLX-G2 series is offered in 15-inch, 12-inch, and new 8-inch woofer sizes, both powered and passive variants. ZLX-G2 loudspeakers lead with acoustic output and extended frequency range. The Electro-Voice-patented Signal Synchronized Transducers (SST) baffle design ensures enhanced bass response, smaller size and more even coverage across all frequencies. ZLX-G2 is designed with a robust and ergonomic enclosure for day-to-day durability and portability.
POWERED BY DYNACORD, all powered ZLX-G2 loudspeakers feature a built-in digital mixer with FX, EQ, automatic feedback suppression (AFS) and ducking. The mixer includes two XLR/TRS combo jacks, and provides 24V phantom power and Hi-Z compatibility. Bluetooth® stereo streaming and linking for true wireless stereo setup are integrated into the ZLX-G2 series. The mixer and all speaker functions are easily controlled from the Electro-Voice QuickSmart Mobile app. The app allows pairing and grouping of up to six loudspeakers, in any combination. The new larger full-color LCD display and simple single encoder and push-key interface result in quick setup and more user control. Powered ZLX-G2 loudspeakers contain Electro-Voice-specific subwoofer presets that adjust for both gain and time alignment, resulting in full acoustic optimization. Additional highpass filters (HPF) are available in the DSP for increased compatibility.
ZLX-G2 series accessories such as padded covers, a Ubracket for mounting 12- and 15-inch models, a truss clamp adapter for 8-inch models, and universal wallmount brackets compatible with all models are available.
Features:
- ZLX-G2 is the next generation of the bestselling pro-audio loudspeaker series from Electro-Voice
- Increased maximum SPL output and extended frequency response
- Robust and ergonomic design for day-to-day durability and portability
- Advanced connectivity with Bluetooth® wireless stereo streaming and QuickSmart Mobile app control
- POWERED BY DYNACORD - built in digital mixer with FX, AFS, ducker, PEQ and more
Frequency response (-3 dB) (Hz) | 58 Hz Ð 20,000 Hz |
Frequency range (-10 dB) (Hz) | 50 Hz Ð 20,000 Hz |
Maximum sound pressure level at a distance of 1 m (dB) | 126 dB |
Coverage angle HxV (¡) | 90¡ x 60¡ |
Crossover frequency (kHz) | 1.40 kHz |
Power rating (W) | 1000 W |
Power consumption (V, Hz)Ê4 | 100 - 240 V~, 50 - 60 Hz |
LF transducer | WECA2088 |
LF transducer size (in) | 8 in |
LF transducer magnet material | Ferrite |
HF transducer | DECA2516 |
HF transducer type | Compression driver |
HF transducer size (in) | 1.40 in |
HF transducer magnet material | Ferrite |
HF transducer diaphragm material | Titanium |
Connector type | (2) XLR/TRS combo, (1) 1/4-inch TS Hi-Z |
Material | Polypropylene |
Grille material | Powder coated steel |
Dimensions (H x W x D) (mm) | 459.6 mm x 289.9 mm x 280.5 mm |
Dimensions (H x W x D) (in) | 18.09 in x 11.41 in x 11.04 in |
Shipping dimensions (H x W x D) (mm) | 500 mm x 390 mm x 350 mm |
Shipping dimensions (H x W x D) (in) | 19.69 in x 15.35 in x 13.78 in |
Weight (kg) | 10.64 kg |
Weight (lb) | 23.46 lb |
Shipping weight (kg) | 12.58 kg |
Shipping weight (lb) | 27.73 lb |
The new ZLX-G2 professional audio loudspeaker series is the next generation of the best-selling speakers from Electro-Voice, which raises the standard for performance and features in its class. The ZLX-G2 series is offered in 15-inch, 12-inch, and new 8-inch woofer sizes, both powered and passive variants. ZLX-G2 loudspeakers lead with acoustic output and extended frequency range. The Electro-Voice-patented Signal Synchronized Transducers (SST) baffle design ensures enhanced bass response, smaller size and more even coverage across all frequencies. ZLX-G2 is designed with a robust and ergonomic enclosure for day-to-day durability and portability.
POWERED BY DYNACORD, all powered ZLX-G2 loudspeakers feature a built-in digital mixer with FX, EQ, automatic feedback suppression (AFS) and ducking. The mixer includes two XLR/TRS combo jacks, and provides 24V phantom power and Hi-Z compatibility. Bluetooth® stereo streaming and linking for true wireless stereo setup are integrated into the ZLX-G2 series. The mixer and all speaker functions are easily controlled from the Electro-Voice QuickSmart Mobile app. The app allows pairing and grouping of up to six loudspeakers, in any combination. The new larger full-color LCD display and simple single encoder and push-key interface result in quick setup and more user control. Powered ZLX-G2 loudspeakers contain Electro-Voice-specific subwoofer presets that adjust for both gain and time alignment, resulting in full acoustic optimization. Additional highpass filters (HPF) are available in the DSP for increased compatibility.
ZLX-G2 series accessories such as padded covers, a Ubracket for mounting 12- and 15-inch models, a truss clamp adapter for 8-inch models, and universal wallmount brackets compatible with all models are available.
Features:
- ZLX-G2 is the next generation of the bestselling pro-audio loudspeaker series from Electro-Voice
- Increased maximum SPL output and extended frequency response
- Robust and ergonomic design for day-to-day durability and portability
- Advanced connectivity with Bluetooth® wireless stereo streaming and QuickSmart Mobile app control
- POWERED BY DYNACORD - built in digital mixer with FX, AFS, ducker, PEQ and more
Frequency response (-3 dB) (Hz) | 58 Hz Ð 20,000 Hz |
Frequency range (-10 dB) (Hz) | 50 Hz Ð 20,000 Hz |
Maximum sound pressure level at a distance of 1 m (dB) | 126 dB |
Coverage angle HxV (¡) | 90¡ x 60¡ |
Crossover frequency (kHz) | 1.40 kHz |
Power rating (W) | 1000 W |
Power consumption (V, Hz)Ê4 | 100 - 240 V~, 50 - 60 Hz |
LF transducer | WECA2088 |
LF transducer size (in) | 8 in |
LF transducer magnet material | Ferrite |
HF transducer | DECA2516 |
HF transducer type | Compression driver |
HF transducer size (in) | 1.40 in |
HF transducer magnet material | Ferrite |
HF transducer diaphragm material | Titanium |
Connector type | (2) XLR/TRS combo, (1) 1/4-inch TS Hi-Z |
Material | Polypropylene |
Grille material | Powder coated steel |
Dimensions (H x W x D) (mm) | 459.6 mm x 289.9 mm x 280.5 mm |
Dimensions (H x W x D) (in) | 18.09 in x 11.41 in x 11.04 in |
Shipping dimensions (H x W x D) (mm) | 500 mm x 390 mm x 350 mm |
Shipping dimensions (H x W x D) (in) | 19.69 in x 15.35 in x 13.78 in |
Weight (kg) | 10.64 kg |
Weight (lb) | 23.46 lb |
Shipping weight (kg) | 12.58 kg |
Shipping weight (lb) | 27.73 lb |
